DolphinExample.x3d (X3dToXhtml listing)

X3D Model Documentation: DolphinExample.x3d

1	`<?xml version="1.0" encoding="UTF-8"?>`
2	`<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">`
3	<X3D profile='Immersive' version='3.0' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
4	<head>
5	<meta name='title' content=' DolphinExample.x3d '/>
6	<meta name='description' content='Manual translation of Dolphin model from the Prototype Repository.'/>
7	<meta name='creator' content='unknown, if you know then please contact brutzman@nps.navy.mil'/>
8	<meta name='translator' content='Don Brutzman'/>
9	<meta name='created' content='22 January 2001'/>
10	<meta name='modified' content='20 October 2019'/>
11	<meta name='reference' content=' NavyDolphinLocatesSunkenBoatAugust1997.txt '/>
12	<meta name='reference' content=' http://www.chinfo.navy.mil/navpalib/news/navywire/nwsa97/nwsa0822.txt '/>
13	<meta name='reference' content='http://www.vrml-content.org'/>
14	<meta name='subject' content='VRML X3D Prototype ProtoRepository Dolphin'/>
15	<meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Savage/Biologics/Dolphin/DolphinExample.x3d '/>
16	<meta name='generator' content='X3D-Edit 3.2, https://www.web3d.org/x3d/tools/X3D-Edit'/>
17	<meta name='license' content='../../license.html'/>
18	</head>

<!--

Event Graph ROUTE Table shows event connections.

-->
<!--

DEF nodes index: DOLPHIN, TS

Index for Viewpoint nodes: Viewpoint_1, Viewpoint_2, Viewpoint_3, Viewpoint_4, Viewpoint_5, Viewpoint_6

Index for ExternProtoDeclare definition: Dolphin

-->

19	<Scene>
20	<WorldInfo title='DolphinExample.x3d'/>
21	<ExternProtoDeclare name='Dolphin' url=' "DolphinPrototype.wrl#Dolphin" "https://www.web3d.org/x3d/content/examples/Savage/Biologics/Dolphin/DolphinPrototype.wrl#Dolphin" "DolphinPrototype.x3d#Dolphin" "https://www.web3d.org/x3d/content/examples/Savage/Biologics/Dolphin/DolphinPrototype.x3d#Dolphin" '>
22	<field name='set_fraction' type='SFFloat' accessType='inputOnly'/>
23	<field name='collide' type='SFBool' accessType='inputOutput'/>
24	<field name='collideTime' type='SFTime' accessType='outputOnly'/>
25	</ExternProtoDeclare>
26	<!-- ==================== -->
27	<!-- ROUTE information for DOLPHIN node: [from TS.fraction_changed to set_fraction ] --> <ProtoInstance name='Dolphin' DEF='DOLPHIN'/>
28	<Background groundAngle='1.57079' groundColor='0.15 0.3 0.35 0.35 0.65 0.65' skyAngle='1.57079' skyColor='1 1 1 0.35 0.65 0.65'/>
29	<DirectionalLight ambientIntensity='.7' color='.55 .75 .75' direction='0 -1 0'/>
30	<Viewpoint description='SideFar' position='0 0 9'/>
31	<Viewpoint description='Side' position='0 0 4.059'/>
32	<Viewpoint description='Front' orientation='0 1 0 1.56' position='4.097 -.42 0.044'/>
33	<Viewpoint description='Bottom' orientation='.5573 .6209 -.5513 2.0205' position='.617 -6.46 0.006'/>
34	<Viewpoint description='Top' orientation='.5966 -.5438 -.5902 4.1469' position='-.688 6.516 -0.008'/>
35	<Viewpoint description='CloseUpAngle' orientation='-0.0384 .9991 0.0161 .7972' position='1.896 -.333 1.341'/>
36	<!-- ROUTE information for TS node: [from fraction_changed to DOLPHIN.set_fraction ] --> <TimeSensor DEF='TS' loop='true'/>
37	< ROUTE fromNode='TS' fromField='fraction_changed' toNode='DOLPHIN' toField='set_fraction'/>
38	</Scene>
39	</X3D>

<!--

Event Graph ROUTE Table shows event connections.

-->
<!--

-->

X3D Tooltips element index: Background, DirectionalLight, ExternProtoDeclare, field, head, meta, ProtoInstance, ROUTE, Scene, TimeSensor, Viewpoint, WorldInfo, X3D, plus documentation for accessType definitions, type definitions, XML data types, and field types

Event Graph ROUTE Table with 1 ROUTE connection total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

TS
TimeSensor
fraction_changed
SFFloat

→
ROUTE
event to
(1)

DOLPHIN
ProtoInstance
set_fraction
SFFloat

DOLPHIN
ProtoInstance
Dolphin

No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀

-->
