X3D Example Archives: Basic, Distributed Interactive Simulation

[1] AriesEspduPrototype.x3d (default X3D view from 0 0 10)
Directory Viewpoint Slideshow
DIS Gimbals Example with F18

Distributed Interactive Simulation (DIS) is an IEEE standard for conducting real-time platform-level gaming across multiple host computers and is used worldwide, especially by military organizations but also by other agencies such as those involved in space exploration and medicine.

The IEEE Distributed Interactive Simulation (DIS) networking-protocol standard can be used for synchronized virtual environments and Live, Virtual, Constructive (LVC) simulations. Ongoing development work and DIS details are maintained by the Simulation Interoperability Standards Organization (SISO) which includes the DIS Product Development Group (PDG).

X3D nodes that include DIS support are X3D nodes that include DIS support are EspduTransform, DISEntityManager, DISEntityTypeMapping, ReceiverPdu, SignalPdu and TransmitterPdu.

A supporting DIS chapter slideset is available online via X3dGraphics.com. Related work includes X3D-Edit DIS Support as well as the Open-DIS software library, which provides open-source implementations of DIS in C++, C#, Java, Objective-C and JavaScript.

Advisory: the Distributed Interactive Simulation (DIS) component in not widely supported in X3D. Further work is welcome.
