X3D XML Schema x3d-3.2.xsd

schema location:	http://www.web3d.org/specifications/x3d-3.2.xsd
attributeFormDefault:	unqualified
elementFormDefault:	qualified

Elements	Groups	Complex types	Simple types	Attr. groups
Anchor	AppearanceChildContentModel	SceneGraphStructureStatement	accessTypeChoices	DEF_USE
Appearance	AppearanceChildContentModelNoProtoInstance	X3DAppearanceChildNode	appliedParametersChoices	globalAttributes
Arc2D	ChildContentModel	X3DAppearanceNode	bboxSizeType
ArcClose2D	ChildContentModelCore	X3DBackgroundNode	closureTypeChoices
AudioClip	ChildContentModelDIS	X3DBindableNode	componentNameChoices
Background	ChildContentModelFull	X3DBoundedObject	containerFieldChoicesAudioClip
BallJoint	ChildContentModelGeoSpatial	X3DChaserNode	containerFieldChoicesColor
Billboard	ChildContentModelHumanoidAnimation	X3DChildNode	containerFieldChoicesDISEntityTypeMapping
BooleanFilter	ChildContentModelImmersive	X3DColorNode	containerFieldChoicesGroupLODShapeTransform
BooleanSequencer	ChildContentModelInteractive	X3DComposedGeometryNode	containerFieldChoicesHAnimJoint
BooleanToggle	ChildContentModelInterchange	X3DCoordinateNode	containerFieldChoicesHAnimSegment
BooleanTrigger	ChildContentModelNurbs	X3DDamperNode	containerFieldChoicesHAnimSite
BoundedPhysicsModel	ChildContentModelProtoInstance	X3DDragSensorNode	containerFieldChoicesMetadata
Box	ChildContentModelSceneGraphStructure	X3DEnvironmentalSensorNode	containerFieldChoicesPackagedShader
CADAssembly	ColorCoordinateContentModel	X3DEnvironmentTextureNode	containerFieldChoicesShaderPart
CADFace	ColorCoordinateNormalTexCoordContentModel	X3DField	containerFieldChoicesTextureCoordinate
CADLayer	ColorNormalTexCoordContentModel	X3DFogObject	containerFieldChoicesX3DCoordinateNode
CADPart	ComposedGeometryContentModel	X3DFollowerNode	containerFieldChoicesX3DNormalNode
Circle2D	GeometryContentModel	X3DFontStyleNode	containerFieldChoicesX3DTexture2DNode
ClipPlane	GeometryContentModel2D	X3DGeometricPropertyNode	containerFieldChoicesX3DTexture3DNode
CollidableOffset	GeometryContentModel2DImmersive	X3DGeometryNode	containerFieldChoicesX3DUrlObject
CollidableShape	GeometryContentModelCAD	X3DGroupingNode	containerFieldChoicesX3dUrlObjectTexture
Collision	GeometryContentModelGeoSpatial	X3DInfoNode	fieldTypeChoices
CollisionCollection	GeometryContentModelImmersive	X3DInterpolatorNode	fogTypeChoices
CollisionSensor	GeometryContentModelInteractive	X3DKeyDeviceSensorNode	fontFamilyValues
CollisionSpace	GeometryContentModelInterchange	X3DLayerNode	fontStyleChoices
Color	GeometryContentModelNurbs	X3DLayoutNode	forceOutputValues
ColorDamper	GroupingNodeChildContentModel	X3DLightNode	generatedCubeMapTextureUpdateChoices
ColorInterpolator	LayoutGroupContentModel	X3DMaterialNode	geoMetadataKeyValues
ColorRGBA	LoadSensorChildContentModel	X3DMetadataObject	geoSystemEarthEllipsoidValues
component	PickSensorGroupingNodeContentModel	X3DNBodyCollidableNode	geoSystemSpatialReferenceFrameValues
ComposedCubeMapTexture	RigidBodyCollectionContentModel	X3DNBodyCollisionSpaceNode	geoSystemType
ComposedShader	RigidBodyContentModel	X3DNetworkSensorNode	hanimFeaturePointNameValues
ComposedTexture3D	RigidJointNodeContentModel	X3DNode	hanimHumanoidInfoKeyValues
Cone	SceneGraphFragmentContentModel	X3DNodeMixedContent	hanimJointNameValues
ConeEmitter	SceneGraphFragmentWithPrototypeDeclarationsContentModel	X3DNormalNode	hanimSegmentNameValues
connect	ShapeChildContentModel	X3DNurbsControlCurveNode	hanimVersionChoices
Contact	SoundChildContentModel	X3DNurbsSurfaceGeometryNode	initializeOnlyAccessTypes
Contour2D	TextChildContentModel	X3DParametricGeometryNode	inputOnlyAccessTypes
ContourPolyline2D	TextureBackgroundChildContentModel	X3DParticleEmitterNode	inputOutputAccessTypes
Coordinate		X3DParticlePhysicsModelNode	intensityType
CoordinateDamper		X3DPickableObject	intersectionTypeValues
CoordinateDouble		X3DPickSensorNode	justifyChoices
CoordinateInterpolator		X3DPointingDeviceSensorNode	layoutAlignChoices
CoordinateInterpolator2D		X3DProductStructureChildNode	layoutScaleModeChoices
Cylinder		X3DProgrammableShaderObject	layoutUnitsChoices
CylinderSensor		X3DPrototypeInstance	metaDirectionChoices
DirectionalLight		X3DRigidJointNode	metaNameValues
DISEntityManager		X3DScriptNode	MFBool
DISEntityTypeMapping		X3DSensorNode	MFColor
Disk2D		X3DSequencerNode	MFColorRGBA
DoubleAxisHingeJoint		X3DShaderNode	MFDouble
EaseInEaseOut		X3DShapeNode	MFFloat
ElevationGrid		X3DSoundNode	MFImage
EspduTransform		X3DSoundSourceNode	MFInt32
ExplosionEmitter		X3DTexture2DNode	MFMatrix3d
EXPORT		X3DTexture3DNode	MFMatrix3f
ExternProtoDeclare		X3DTextureCoordinateNode	MFMatrix4d
Extrusion		X3DTextureNode	MFMatrix4f
field		X3DTextureTransformNode	MFNode
fieldValue		X3DTimeDependentNode	MFRotation
FillProperties		X3DTouchSensorNode	MFString
FloatVertexAttribute		X3DTriggerNode	MFTime
Fog		X3DUrlObject	MFVec2d
FogCoordinate		X3DVertexAttributeNode	MFVec2f
FontStyle		X3DViewpointNode	MFVec3d
ForcePhysicsModel		X3DViewportNode	MFVec3f
GeneratedCubeMapTexture			MFVec4d
GeoCoordinate			MFVec4f
GeoElevationGrid			multiTextureFunctionValues
GeoLocation			multiTextureModeValues
GeoLOD			multiTextureSourceValues
GeoMetadata			navigationTransitionTypeValues
GeoOrigin			navigationTypeValues
GeoPositionInterpolator			networkModeChoices
GeoProximitySensor			outputOnlyAccessTypes
GeoTouchSensor			particleSystemGeometryTypeValues
GeoTransform			phaseFunctionValues
GeoViewpoint			pickableObjectTypeValues
Group			pickSensorMatchCriterionChoices
HAnimDisplacer			pickSensorSortOrderValues
HAnimHumanoid			profileNameChoices
HAnimJoint			projectionVolumeStyleTypeChoices
HAnimSegment			SFBool
HAnimSite			SFColor
head			SFColorRGBA
ImageCubeMapTexture			SFDouble
ImageTexture			SFFloat
ImageTexture3D			SFImage
IMPORT			SFInt32
IndexedFaceSet			SFMatrix3d
IndexedLineSet			SFMatrix3f
IndexedQuadSet			SFMatrix4d
IndexedTriangleFanSet			SFMatrix4f
IndexedTriangleSet			SFNode
IndexedTriangleStripSet			SFRotation
Inline			SFString
IntegerSequencer			SFTime
IntegerTrigger			SFVec2d
IS			SFVec2f
KeySensor			SFVec3d
Layer			SFVec3f
LayerSet			SFVec4d
Layout			SFVec4f
LayoutGroup			shaderLanguageValues
LayoutLayer			shaderPartTypeValues
LinePickSensor			textureBoundaryModeChoices
LineProperties			textureCompressionModeChoices
LineSet			textureCoordinateGeneratorModeChoices
LoadSensor			textureMagnificationModeChoices
LocalFog			textureMinificationModeChoices
LOD			unitCategoryChoices
Material			x3dVersionChoices
Matrix3VertexAttribute
Matrix4VertexAttribute
meta
MetadataDouble
MetadataFloat
MetadataInteger
MetadataSet
MetadataString
MotorJoint
MovieTexture
MultiTexture
MultiTextureCoordinate
MultiTextureTransform
NavigationInfo
Normal
NormalInterpolator
NurbsCurve
NurbsCurve2D
NurbsOrientationInterpolator
NurbsPatchSurface
NurbsPositionInterpolator
NurbsSet
NurbsSurfaceInterpolator
NurbsSweptSurface
NurbsSwungSurface
NurbsTextureCoordinate
NurbsTrimmedSurface
OrientationChaser
OrientationDamper
OrientationInterpolator
OrthoViewpoint
PackagedShader
ParticleSystem
PickableGroup
PixelTexture
PixelTexture3D
PlaneSensor
PointEmitter
PointLight
PointPickSensor
PointSet
Polyline2D
PolylineEmitter
Polypoint2D
PositionChaser
PositionChaser2D
PositionDamper
PositionDamper2D
PositionInterpolator
PositionInterpolator2D
PrimitivePickSensor
ProgramShader
ProtoBody
ProtoDeclare
ProtoInstance
ProtoInterface
ProximitySensor
QuadSet
ReceiverPdu
Rectangle2D
RigidBody
RigidBodyCollection
ROUTE
ScalarChaser
ScalarInterpolator
Scene
ScreenFontStyle
ScreenGroup
Script
ShaderPart
ShaderProgram
Shape
SignalPdu
SingleAxisHingeJoint
SliderJoint
Sound
Sphere
SphereSensor
SplinePositionInterpolator
SplinePositionInterpolator2D
SplineScalarInterpolator
SpotLight
SquadOrientationInterpolator
StaticGroup
StringSensor
SurfaceEmitter
Switch
TexCoordDamper2D
Text
TextureBackground
TextureCoordinate
TextureCoordinate3D
TextureCoordinate4D
TextureCoordinateGenerator
TextureProperties
TextureTransform
TextureTransform3D
TextureTransformMatrix3D
TimeSensor
TimeTrigger
TouchSensor
Transform
TransformSensor
TransmitterPdu
TriangleFanSet
TriangleSet
TriangleSet2D
TriangleStripSet
TwoSidedMaterial
UniversalJoint
Viewpoint
ViewpointGroup
Viewport
VisibilitySensor
VolumeEmitter
VolumePickSensor
WindPhysicsModel
WorldInfo
X3D

schema location:	http://www.web3d.org/specifications/x3d-3.2-Web3dExtensionsPublic.xsd
attributeFormDefault:	unqualified
elementFormDefault:	qualified

Elements	Simple types
XvlShell	XvlShell.shellTypes

schema location:	http://www.web3d.org/specifications/x3d-3.2-Web3dExtensionsPrivate.xsd
attributeFormDefault:	unqualified
elementFormDefault:	qualified

element Anchor

diagram
type	extension of X3DGroupingNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString Background ColorInterpolator CoordinateInterpolator DirectionalLight Group NavigationInfo NormalInterpolator OrientationInterpolator PositionInterpolator ScalarInterpolator Shape TimeSensor Transform Viewpoint WorldInfo Anchor BooleanFilter BooleanSequencer BooleanToggle BooleanTrigger CylinderSensor Inline IntegerSequencer IntegerTrigger KeySensor PlaneSensor PointLight ProximitySensor SphereSensor SpotLight StringSensor Switch TimeTrigger TouchSensor AudioClip Billboard Collision Fog LoadSensor LocalFog LOD Script Sound VisibilitySensor CoordinateInterpolator2D PositionInterpolator2D ClipPlane EaseInEaseOut LinePickSensor PickableGroup PointPickSensor PrimitivePickSensor VolumePickSensor SplinePositionInterpolator SplinePositionInterpolator2D SplineScalarInterpolator SquadOrientationInterpolator StaticGroup CADAssembly CADLayer CADPart OrthoViewpoint ViewpointGroup ColorDamper CoordinateDamper OrientationChaser OrientationDamper PositionChaser PositionChaser2D PositionDamper PositionDamper2D ScalarChaser TexCoordDamper2D TextureBackground CollidableShape CollisionSensor RigidBodyCollection ParticleSystem TransformSensor EspduTransform ReceiverPdu SignalPdu TransmitterPdu DISEntityManager GeoLocation GeoLOD GeoMetadata GeoPositionInterpolator GeoProximitySensor GeoTouchSensor GeoViewpoint GeoTransform HAnimHumanoid HAnimJoint HAnimSegment HAnimSite NurbsOrientationInterpolator NurbsPositionInterpolator NurbsSurfaceInterpolator NurbsSet ProtoInstance ROUTE ExternProtoDeclare ProtoDeclare IMPORT EXPORT
used by	element  TransformSensor groups  ChildContentModelInteractive LoadSensorChildContentModel PickSensorGroupingNodeContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. bboxCenter   SFVec3f      0 0 0      bboxSize   bboxSizeType      -1 -1 -1      description   SFString            parameter   MFString            url   MFString            appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> containerField   containerFieldChoicesX3DUrlObject      children
annotation	appinfo <xs:attribute name="additionalInterface" type="xs:string" default="X3DUrlObject"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:element name="Anchor">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="additionalInterface" type="xs:string" default="X3DUrlObject"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/networking.html#Anchor"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DGroupingNode">         <xs:attribute name="description" type="SFString"/>         <xs:attribute name="parameter" type="MFString"/>         <xs:attribute name="url" type="MFString">           <xs:annotation>             <xs:appinfo>               <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>             </xs:appinfo>           </xs:annotation>         </xs:attribute>         <xs:attribute name="containerField" type="containerFieldChoicesX3DUrlObject" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute Anchor/@description

type	SFString
source	<xs:attribute name="description" type="SFString"/>

attribute Anchor/@parameter

type	MFString
source	<xs:attribute name="parameter" type="MFString"/>

attribute Anchor/@url

type	MFString
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>
source	<xs:attribute name="url" type="MFString">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>     </xs:appinfo>   </xs:annotation> </xs:attribute>

attribute Anchor/@containerField

type	containerFieldChoicesX3DUrlObject
properties	default  children
facets	Kind  Value  Annotation enumeration  children appinfo parent node has abstract type X3DGroupingNode enumeration  watchList appinfo parent node is LoadSensor
source	<xs:attribute name="containerField" type="containerFieldChoicesX3DUrlObject" default="children"/>

element Appearance

diagram
type	extension of X3DAppearanceNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString FillProperties LineProperties Material TwoSidedMaterial ComposedShader PackagedShader ProgramShader ComposedCubeMapTexture ComposedTexture3D ImageTexture ImageTexture3D MovieTexture MultiTexture PixelTexture PixelTexture3D GeneratedCubeMapTexture ImageCubeMapTexture MultiTextureTransform TextureTransform TextureTransform3D TextureTransformMatrix3D ProtoInstance
used by	groups  SceneGraphFragmentContentModel ShapeChildContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. containerField   xs:NMTOKEN      appearance
annotation	appinfo <xs:element name="fillProperties" type="SFNode" fixed="inputOutputField" default="FillProperties"> <xs:annotation> <xs:appinfo> <xs:attribute name="componentName" type="componentNameChoices" fixed="Shape"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="3"/> </xs:appinfo> </xs:annotation> </xs:element> <xs:element name="lineProperties" type="SFNode" fixed="inputOutputField" default="LineProperties"> <xs:annotation> <xs:appinfo> <xs:attribute name="componentName" type="componentNameChoices" fixed="Shape"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> </xs:appinfo> </xs:annotation> </xs:element> <!-- pointProperties added in X3D version 4.0 --> <xs:element name="material" type="SFNode" fixed="inputOutputField" default="X3DMaterialNode"/> <xs:element name="shaders" type="MFNode" fixed="inputOutputField" default="X3DShaderNode"> <xs:annotation> <xs:appinfo> <xs:attribute name="componentName" type="componentNameChoices" fixed="Shape"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="3"/> </xs:appinfo> </xs:annotation> </xs:element> <xs:element name="texture" type="SFNode" fixed="inputOutputField" default="X3DTextureNode"/> <xs:element name="textureTransform" type="SFNode" fixed="inputOutputField" default="X3DTextureTransformNode"> <xs:annotation> <xs:appinfo> <xs:attribute name="componentName" type="componentNameChoices" fixed="Shape"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> </xs:appinfo> </xs:annotation> </xs:element> <xs:attribute name="componentName" type="componentNameChoices" fixed="Shape"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>
source	<xs:element name="Appearance">   <xs:annotation>     <xs:appinfo>       <xs:element name="fillProperties" type="SFNode" fixed="inputOutputField" default="FillProperties">         <xs:annotation>           <xs:appinfo>             <xs:attribute name="componentName" type="componentNameChoices" fixed="Shape"/>             <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="3"/>           </xs:appinfo>         </xs:annotation>       </xs:element>       <xs:element name="lineProperties" type="SFNode" fixed="inputOutputField" default="LineProperties">         <xs:annotation>           <xs:appinfo>             <xs:attribute name="componentName" type="componentNameChoices" fixed="Shape"/>             <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>           </xs:appinfo>         </xs:annotation>       </xs:element>       <!-- pointProperties added in X3D version 4.0 -->       <xs:element name="material" type="SFNode" fixed="inputOutputField" default="X3DMaterialNode"/>       <xs:element name="shaders" type="MFNode" fixed="inputOutputField" default="X3DShaderNode">         <xs:annotation>           <xs:appinfo>             <xs:attribute name="componentName" type="componentNameChoices" fixed="Shape"/>             <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="3"/>           </xs:appinfo>         </xs:annotation>       </xs:element>       <xs:element name="texture" type="SFNode" fixed="inputOutputField" default="X3DTextureNode"/>       <xs:element name="textureTransform" type="SFNode" fixed="inputOutputField" default="X3DTextureTransformNode">         <xs:annotation>           <xs:appinfo>             <xs:attribute name="componentName" type="componentNameChoices" fixed="Shape"/>             <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>           </xs:appinfo>         </xs:annotation>       </xs:element>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Shape"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/shape.html#Appearance"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DAppearanceNode">         <xs:attribute name="containerField" type="xs:NMTOKEN" default="appearance"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute Appearance/@containerField

type	xs:NMTOKEN
properties	default  appearance
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="appearance"/>

element Arc2D

diagram
type	extension of X3DGeometryNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	group  GeometryContentModel2D
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. radius   derived by: SFFloat      1      startAngle   derived by: SFFloat      0      appinfo range +/- 2pi endAngle   derived by: SFFloat      1.570796      appinfo range +/- 2pi containerField   xs:NMTOKEN      geometry
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Geometry2D"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:element name="Arc2D">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Geometry2D"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/geometry2D.html#Arc2D"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DGeometryNode">         <xs:attribute name="radius" default="1">           <!-- type="SFFloatNonNegative" -->           <xs:simpleType>             <xs:restriction base="SFFloat">               <xs:minExclusive value="0"/>             </xs:restriction>           </xs:simpleType>         </xs:attribute>         <xs:attribute name="startAngle" default="0">           <xs:annotation>             <xs:appinfo>range +/- 2pi</xs:appinfo>           </xs:annotation>           <xs:simpleType>             <xs:restriction base="SFFloat">               <xs:minExclusive value="-6.2832"/>               <xs:maxExclusive value="6.2832"/>             </xs:restriction>           </xs:simpleType>         </xs:attribute>         <xs:attribute name="endAngle" default="1.570796">           <xs:annotation>             <xs:appinfo>range +/- 2pi</xs:appinfo>           </xs:annotation>           <xs:simpleType>             <xs:restriction base="SFFloat">               <xs:minExclusive value="-6.2832"/>               <xs:maxExclusive value="6.2832"/>             </xs:restriction>           </xs:simpleType>         </xs:attribute>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="geometry"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute Arc2D/@radius

type	restriction of SFFloat
properties	default  1
facets	Kind  Value  Annotation minExclusive  0
source	<xs:attribute name="radius" default="1">   <!-- type="SFFloatNonNegative" -->   <xs:simpleType>     <xs:restriction base="SFFloat">       <xs:minExclusive value="0"/>     </xs:restriction>   </xs:simpleType> </xs:attribute>

attribute Arc2D/@startAngle

type	restriction of SFFloat
properties	default  0
facets	Kind  Value  Annotation minExclusive  -6.2832 maxExclusive  6.2832
annotation	appinfo range +/- 2pi
source	<xs:attribute name="startAngle" default="0">   <xs:annotation>     <xs:appinfo>range +/- 2pi</xs:appinfo>   </xs:annotation>   <xs:simpleType>     <xs:restriction base="SFFloat">       <xs:minExclusive value="-6.2832"/>       <xs:maxExclusive value="6.2832"/>     </xs:restriction>   </xs:simpleType> </xs:attribute>

attribute Arc2D/@endAngle

type	restriction of SFFloat
properties	default  1.570796
facets	Kind  Value  Annotation minExclusive  -6.2832 maxExclusive  6.2832
annotation	appinfo range +/- 2pi
source	<xs:attribute name="endAngle" default="1.570796">   <xs:annotation>     <xs:appinfo>range +/- 2pi</xs:appinfo>   </xs:annotation>   <xs:simpleType>     <xs:restriction base="SFFloat">       <xs:minExclusive value="-6.2832"/>       <xs:maxExclusive value="6.2832"/>     </xs:restriction>   </xs:simpleType> </xs:attribute>

attribute Arc2D/@containerField

type	xs:NMTOKEN
properties	default  geometry
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="geometry"/>

element ArcClose2D

diagram
type	extension of X3DGeometryNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	group  GeometryContentModel2D
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. radius   derived by: SFFloat      1      startAngle   derived by: SFFloat      0      appinfo range +/- 2pi endAngle   derived by: SFFloat      1.570796      appinfo range +/- 2pi closureType   closureTypeChoices      PIE      solid   SFBool      false      containerField   xs:NMTOKEN      geometry
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Geometry2D"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:element name="ArcClose2D">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Geometry2D"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/geometry2D.html#ArcClose2D"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DGeometryNode">         <xs:attribute name="radius" default="1">           <!-- type="SFFloatNonNegative" -->           <xs:simpleType>             <xs:restriction base="SFFloat">               <xs:minExclusive value="0"/>             </xs:restriction>           </xs:simpleType>         </xs:attribute>         <xs:attribute name="startAngle" default="0">           <xs:annotation>             <xs:appinfo>range +/- 2pi</xs:appinfo>           </xs:annotation>           <xs:simpleType>             <xs:restriction base="SFFloat">               <xs:minExclusive value="-6.2832"/>               <xs:maxExclusive value="6.2832"/>             </xs:restriction>           </xs:simpleType>         </xs:attribute>         <xs:attribute name="endAngle" default="1.570796">           <xs:annotation>             <xs:appinfo>range +/- 2pi</xs:appinfo>           </xs:annotation>           <xs:simpleType>             <xs:restriction base="SFFloat">               <xs:minExclusive value="-6.2832"/>               <xs:maxExclusive value="6.2832"/>             </xs:restriction>           </xs:simpleType>         </xs:attribute>         <xs:attribute name="closureType" type="closureTypeChoices" default="PIE"/>         <xs:attribute name="solid" type="SFBool" default="false"/>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="geometry"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute ArcClose2D/@radius

type	restriction of SFFloat
properties	default  1
facets	Kind  Value  Annotation minExclusive  0
source	<xs:attribute name="radius" default="1">   <!-- type="SFFloatNonNegative" -->   <xs:simpleType>     <xs:restriction base="SFFloat">       <xs:minExclusive value="0"/>     </xs:restriction>   </xs:simpleType> </xs:attribute>

attribute ArcClose2D/@startAngle

type	restriction of SFFloat
properties	default  0
facets	Kind  Value  Annotation minExclusive  -6.2832 maxExclusive  6.2832
annotation	appinfo range +/- 2pi
source	<xs:attribute name="startAngle" default="0">   <xs:annotation>     <xs:appinfo>range +/- 2pi</xs:appinfo>   </xs:annotation>   <xs:simpleType>     <xs:restriction base="SFFloat">       <xs:minExclusive value="-6.2832"/>       <xs:maxExclusive value="6.2832"/>     </xs:restriction>   </xs:simpleType> </xs:attribute>

attribute ArcClose2D/@endAngle

type	restriction of SFFloat
properties	default  1.570796
facets	Kind  Value  Annotation minExclusive  -6.2832 maxExclusive  6.2832
annotation	appinfo range +/- 2pi
source	<xs:attribute name="endAngle" default="1.570796">   <xs:annotation>     <xs:appinfo>range +/- 2pi</xs:appinfo>   </xs:annotation>   <xs:simpleType>     <xs:restriction base="SFFloat">       <xs:minExclusive value="-6.2832"/>       <xs:maxExclusive value="6.2832"/>     </xs:restriction>   </xs:simpleType> </xs:attribute>

attribute ArcClose2D/@closureType

type	closureTypeChoices
properties	default  PIE
facets	Kind  Value  Annotation enumeration  PIE appinfo Connects arc endpoints to center, forming a pie wedge enumeration  CHORD appinfo Connects arc endpoints directly to each other, as in chord on a circle
source	<xs:attribute name="closureType" type="closureTypeChoices" default="PIE"/>

attribute ArcClose2D/@solid

type	SFBool
properties	default  false
source	<xs:attribute name="solid" type="SFBool" default="false"/>

attribute ArcClose2D/@containerField

type	xs:NMTOKEN
properties	default  geometry
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="geometry"/>

element AudioClip

diagram
type	extension of X3DSoundSourceNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	groups  ChildContentModelImmersive LoadSensorChildContentModel SoundChildContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. loop   SFBool      false      pauseTime   SFTime      0      appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Time"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> resumeTime   SFTime      0      appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Time"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> startTime   SFTime      0      stopTime   SFTime      0      description   SFString            pitch   derived by: SFFloat      1.0      url   MFString            appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> containerField   containerFieldChoicesAudioClip      source
annotation	appinfo <xs:attribute name="additionalInterface" type="xs:string" default="X3DUrlObject"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="Sound"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>
source	<xs:element name="AudioClip">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="additionalInterface" type="xs:string" default="X3DUrlObject"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Sound"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/sound.html#AudioClip"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DSoundSourceNode">         <xs:attribute name="url" type="MFString">           <xs:annotation>             <xs:appinfo>               <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>             </xs:appinfo>           </xs:annotation>         </xs:attribute>         <xs:attribute name="containerField" type="containerFieldChoicesAudioClip" default="source"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute AudioClip/@url

type	MFString
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>
source	<xs:attribute name="url" type="MFString">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>     </xs:appinfo>   </xs:annotation> </xs:attribute>

attribute AudioClip/@containerField

type	containerFieldChoicesAudioClip
properties	default  source
facets	Kind  Value  Annotation enumeration  source appinfo parent node is Sound node enumeration  watchList appinfo parent node is LoadSensor
source	<xs:attribute name="containerField" type="containerFieldChoicesAudioClip" default="source"/>

element Background

diagram
type	extension of X3DBackgroundNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	group  ChildContentModelInterchange
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. groundAngle   MFFloat            appinfo <xs:minInclusive value="0"/> <xs:maxInclusive value="1.5708"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> groundColor   MFColor            skyAngle   MFFloat            appinfo <xs:minInclusive value="0"/> <xs:maxInclusive value="3.1416"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> skyColor   MFColor      0 0 0      appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> Only one skyColor is required at level 1. transparency   intensityType      0      backUrl   MFString            appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> bottomUrl   MFString            appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> frontUrl   MFString            appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> leftUrl   MFString            appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> rightUrl   MFString            appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> topUrl   MFString            appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/> containerField   xs:NMTOKEN      children
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>
source	<xs:element name="Background">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/enveffects.html#Background"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DBackgroundNode">         <xs:attribute name="backUrl" type="MFString">           <xs:annotation>             <xs:appinfo>               <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>               <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>             </xs:appinfo>           </xs:annotation>         </xs:attribute>         <xs:attribute name="bottomUrl" type="MFString">           <xs:annotation>             <xs:appinfo>               <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>               <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>             </xs:appinfo>           </xs:annotation>         </xs:attribute>         <xs:attribute name="frontUrl" type="MFString">           <xs:annotation>             <xs:appinfo>               <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>               <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>             </xs:appinfo>           </xs:annotation>         </xs:attribute>         <xs:attribute name="leftUrl" type="MFString">           <xs:annotation>             <xs:appinfo>               <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>               <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>             </xs:appinfo>           </xs:annotation>         </xs:attribute>         <xs:attribute name="rightUrl" type="MFString">           <xs:annotation>             <xs:appinfo>               <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>               <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>             </xs:appinfo>           </xs:annotation>         </xs:attribute>         <xs:attribute name="topUrl" type="MFString">           <xs:annotation>             <xs:appinfo>               <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>               <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>               <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>             </xs:appinfo>           </xs:annotation>         </xs:attribute>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute Background/@backUrl

type	MFString
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:attribute name="backUrl" type="MFString">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>   </xs:annotation> </xs:attribute>

attribute Background/@bottomUrl

type	MFString
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:attribute name="bottomUrl" type="MFString">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>   </xs:annotation> </xs:attribute>

attribute Background/@frontUrl

type	MFString
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:attribute name="frontUrl" type="MFString">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>   </xs:annotation> </xs:attribute>

attribute Background/@leftUrl

type	MFString
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:attribute name="leftUrl" type="MFString">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>   </xs:annotation> </xs:attribute>

attribute Background/@rightUrl

type	MFString
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:attribute name="rightUrl" type="MFString">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>   </xs:annotation> </xs:attribute>

attribute Background/@topUrl

type	MFString
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:attribute name="topUrl" type="MFString">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Networking"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="4"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EnvironmentalEffects"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>   </xs:annotation> </xs:attribute>

attribute Background/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element BallJoint

diagram
type	extension of X3DRigidJointNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString RigidBody ProtoInstance
used by	groups  RigidBodyCollectionContentModel SceneGraphFragmentContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. forceOutput   MFString      "NONE"      anchorPoint   SFVec3f      0 0 0      containerField   xs:NMTOKEN      joints
annotation	appinfo <xs:attribute name="body1AnchorPoint" type="SFVec3f" fixed="outputOnlyField"/> <xs:attribute name="body2AnchorPoint" type="SFVec3f" fixed="outputOnlyField"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="RigidBodyPhysics"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>                 BallJoint represents an unconstrained joint between two bodies that pivot about a common anchor point.
source	<xs:element name="BallJoint">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="body1AnchorPoint" type="SFVec3f" fixed="outputOnlyField"/>       <xs:attribute name="body2AnchorPoint" type="SFVec3f" fixed="outputOnlyField"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="RigidBodyPhysics"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>                 BallJoint represents an unconstrained joint between two bodies that pivot about a common anchor point. </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/rigid_physics.html#BallJoint"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DRigidJointNode">         <xs:attribute name="anchorPoint" type="SFVec3f" default="0 0 0"/>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="joints"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute BallJoint/@anchorPoint

type	SFVec3f
properties	default  0 0 0
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){2}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
source	<xs:attribute name="anchorPoint" type="SFVec3f" default="0 0 0"/>

attribute BallJoint/@containerField

type	xs:NMTOKEN
properties	default  joints
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="joints"/>

element Billboard

diagram
type	extension of X3DGroupingNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString Background ColorInterpolator CoordinateInterpolator DirectionalLight Group NavigationInfo NormalInterpolator OrientationInterpolator PositionInterpolator ScalarInterpolator Shape TimeSensor Transform Viewpoint WorldInfo Anchor BooleanFilter BooleanSequencer BooleanToggle BooleanTrigger CylinderSensor Inline IntegerSequencer IntegerTrigger KeySensor PlaneSensor PointLight ProximitySensor SphereSensor SpotLight StringSensor Switch TimeTrigger TouchSensor AudioClip Billboard Collision Fog LoadSensor LocalFog LOD Script Sound VisibilitySensor CoordinateInterpolator2D PositionInterpolator2D ClipPlane EaseInEaseOut LinePickSensor PickableGroup PointPickSensor PrimitivePickSensor VolumePickSensor SplinePositionInterpolator SplinePositionInterpolator2D SplineScalarInterpolator SquadOrientationInterpolator StaticGroup CADAssembly CADLayer CADPart OrthoViewpoint ViewpointGroup ColorDamper CoordinateDamper OrientationChaser OrientationDamper PositionChaser PositionChaser2D PositionDamper PositionDamper2D ScalarChaser TexCoordDamper2D TextureBackground CollidableShape CollisionSensor RigidBodyCollection ParticleSystem TransformSensor EspduTransform ReceiverPdu SignalPdu TransmitterPdu DISEntityManager GeoLocation GeoLOD GeoMetadata GeoPositionInterpolator GeoProximitySensor GeoTouchSensor GeoViewpoint GeoTransform HAnimHumanoid HAnimJoint HAnimSegment HAnimSite NurbsOrientationInterpolator NurbsPositionInterpolator NurbsSurfaceInterpolator NurbsSet ProtoInstance ROUTE ExternProtoDeclare ProtoDeclare IMPORT EXPORT
used by	element  TransformSensor groups  ChildContentModelImmersive PickSensorGroupingNodeContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. bboxCenter   SFVec3f      0 0 0      bboxSize   bboxSizeType      -1 -1 -1      axisOfRotation   SFVec3f      0 1 0      containerField   xs:NMTOKEN      children
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Navigation"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:element name="Billboard">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Navigation"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/navigation.html#Billboard"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DGroupingNode">         <xs:attribute name="axisOfRotation" type="SFVec3f" default="0 1 0"/>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute Billboard/@axisOfRotation

type	SFVec3f
properties	default  0 1 0
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){2}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
source	<xs:attribute name="axisOfRotation" type="SFVec3f" default="0 1 0"/>

attribute Billboard/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element BooleanFilter

diagram
type	extension of X3DChildNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	group  ChildContentModelInteractive
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. containerField   xs:NMTOKEN      children
annotation	appinfo <xs:attribute name="set_boolean" type="SFBool" fixed="inputOnlyField"/> <xs:attribute name="inputFalse" type="SFBool" fixed="outputOnlyField"/> <xs:attribute name="inputNegate" type="SFBool" fixed="outputOnlyField"/> <xs:attribute name="inputTrue" type="SFBool" fixed="outputOnlyField"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EventUtilities"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>
source	<xs:element name="BooleanFilter">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="set_boolean" type="SFBool" fixed="inputOnlyField"/>       <xs:attribute name="inputFalse" type="SFBool" fixed="outputOnlyField"/>       <xs:attribute name="inputNegate" type="SFBool" fixed="outputOnlyField"/>       <xs:attribute name="inputTrue" type="SFBool" fixed="outputOnlyField"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EventUtilities"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/utils.html#BooleanFilter"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DChildNode">         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute BooleanFilter/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element BooleanSequencer

diagram
type	extension of X3DSequencerNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	group  ChildContentModelInteractive
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. key   MFFloat            keyValue   MFBool            containerField   xs:NMTOKEN      children
annotation	appinfo <xs:attribute name="value_changed" type="SFBool" fixed="outputOnlyField"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EventUtilities"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>
source	<xs:element name="BooleanSequencer">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="value_changed" type="SFBool" fixed="outputOnlyField"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EventUtilities"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/utils.html#BooleanSequencer"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DSequencerNode">         <xs:attribute name="keyValue" type="MFBool"/>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute BooleanSequencer/@keyValue

type	MFBool
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*((true|false)\s*,?\s*)*
source	<xs:attribute name="keyValue" type="MFBool"/>

attribute BooleanSequencer/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element BooleanToggle

diagram
type	extension of X3DChildNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	group  ChildContentModelInteractive
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. toggle   SFBool      false      containerField   xs:NMTOKEN      children
annotation	appinfo <xs:attribute name="set_boolean" type="SFBool" fixed="inputOnlyField"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EventUtilities"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>
source	<xs:element name="BooleanToggle">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="set_boolean" type="SFBool" fixed="inputOnlyField"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EventUtilities"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/utils.html#BooleanToggle"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DChildNode">         <xs:attribute name="toggle" type="SFBool" default="false"/>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute BooleanToggle/@toggle

type	SFBool
properties	default  false
source	<xs:attribute name="toggle" type="SFBool" default="false"/>

attribute BooleanToggle/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element BooleanTrigger

diagram
type	extension of X3DTriggerNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	group  ChildContentModelInteractive
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. containerField   xs:NMTOKEN      children
annotation	appinfo <xs:attribute name="set_triggerTime" type="SFTime" fixed="inputOnlyField"/> <xs:attribute name="triggerTrue" type="SFBool" fixed="outputOnlyField"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="EventUtilities"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>
source	<xs:element name="BooleanTrigger">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="set_triggerTime" type="SFTime" fixed="inputOnlyField"/>       <xs:attribute name="triggerTrue" type="SFBool" fixed="outputOnlyField"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="EventUtilities"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/utils.html#BooleanTrigger"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DTriggerNode">         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute BooleanTrigger/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element BoundedPhysicsModel

diagram
type	extension of X3DParticlePhysicsModelNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString Box Cone Cylinder IndexedFaceSet IndexedLineSet IndexedTriangleFanSet IndexedTriangleSet IndexedTriangleStripSet LineSet PointSet Sphere TriangleFanSet TriangleSet TriangleStripSet ElevationGrid Polyline2D Polypoint2D Rectangle2D TriangleSet2D Extrusion Text Arc2D ArcClose2D Circle2D Disk2D QuadSet IndexedQuadSet GeoElevationGrid NurbsCurve NurbsPatchSurface NurbsSweptSurface NurbsSwungSurface NurbsTrimmedSurface ProtoInstance
used by	element  ParticleSystem
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. enabled   SFBool      true      containerField   xs:NMTOKEN      physics
annotation	appinfo <xs:element name="geometry" type="SFNode" fixed="inputOutputField" default="X3DGeometryNode"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="ParticleSystems"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:element name="BoundedPhysicsModel">   <xs:annotation>     <xs:appinfo>       <xs:element name="geometry" type="SFNode" fixed="inputOutputField" default="X3DGeometryNode"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="ParticleSystems"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/particle_systems.html#BoundedPhysicsModel"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DParticlePhysicsModelNode">         <xs:choice minOccurs="0" maxOccurs="1">           <xs:annotation>             <xs:documentation>geometry</xs:documentation>           </xs:annotation>           <xs:group ref="GeometryContentModel"/>           <xs:element ref="ProtoInstance">             <xs:annotation>               <xs:documentation>Appropriately typed substitution node</xs:documentation>             </xs:annotation>           </xs:element>         </xs:choice>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="physics"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute BoundedPhysicsModel/@containerField

type	xs:NMTOKEN
properties	default  physics
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="physics"/>

element Box

diagram
type	extension of X3DGeometryNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	element  PrimitivePickSensor groups  GeometryContentModelInterchange RigidBodyContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. size   SFVec3f      2 2 2      solid   SFBool      true      containerField   xs:NMTOKEN      geometry
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Geometry3D"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>
source	<xs:element name="Box">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Geometry3D"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/geometry3D.html#Box"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DGeometryNode">         <xs:attribute name="size" type="SFVec3f" default="2 2 2"/>         <xs:attribute name="solid" type="SFBool" default="true"/>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="geometry"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute Box/@size

type	SFVec3f
properties	default  2 2 2
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){2}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
source	<xs:attribute name="size" type="SFVec3f" default="2 2 2"/>

attribute Box/@solid

type	SFBool
properties	default  true
source	<xs:attribute name="solid" type="SFBool" default="true"/>

attribute Box/@containerField

type	xs:NMTOKEN
properties	default  geometry
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="geometry"/>

element CADAssembly

diagram
type	extension of X3DGroupingNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString Background ColorInterpolator CoordinateInterpolator DirectionalLight Group NavigationInfo NormalInterpolator OrientationInterpolator PositionInterpolator ScalarInterpolator Shape TimeSensor Transform Viewpoint WorldInfo Anchor BooleanFilter BooleanSequencer BooleanToggle BooleanTrigger CylinderSensor Inline IntegerSequencer IntegerTrigger KeySensor PlaneSensor PointLight ProximitySensor SphereSensor SpotLight StringSensor Switch TimeTrigger TouchSensor AudioClip Billboard Collision Fog LoadSensor LocalFog LOD Script Sound VisibilitySensor CoordinateInterpolator2D PositionInterpolator2D ClipPlane EaseInEaseOut LinePickSensor PickableGroup PointPickSensor PrimitivePickSensor VolumePickSensor SplinePositionInterpolator SplinePositionInterpolator2D SplineScalarInterpolator SquadOrientationInterpolator StaticGroup CADAssembly CADLayer CADPart OrthoViewpoint ViewpointGroup ColorDamper CoordinateDamper OrientationChaser OrientationDamper PositionChaser PositionChaser2D PositionDamper PositionDamper2D ScalarChaser TexCoordDamper2D TextureBackground CollidableShape CollisionSensor RigidBodyCollection ParticleSystem TransformSensor EspduTransform ReceiverPdu SignalPdu TransmitterPdu DISEntityManager GeoLocation GeoLOD GeoMetadata GeoPositionInterpolator GeoProximitySensor GeoTouchSensor GeoViewpoint GeoTransform HAnimHumanoid HAnimJoint HAnimSegment HAnimSite NurbsOrientationInterpolator NurbsPositionInterpolator NurbsSurfaceInterpolator NurbsSet ProtoInstance ROUTE ExternProtoDeclare ProtoDeclare IMPORT EXPORT
used by	element  TransformSensor groups  ChildContentModelFull PickSensorGroupingNodeContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. bboxCenter   SFVec3f      0 0 0      bboxSize   bboxSizeType      -1 -1 -1      name   SFString            appinfo name attribute is ordinarily required, unless this is a USE node containerField   xs:NMTOKEN      children
annotation	appinfo <xs:attribute name="additionalInterface" type="xs:string" default="X3DProductStructureChildNode"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="CADGeometry"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:element name="CADAssembly">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="additionalInterface" type="xs:string" default="X3DProductStructureChildNode"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="CADGeometry"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/CADGeometry.html#CADAssembly"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DGroupingNode">         <xs:annotation>           <xs:documentation>children</xs:documentation>         </xs:annotation>         <xs:attribute name="name" type="SFString">           <xs:annotation>             <xs:appinfo>name attribute is ordinarily required, unless this is a USE node</xs:appinfo>             <!-- Design note: cannot REQUIRE @name field or else USE nodes incorrectly fail to validate -->             <xs:documentation source="https://www.web3d.org/x3d/content/examples/X3dSceneAuthoringHints.html#NameTyping"/>           </xs:annotation>         </xs:attribute>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute CADAssembly/@name

type	SFString
annotation	appinfo name attribute is ordinarily required, unless this is a USE node
source	<xs:attribute name="name" type="SFString">   <xs:annotation>     <xs:appinfo>name attribute is ordinarily required, unless this is a USE node</xs:appinfo>     <!-- Design note: cannot REQUIRE @name field or else USE nodes incorrectly fail to validate -->     <xs:documentation source="https://www.web3d.org/x3d/content/examples/X3dSceneAuthoringHints.html#NameTyping"/>   </xs:annotation> </xs:attribute>

attribute CADAssembly/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element CADFace

diagram
type	extension of X3DProductStructureChildNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString Shape LOD Transform ProtoInstance
used by	element  CADPart
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. name   SFString            appinfo name attribute is ordinarily required, unless this is a USE node bboxCenter   SFVec3f      0 0 0      bboxSize   bboxSizeType      -1 -1 -1      containerField   xs:NMTOKEN      children
annotation	appinfo <xs:element name="shape" type="SFNode" fixed="inputOutputField" default="Shape|LOD|Transform"/> <xs:attribute name="additionalInterface" type="xs:string" default="X3DBoundedObject"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="CADGeometry"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:element name="CADFace">   <xs:annotation>     <xs:appinfo>       <xs:element name="shape" type="SFNode" fixed="inputOutputField" default="Shape|LOD|Transform"/>       <xs:attribute name="additionalInterface" type="xs:string" default="X3DBoundedObject"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="CADGeometry"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/CADGeometry.html#CADFace"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DProductStructureChildNode">         <xs:choice minOccurs="0" maxOccurs="1">           <xs:annotation>             <xs:documentation>shape</xs:documentation>           </xs:annotation>           <xs:element ref="Shape"/>           <xs:element ref="LOD"/>           <xs:element ref="Transform"/>           <xs:element ref="ProtoInstance">             <xs:annotation>               <xs:documentation>Appropriately typed substitution node</xs:documentation>             </xs:annotation>           </xs:element>         </xs:choice>         <xs:attribute name="bboxCenter" type="SFVec3f" default="0 0 0"/>         <xs:attribute name="bboxSize" type="bboxSizeType" default="-1 -1 -1"/>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>       <!-- bboxDisplay, visible added in X3D version 4.0 -->     </xs:complexContent>   </xs:complexType> </xs:element>

attribute CADFace/@bboxCenter

type	SFVec3f
properties	default  0 0 0
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){2}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
source	<xs:attribute name="bboxCenter" type="SFVec3f" default="0 0 0"/>

attribute CADFace/@bboxSize

type	bboxSizeType
properties	default  -1 -1 -1
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*((([+]?(((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){2}([+]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*)|((\-1(\.(0)*)?([Ee][+-]?[0]+)?\s+){2}\-1(\.(0)*)?([Ee][+-]?[0]+)?)\s*)?
source	<xs:attribute name="bboxSize" type="bboxSizeType" default="-1 -1 -1"/>

attribute CADFace/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element CADLayer

diagram
type	extension of X3DGroupingNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString Background ColorInterpolator CoordinateInterpolator DirectionalLight Group NavigationInfo NormalInterpolator OrientationInterpolator PositionInterpolator ScalarInterpolator Shape TimeSensor Transform Viewpoint WorldInfo Anchor BooleanFilter BooleanSequencer BooleanToggle BooleanTrigger CylinderSensor Inline IntegerSequencer IntegerTrigger KeySensor PlaneSensor PointLight ProximitySensor SphereSensor SpotLight StringSensor Switch TimeTrigger TouchSensor AudioClip Billboard Collision Fog LoadSensor LocalFog LOD Script Sound VisibilitySensor CoordinateInterpolator2D PositionInterpolator2D ClipPlane EaseInEaseOut LinePickSensor PickableGroup PointPickSensor PrimitivePickSensor VolumePickSensor SplinePositionInterpolator SplinePositionInterpolator2D SplineScalarInterpolator SquadOrientationInterpolator StaticGroup CADAssembly CADLayer CADPart OrthoViewpoint ViewpointGroup ColorDamper CoordinateDamper OrientationChaser OrientationDamper PositionChaser PositionChaser2D PositionDamper PositionDamper2D ScalarChaser TexCoordDamper2D TextureBackground CollidableShape CollisionSensor RigidBodyCollection ParticleSystem TransformSensor EspduTransform ReceiverPdu SignalPdu TransmitterPdu DISEntityManager GeoLocation GeoLOD GeoMetadata GeoPositionInterpolator GeoProximitySensor GeoTouchSensor GeoViewpoint GeoTransform HAnimHumanoid HAnimJoint HAnimSegment HAnimSite NurbsOrientationInterpolator NurbsPositionInterpolator NurbsSurfaceInterpolator NurbsSet ProtoInstance ROUTE ExternProtoDeclare ProtoDeclare IMPORT EXPORT
used by	element  TransformSensor groups  ChildContentModelFull PickSensorGroupingNodeContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. bboxCenter   SFVec3f      0 0 0      bboxSize   bboxSizeType      -1 -1 -1      name   SFString            appinfo name attribute is ordinarily required, unless this is a USE node visible   MFBool            containerField   xs:NMTOKEN      children
annotation	appinfo <!-- no inheritance of X3DProductStructureChildNode though matching requirements --> <xs:attribute name="componentName" type="componentNameChoices" fixed="CADGeometry"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:element name="CADLayer">   <xs:annotation>     <xs:appinfo>       <!-- no inheritance of X3DProductStructureChildNode though matching requirements -->       <xs:attribute name="componentName" type="componentNameChoices" fixed="CADGeometry"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/CADGeometry.html#CADLayer"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DGroupingNode">         <xs:annotation>           <xs:documentation>children</xs:documentation>         </xs:annotation>         <xs:attribute name="name" type="SFString">           <xs:annotation>             <xs:appinfo>name attribute is ordinarily required, unless this is a USE node</xs:appinfo>             <!-- Design note: cannot REQUIRE @name field or else USE nodes incorrectly fail to validate -->             <xs:documentation source="https://www.web3d.org/x3d/content/examples/X3dSceneAuthoringHints.html#NameTyping"/>           </xs:annotation>         </xs:attribute>         <xs:attribute name="visible" type="MFBool"/>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute CADLayer/@name

type	SFString
annotation	appinfo name attribute is ordinarily required, unless this is a USE node
source	<xs:attribute name="name" type="SFString">   <xs:annotation>     <xs:appinfo>name attribute is ordinarily required, unless this is a USE node</xs:appinfo>     <!-- Design note: cannot REQUIRE @name field or else USE nodes incorrectly fail to validate -->     <xs:documentation source="https://www.web3d.org/x3d/content/examples/X3dSceneAuthoringHints.html#NameTyping"/>   </xs:annotation> </xs:attribute>

attribute CADLayer/@visible

type	MFBool
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*((true|false)\s*,?\s*)*
source	<xs:attribute name="visible" type="MFBool"/>

attribute CADLayer/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element CADPart

diagram
type	extension of X3DProductStructureChildNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString CADFace ProtoInstance
used by	element  TransformSensor groups  ChildContentModelFull PickSensorGroupingNodeContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. name   SFString            appinfo name attribute is ordinarily required, unless this is a USE node center   SFVec3f      0 0 0      rotation   SFRotation      0 0 1 0      scale   SFVec3f      1 1 1      scaleOrientation   SFRotation      0 0 1 0      translation   SFVec3f      0 0 0      bboxCenter   SFVec3f      0 0 0      bboxSize   bboxSizeType      -1 -1 -1      containerField   xs:NMTOKEN      children
annotation	appinfo <xs:element name="addChildren" type="MFNode" fixed="inputOnlyField" default="CADFace"> <xs:annotation> <xs:documentation>CADPart implements X3DGroupingNode but can only contain CADFace or ProtoInstance nodes</xs:documentation> </xs:annotation> </xs:element> <xs:element name="removeChildren" type="MFNode" fixed="inputOnlyField" default="CADFace"/> <xs:element name="children" type="MFNode" fixed="inputOutputField" default="CADFace"/> <xs:attribute name="additionalInterface" type="xs:string" default="X3DGroupingNode"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="CADGeometry"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:element name="CADPart">   <xs:annotation>     <xs:appinfo>       <xs:element name="addChildren" type="MFNode" fixed="inputOnlyField" default="CADFace">         <xs:annotation>           <xs:documentation>CADPart implements X3DGroupingNode but can only contain CADFace or ProtoInstance nodes</xs:documentation>         </xs:annotation>       </xs:element>       <xs:element name="removeChildren" type="MFNode" fixed="inputOnlyField" default="CADFace"/>       <xs:element name="children" type="MFNode" fixed="inputOutputField" default="CADFace"/>       <xs:attribute name="additionalInterface" type="xs:string" default="X3DGroupingNode"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="CADGeometry"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/CADGeometry.html#CADPart"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DProductStructureChildNode">         <xs:choice minOccurs="0" maxOccurs="unbounded">           <xs:annotation>             <xs:documentation>children</xs:documentation>           </xs:annotation>           <xs:element ref="CADFace"/>           <xs:element ref="ProtoInstance">             <xs:annotation>               <xs:documentation>Appropriately typed substitution node</xs:documentation>             </xs:annotation>           </xs:element>         </xs:choice>         <xs:attribute name="center" type="SFVec3f" default="0 0 0"/>         <xs:attribute name="rotation" type="SFRotation" default="0 0 1 0"/>         <xs:attribute name="scale" type="SFVec3f" default="1 1 1"/>         <xs:attribute name="scaleOrientation" type="SFRotation" default="0 0 1 0"/>         <xs:attribute name="translation" type="SFVec3f" default="0 0 0"/>         <xs:attribute name="bboxCenter" type="SFVec3f" default="0 0 0"/>         <xs:attribute name="bboxSize" type="bboxSizeType" default="-1 -1 -1"/>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>       <!-- bboxDisplay, visible added in X3D version 4.0 -->       <!-- additional contained element (node) content -->       <!-- additional contained attribute (simple-type) content, matching X3DGroupingNode -->     </xs:complexContent>   </xs:complexType> </xs:element>

attribute CADPart/@center

type	SFVec3f
properties	default  0 0 0
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){2}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
source	<xs:attribute name="center" type="SFVec3f" default="0 0 0"/>

attribute CADPart/@rotation

type	SFRotation
properties	default  0 0 1 0
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){3}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
source	<xs:attribute name="rotation" type="SFRotation" default="0 0 1 0"/>

attribute CADPart/@scale

type	SFVec3f
properties	default  1 1 1
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){2}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
source	<xs:attribute name="scale" type="SFVec3f" default="1 1 1"/>

attribute CADPart/@scaleOrientation

type	SFRotation
properties	default  0 0 1 0
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){3}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
source	<xs:attribute name="scaleOrientation" type="SFRotation" default="0 0 1 0"/>

attribute CADPart/@translation

type	SFVec3f
properties	default  0 0 0
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){2}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
source	<xs:attribute name="translation" type="SFVec3f" default="0 0 0"/>

attribute CADPart/@bboxCenter

type	SFVec3f
properties	default  0 0 0
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){2}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
source	<xs:attribute name="bboxCenter" type="SFVec3f" default="0 0 0"/>

attribute CADPart/@bboxSize

type	bboxSizeType
properties	default  -1 -1 -1
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*((([+]?(((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){2}([+]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*)|((\-1(\.(0)*)?([Ee][+-]?[0]+)?\s+){2}\-1(\.(0)*)?([Ee][+-]?[0]+)?)\s*)?
source	<xs:attribute name="bboxSize" type="bboxSizeType" default="-1 -1 -1"/>

attribute CADPart/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element Circle2D

diagram
type	extension of X3DGeometryNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	group  GeometryContentModel2D
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. radius   derived by: SFFloat      1      containerField   xs:NMTOKEN      geometry
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Geometry2D"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>
source	<xs:element name="Circle2D">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Geometry2D"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="2"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/geometry2D.html#Circle2D"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DGeometryNode">         <xs:attribute name="radius" default="1">           <!-- type="SFFloatPositive" -->           <xs:simpleType>             <xs:restriction base="SFFloat">               <xs:minExclusive value="0"/>             </xs:restriction>           </xs:simpleType>         </xs:attribute>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="geometry"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute Circle2D/@radius

type	restriction of SFFloat
properties	default  1
facets	Kind  Value  Annotation minExclusive  0
source	<xs:attribute name="radius" default="1">   <!-- type="SFFloatPositive" -->   <xs:simpleType>     <xs:restriction base="SFFloat">       <xs:minExclusive value="0"/>     </xs:restriction>   </xs:simpleType> </xs:attribute>

attribute Circle2D/@containerField

type	xs:NMTOKEN
properties	default  geometry
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="geometry"/>

element ClipPlane

diagram
type	extension of X3DChildNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString
used by	group  ChildContentModelFull
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. enabled   SFBool      true      plane   SFVec4f      0 1 0 0      appinfo <xs:minInclusive value="-1"/> <xs:maxInclusive value="1"/> containerField   xs:NMTOKEN      children
annotation	appinfo <xs:attribute name="componentName" type="componentNameChoices" fixed="Rendering"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="5"/>
source	<xs:element name="ClipPlane">   <xs:annotation>     <xs:appinfo>       <xs:attribute name="componentName" type="componentNameChoices" fixed="Rendering"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="5"/>     </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/rendering.html#ClipPlane"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DChildNode">         <xs:attribute name="enabled" type="SFBool" default="true"/>         <xs:attribute name="plane" type="SFVec4f" default="0 1 0 0">           <xs:annotation>             <xs:appinfo>               <xs:minInclusive value="-1"/>               <xs:maxInclusive value="1"/>             </xs:appinfo>           </xs:annotation>         </xs:attribute>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute ClipPlane/@enabled

type	SFBool
properties	default  true
source	<xs:attribute name="enabled" type="SFBool" default="true"/>

attribute ClipPlane/@plane

type	SFVec4f
properties	default  0 1 0 0
facets	Kind  Value  Annotation whiteSpace  collapse pattern  \s*(([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s+){3}([+-]?((0|[1-9][0-9]*)(\.[0-9]*)?|\.[0-9]+)([Ee][+-]?[0-9]+)?)\s*
annotation	appinfo <xs:minInclusive value="-1"/> <xs:maxInclusive value="1"/>
source	<xs:attribute name="plane" type="SFVec4f" default="0 1 0 0">   <xs:annotation>     <xs:appinfo>       <xs:minInclusive value="-1"/>       <xs:maxInclusive value="1"/>     </xs:appinfo>   </xs:annotation> </xs:attribute>

attribute ClipPlane/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element CollidableOffset

diagram
type	extension of X3DNBodyCollidableNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString CollidableOffset CollidableShape ProtoInstance
used by	elements  CollidableOffset CollisionCollection CollisionSpace Contact groups  RigidBodyContentModel SceneGraphFragmentContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. bboxCenter   SFVec3f      0 0 0      bboxSize   bboxSizeType      -1 -1 -1      enabled   SFBool      true      rotation   SFRotation      0 0 1 0      translation   SFVec3f      0 0 0      containerField   xs:NMTOKEN      children
annotation	appinfo <xs:element name="collidable" type="SFNode" fixed="initializeOnlyField" default="X3DNBodyCollidableNode"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="RigidBodyPhysics"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>                 CollidableOffset repositions geometry relative to center of owning body.
source	<xs:element name="CollidableOffset">   <xs:annotation>     <xs:appinfo>       <xs:element name="collidable" type="SFNode" fixed="initializeOnlyField" default="X3DNBodyCollidableNode"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="RigidBodyPhysics"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>                 CollidableOffset repositions geometry relative to center of owning body. </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/rigid_physics.html#CollidableOffset"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DNBodyCollidableNode">         <xs:choice minOccurs="0" maxOccurs="1">           <xs:element ref="CollidableOffset">             <xs:annotation>               <xs:documentation>collidable</xs:documentation>             </xs:annotation>           </xs:element>           <xs:element ref="CollidableShape">             <xs:annotation>               <xs:documentation>collidable</xs:documentation>             </xs:annotation>           </xs:element>           <xs:element ref="ProtoInstance">             <xs:annotation>               <xs:documentation>Appropriately typed substitution node</xs:documentation>             </xs:annotation>           </xs:element>         </xs:choice>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute CollidableOffset/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element CollidableShape

diagram
type	extension of X3DNBodyCollidableNode
properties	content  complex
children	IS MetadataDouble MetadataFloat MetadataInteger MetadataSet MetadataString Shape ProtoInstance
used by	elements  CollidableOffset CollisionCollection CollisionSpace Contact groups  ChildContentModelFull RigidBodyContentModel
attributes	Name   Type   Use   Default   Fixed   Annotation DEF   xs:ID            appinfo DEF defines a unique ID name for each node, referenceable by other nodes. USE   xs:IDREF            appinfo USE means reuse an already DEF-ed node ID, excluding all child nodes and all other attributes (except for containerField, which can have a different value). class   xs:NMTOKENS            appinfo The class attribute is a space-separated list of classes, reserved for use by Cascading Style Sheets (CSS) and XML stylesheets. bboxCenter   SFVec3f      0 0 0      bboxSize   bboxSizeType      -1 -1 -1      enabled   SFBool      true      rotation   SFRotation      0 0 1 0      translation   SFVec3f      0 0 0      containerField   xs:NMTOKEN      children
annotation	appinfo <xs:element name="shape" type="SFNode" fixed="initializeOnlyField" default="Shape"/> <xs:attribute name="componentName" type="componentNameChoices" fixed="RigidBodyPhysics"/> <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>                 CollidableShape connects the collision detection system, the rigid body model, and the renderable scene graph.
source	<xs:element name="CollidableShape">   <xs:annotation>     <xs:appinfo>       <xs:element name="shape" type="SFNode" fixed="initializeOnlyField" default="Shape"/>       <xs:attribute name="componentName" type="componentNameChoices" fixed="RigidBodyPhysics"/>       <xs:attribute name="componentLevel" type="xs:positiveInteger" fixed="1"/>                 CollidableShape connects the collision detection system, the rigid body model, and the renderable scene graph. </xs:appinfo>     <xs:documentation source="https://www.web3d.org/documents/specifications/19775-1/V3.3/Part01/components/rigid_physics.html#CollidableShape"/>   </xs:annotation>   <xs:complexType>     <xs:complexContent>       <xs:extension base="X3DNBodyCollidableNode">         <xs:choice minOccurs="0" maxOccurs="1">           <xs:element ref="Shape">             <xs:annotation>               <xs:documentation>shape</xs:documentation>             </xs:annotation>           </xs:element>           <xs:element ref="ProtoInstance">             <xs:annotation>               <xs:documentation>Appropriately typed substitution node</xs:documentation>             </xs:annotation>           </xs:element>         </xs:choice>         <xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute CollidableShape/@containerField

type	xs:NMTOKEN
properties	default  children
source	<xs:attribute name="containerField" type="xs:NMTOKEN" default="children"/>

element Collision
