<head>
<meta name='title' content='test-cutOffAnglesim1.x3d'/>
<meta name='MovingImage' content='test-cutOffAnglesim1-movie.mpg'/>
<meta name='reference' content=' http://www.nist.gov/vrml.html '/>
<meta name='reference' content=' http://www.itl.nist.gov/div897/ctg/vrml/vrml.html '/>
<meta name='creator' content=' http://www.itl.nist.gov/div897/ctg/vrml/members.html '/>
<meta name='disclaimer' content=' This file was provided by the National Institute of Standards and Technology, and is part of the X3D Conformance Test Suite, available at http://www.nist.gov/vrml.html The information contained within this file is provided for use in establishing conformance to the ISO VRML97 Specification. Conformance to this test does not imply recommendation or endorsement by the National Institute of Standards and Technology. This software can be redistributed and/or modified freely provided that any derivative works bear some notice that they are derived from it, and any modified versions bear some notice that they have been modified. '/>
<meta name='info' content=' Correct definition and compliance of this conformance scene is maintained by the X3D Working Group, http://www.web3d.org/working-groups/x3d '/>
<meta name='translator' content='Michael Kass NIST, Don Brutzman NPS'/>
<meta name='translated' content='21 January 2001'/>
<meta name='modified' content='12 June 2002'/>
<meta name='description' content='Test browser to set the cutOffAngle field to a range of values on a set of a simple geometry (sphere) Seven rows of spheres are drawn in the local coordinate system and a single SpotLight is defined at the center. The lights cutOffAngle is increased as the animation progesses. The animation is started by clicking on the text above the geometry. The beamWidth is set to 1.570796 for the light and is never changed. This should cause the whole area illuminated by the light to be lighted at full intensity. The area of illumination shall be no larger than the maximum value for the cutOffAngle (0.4). A browser may choose to ignore the beamWidth field.'/>
<meta name='identifier' content=' http://www.web3d.org/x3d/content/examples/ConformanceNist/Lights/SpotLight/test-cutOffAnglesim1.x3d '/>
<meta name='generator' content='Vrml97ToX3dNist, http://ovrt.nist.gov/v2_x3d.html'/>
<meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
<meta name='license' content=' ../../license.html'/>
</head>
<!--
Index for DEF nodes : text-color, text-time, the-appearance, the-click, the-cutoff, the-light, the-sphere, the-time, the-touch
Index for Viewpoint image : Viewpoint_1
-->
<Scene>
<Group>
<Viewpoint description='Front View' position='0 0 15'/>
</Group>
<Background groundColor='0 0 0' skyColor='1 0 0'/>
<NavigationInfo headlight='false' type='"EXAMINE" "WALK" "FLY" "ANY"'/>
<PointLight on='false'/>
<DirectionalLight on='false'/>
<Transform scale='0.02 0.02 0.02' translation='-3.4 4 0'>
<Shape>
<Appearance>
<!-- the-click ROUTE:  [from text-color.value_changed to emissiveColor ] -->
<Material DEF='the-click' ambientIntensity='1' emissiveColor='0 0 1'/>
</Appearance>
<Text string='"CLICK HERE TO START"'>
<FontStyle size='32' style='BOLD'/>
</Text>
</Shape>
<!-- the-touch ROUTEs:  [from touchTime to text-time.startTime ] [from touchTime to the-time.startTime ] -->
<TouchSensor DEF='the-touch' description='touch to activate'/>
</Transform>
<!-- the-light ROUTE:  [from the-cutoff.value_changed to cutOffAngle ] -->
<SpotLight DEF='the-light' beamWidth='1.57079' cutOffAngle='0.01' location='0 0 7' radius='7'/>
<!-- text-time ROUTEs:  [from the-touch.touchTime to startTime ] [from fraction_changed to text-color.set_fraction ] -->
<TimeSensor DEF='text-time'/>
<!-- the-time ROUTEs:  [from the-touch.touchTime to startTime ] [from fraction_changed to the-cutoff.set_fraction ] -->
<TimeSensor DEF='the-time' cycleInterval='8'/>
<!-- the-cutoff ROUTEs:  [from the-time.fraction_changed to set_fraction ] [from value_changed to the-light.cutOffAngle ] -->
<ScalarInterpolator DEF='the-cutoff' key='0 0.2 0.4 0.6 0.8 1' keyValue='0.1 0.15 0.2 0.25 0.3 0.4'/>
<!-- text-color ROUTEs:  [from text-time.fraction_changed to set_fraction ] [from value_changed to the-click.emissiveColor ] -->
<ColorInterpolator DEF='text-color' key='0 0.5 1' keyValue='0 0 1 1 1 1 0 0 1'/>
<Transform translation='-4 0 0'>
<Shape>
<Appearance DEF='the-appearance'>
<Material/>
</Appearance>
<Sphere DEF='the-sphere' radius='0.4'/>
</Shape>
