The Bones example models are simple geometric shapes of bones and cartilage, with no HAnim structural nodes included. They are suitable for composition and reuse in HAnim models by loading via either Inline or InlineGeometry nodes.

These models are improved versions of Shape geometry found in the originals subdirectory with naming changes recorded in CHANGELOG.md.

These examples were first published in X3D Example Archives: Basic, Medical and support the work of the Web3D Humanoid Animation (HAnim) Working Group.

The majority of these bones are connected to animatable joints and can be found, with the same names, in HAnim Level of Articulation (LOA)-4, defined at Humanoid Animation (HAnim) Architecture specification draft version 4.1, clause 4 Concepts, section 4.11.6.5 LOA‑4 hierarchy. Of future note: a number of models listed here (such as teeth and cartilage) might someday get adopted to the HAnim Specification draft version 2.1 in a new section defining Level of Articulation LOA-5.

TODO: rename cartilage models; continue adding models for LOA-4 segments that are combinations of bones. Missing: c1disc.x3d r_patella.x3d l_patella.x3d l_tarsal_distal_phalanx_5.x3d.
