These X3D scenes are adapted directly from the original VRML 2.0 Sourcebook chapter examples. Also available: VRML 2.0 Sourcebook chapter course notes. |
| X3D Scenes | Descriptions |
|---|---|
| Figure 13.10 Point Set Box Corners | Points in an IndexedPointSet mark the eight corners of a box. Point size is always 1 pixel regardless of distance. |
| Figure 13.11 Indexed Line Set Box Wireframe | A simple wireframe cube drawn with IndexedLineSet. |
| Figure 13.12 Indexed Face Set Cube | A simple solid cube drawn with IndexedFaceSet. |
| Figure 13.13 Indexed Face Set Lightning Bolt | A 3D lightning bolt using concave faces. Compare Figures 13.13 and 17.7b. |
| Figure 13.14 Vaulted Ceiling Piece Creased | A nonsolid vaulted ceiling piece. |
| Figure 13.15 Vaulted Ceiling Piece | A smoothly shaded vaulted ceiling piece. |
| Figure 13.16 Vaulted Ceiling | A vaulted ceiling piece used repeatedly to build part of a medieval building. |
| Figure 13.17a Morphing Cube | A morphing cube shape using IndexedFaceSet and CoordinateInterpolator. |
| Figure 13.17b Morphing Cube Line Set | A morphing cube shape using IndexedLineSet and CoordinateInterpolator. Note that constant-width lines thwart perspective rendering and lead to optical-illusion effects. |
http://www.web3d.org/x3d/content/examples/Vrml2.0Sourcebook/Chapter13-PointsLinesFaces
|
|
|
|
|
|
Current and archived nightly builds and distributions of these examples are also available.
The X3D Resources: Examples page and Savage Developers Guide provide more information about the production of this archive.
