X3D Model Documentation: MainStage.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2  <!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 4.0//EN" "https://www.web3d.org/specifications/x3d-4.0.dtd">
  3  <X3D profile='Immersive' version='4.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-4.0.xsd'>
  4       <head>
  5            <component level='1' name='HAnim'/>
  6            <meta name='title' content=' MainStage.x3d '/>
  7            <meta name='description' content='Main stage for HAnim scene Winter and Spring.'/>
  8            <meta name='creator' content='Carol McDonald, Joe Williams, Katy Schildmeyer, and John Carlson'/>
  9            <meta name='translator' content='Joe Williams and Don Brutzman'/>
 10            <meta name='created' content='25 May 2023'/>
 11            <meta name='modified' content='8 September 2024'/>
 12            <meta name='reference' content=' MainStageREADME.txt '/>
 13            <meta name='hint' content='containerField=watchList changed to containerField=children in X3D 4.0'/>
 14            <meta name='MovingImage' content='WinterAndSpring3 by Joe Williams https://youtu.be/5HrX7_uu9mU'/>
 15            <meta name='reference' content=' originals/0WSMainStage09g.x3d '/>
 16            <meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/MainStage.x3d '/>
 17            <meta name='generator' content='X3D-Edit 4.0, https://www.web3d.org/x3d/tools/X3D-Edit'/>
 18            <meta name='license' content='../license.html'/>
 19       </head>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->
<!-- to top DEF nodes index: Background1Black, Background1BlackSequencer, Background2GraySkyGreenGrass, Background2GraySkyGreenGrassSequencer, Background3BlueSkyGreenGrass, Background3SkyBlueGreenGrassSequencer, Background4DarkGrey, Background4DarkGreySequencer, BackgroundsAndBackgroundSwitching, BorderFlowers, Bushes, BushesTransform, CaneFitting, CharactersAndCharacterViewpoints, Clock100Seconds, Clock100SecondsTRIGGER, DelayFILTER, DelayTIME, EveryInlineLoadSensor, Floor, FlowerGardens, FlowerSet, Gramps, Gramps_HumanoidRoot_RotationInterpolator, Gramps_HumanoidRoot_TranslationInterpolator, Gramps01View, Gramps01ViewSequencer, Gramps03View, Gramps03ViewSequencer, Gramps11, GrampsBox, GrampsGrandKids, GrampsStage, JointCoordinateAxes, Leif, Leif_HumanoidRoot_RotationInterpolator, Leif_Root_TranslationInterpolator, LeifAnimated, LeifBox, LeifView, LeifViewSequencer, Lily, Lily_HumanoidRoot_RotationInterpolator, Lily_HumanoidRoot_TranslationInterpolator, LilyAnimated, LilyBox, Lilyview, LilyViewSequencer, Melodies1, PathMeshTopSurface, Pathway, PathwayGrid, PathwaySurface1, PathwaySurface2, Scene_GrampsBack1View, Scene_GrampsBack1ViewSequencer, Scene_KidsRunningTowardGramps, Scene_KidsRunningTowardGrampsSequencer, Scene_StageFarView, Scene_StageFarViewSequencer, SceneMusic1, SceneViewpoints01, SceneViewPoints02, StageDecorations, StageSurface, StartTIME, TitlesandViewpointsInOrderofAppearance, TitleSet1, TitleSet1of2, Tufani, Tufani_HumanoidRoot_RotationInterpolator, Tufani_HumanoidRoot_TranslationInterpolator, TufaniAnimated, TufaniBox, Tufaniview, TufaniViewSequencer, TwoFlowerGardens, WinterAndSpringTitle, WinterAndSpringTitleView, WinterAndSpringTitleViewSequencer, WSAudio, WSAuthorsTitle, WSAuthorsTitleView, WSAuthorsTitleViewSequencer, WSDedicationTitle, WSDedicationTitleView, WSDedicationTitleViewSequencer, WSMusicCreditsTitle, WSMusicCreditsTitleView, WSMusicCreditsTitleViewSequencer, WSThanksTitle, WSThanksTitleView, WSThanksTitleViewSequencer

Index for Viewpoint nodes: Gramps01View, Gramps03View, LeifView, Lilyview, Scene_GrampsBack1View, Scene_KidsRunningTowardGramps, Scene_StageFarView, Tufaniview, WinterAndSpringTitleView, WSAuthorsTitleView, WSDedicationTitleView, WSMusicCreditsTitleView, WSThanksTitleView
-->
 20       <Scene>
 21            <WorldInfo title='MainStage.x3d'/>
 22            <NavigationInfo headlight='false' transitionTime='0'/>
 23            <!-- These lights are intentionally shining on all of the models loaded within a top-level scene -->
 24            <DirectionalLight direction='0 0 1' global='true' intensity='0.75'/>
 25            <DirectionalLight global='true' intensity='0.75'/>
 26            <DirectionalLight global='true' intensity='0.75'/>
 27            <DirectionalLight direction='-1 0 0' global='true' intensity='0.75'/>
 28            <DirectionalLight direction='0 -0.75 0' global='true' intensity='0.75'/>
 29
          <!-- ROUTE information for StartTIME node:  [from EveryInlineLoadSensor.loadTime to startTime ] [from stopTime to DelayTIME.set_startTime ] [from stopTime to Melodies1.set_startTime ] [self-route from cycleTime to set_stopTime ] -->
           <TimeSensor DEF='StartTIME'/>
 30            <!-- scene ready signal Start audio -->
 31
          <!-- ROUTE information for DelayTIME node:  [from StartTIME.stopTime to set_startTime ] [from isActive to DelayFILTER.set_boolean ] -->
           <TimeSensor DEF='DelayTIME' cycleInterval='0.5'/>
 32            <!-- delay between start audio and start animations -->
 33
          <!-- ROUTE information for Clock100Seconds node:  [from Clock100SecondsTRIGGER.triggerTime to set_startTime ] [from fraction_changed to Gramps_HumanoidRoot_TranslationInterpolator.set_fraction ] [from fraction_changed to Gramps_HumanoidRoot_RotationInterpolator.set_fraction ] [from fraction_changed to Leif_Root_TranslationInterpolator.set_fraction ] [from fraction_changed to Leif_HumanoidRoot_RotationInterpolator.set_fraction ] [from fraction_changed to Lily_HumanoidRoot_TranslationInterpolator.set_fraction ] [from fraction_changed to Lily_HumanoidRoot_RotationInterpolator.set_fraction ] [from fraction_changed to Tufani_HumanoidRoot_TranslationInterpolator.set_fraction ] [from fraction_changed to Tufani_HumanoidRoot_RotationInterpolator.set_fraction ] [from fraction_changed to Scene_StageFarViewSequencer.set_fraction ] [from fraction_changed to WinterAndSpringTitleViewSequencer.set_fraction ] [from fraction_changed to WSAuthorsTitleViewSequencer.set_fraction ] [from fraction_changed to Scene_GrampsBack1ViewSequencer.set_fraction ] [from fraction_changed to Scene_KidsRunningTowardGrampsSequencer.set_fraction ] [from fraction_changed to LeifViewSequencer.set_fraction ] [from fraction_changed to LilyViewSequencer.set_fraction ] [from fraction_changed to TufaniViewSequencer.set_fraction ] [from fraction_changed to Gramps01ViewSequencer.set_fraction ] [from fraction_changed to Gramps03ViewSequencer.set_fraction ] [from fraction_changed to WSDedicationTitleViewSequencer.set_fraction ] [from fraction_changed to WSThanksTitleViewSequencer.set_fraction ] [from fraction_changed to WSMusicCreditsTitleViewSequencer.set_fraction ] [from fraction_changed to Background1BlackSequencer.set_fraction ] [from fraction_changed to Background2GraySkyGreenGrassSequencer.set_fraction ] [from fraction_changed to Background3SkyBlueGreenGrassSequencer.set_fraction ] [from fraction_changed to Background4DarkGreySequencer.set_fraction ] -->
           <TimeSensor DEF='Clock100Seconds' cycleInterval='100'/>
 34            <!-- start animation -->
 35
          <!-- ROUTE information for DelayFILTER node:  [from DelayTIME.isActive to set_boolean ] [from inputFalse to Clock100SecondsTRIGGER.set_boolean ] -->
           <BooleanFilter DEF='DelayFILTER'/>
 36
          <!-- ROUTE information for Clock100SecondsTRIGGER node:  [from DelayFILTER.inputFalse to set_boolean ] [from triggerTime to Clock100Seconds.set_startTime ] -->
           <TimeTrigger DEF='Clock100SecondsTRIGGER'/>
 37            <!-- generate Clock100Seconds startTime from completion of Delay -->
 38            < ROUTE  fromNode='StartTIME' fromField='cycleTime' toNode='StartTIME' toField='set_stopTime'/>
 39            <!-- stop Start -->
 40            < ROUTE  fromNode='StartTIME' fromField='stopTime' toNode='DelayTIME' toField='set_startTime'/>
 41            <!-- turn on delay and audio -->
 42            < ROUTE  fromNode='DelayTIME' fromField='isActive' toNode='DelayFILTER' toField='set_boolean'/>
 43            < ROUTE  fromNode='DelayFILTER' fromField='inputFalse' toNode='Clock100SecondsTRIGGER' toField='set_boolean'/>
 44            < ROUTE  fromNode='Clock100SecondsTRIGGER' fromField='triggerTime' toNode='Clock100Seconds' toField='set_startTime'/>
 45            <!-- start animation timer -->
 46            <Group DEF='WSAudio'>
 47                 <Sound DEF='SceneMusic1' location='-5 10 10' maxBack='50' maxFront='50' minBack='25' minFront='25' spatialize='false'>
 48                      <!-- X3D Players should pick the first version that works, providing better interoperability -->
 49                      <!-- For playability in this very big scene, the audio files are ordered by smaller file sizes first -->
 50
                    <!-- ROUTE information for Melodies1 node:  [from StartTIME.stopTime to set_startTime ] -->
                     <AudioClip DEF='Melodies1' description='John Harrison with the Wichita State University Chamber'   url=' "audio/Winter_Spring_rv2_keyedMono.wav" "audio/winter_spring_rv2_keyed_143.wav" "audio/winter_spring_rv2_keyed.mp3" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/audio/Winter_Spring_rv2_keyedMono.wav" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/audio/winter_spring_rv2_keyed_143.wav" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/audio/winter_spring_rv2_keyed.mp3" '/>
 51                 </Sound>
 52                 <!-- start audio -->
 53                 < ROUTE  fromNode='StartTIME' fromField='stopTime' toNode='Melodies1' toField='set_startTime'/>
 54            </Group>
 55            <Group DEF='GrampsStage'>
 56                 <Group DEF='StageSurface'>
 57                      <Transform DEF='Floor' translation='15 -0.3 15'>
 58                           <Shape>
 59                                <Box size='1500 0.1 1500'/>
 60                                <Appearance>
 61                                     <ImageTexture   url=' "images/Lawn.jpg " "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/images/Lawn.jpg " '/>
 62                                     <Material diffuseColor='0 0.8 0.0' emissiveColor='0 0.7 0' specularColor='0 0.4 0'/>
 63                                </Appearance>
 64                           </Shape>
 65                      </Transform>
 66                      <Transform DEF='PathwaySurface1' translation='0 -0.15 0'>
 67
                         <!-- Inline PathMeshTopSurface is a DEF node that has 2 USE nodes: USE_1, USE_2 -->
                          <Inline DEF='PathMeshTopSurface'   url=' "PathMeshTopSurface.x3d" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/PathMeshTopSurface.x3d" "PathMeshTopSurface.wrl" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/PathMeshTopSurface.wrl" '/>
 68                      </Transform>
 69                      <Transform DEF='PathwaySurface2' translation='0 -0.1 0.1'>
 70                           <Inline USE='PathMeshTopSurface'/>
 71                      </Transform>
 72                      <Transform DEF='PathwayGrid' translation='0.0 -0.12 0'>
 73
                         <!-- Inline Pathway is a DEF node that has 1 USE node: USE_1 -->
                          <Inline DEF='Pathway'   url=' "Pathway.x3d" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/Pathway.x3d" "Pathway.wrl" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/Pathway.wrl" '/>
 74                      </Transform>
 75                 </Group>
 76                 <Group DEF='StageDecorations'>
 77                      <Transform DEF='BushesTransform' translation='0 -0.2 0'>
 78
                         <!-- Inline Bushes is a DEF node that has 1 USE node: USE_1 -->
                          <Inline DEF='Bushes'   url=' "Bushes.x3d" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/Bushes.x3d" "Bushes.wrl" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/Bushes.wrl" '/>
 79                      </Transform>
 80                      <Transform DEF='BorderFlowers'>
 81
                         <!-- Inline FlowerSet is a DEF node that has 1 USE node: USE_1 -->
                          <Inline DEF='FlowerSet'   url=' "FlowerSet.x3d" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/FlowerSet.x3d" "FlowerSet.wrl" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/FlowerSet.wrl" '/>
 82                      </Transform>
 83                      <Transform DEF='TwoFlowerGardens'>
 84
                         <!-- Inline FlowerGardens is a DEF node that has 1 USE node: USE_1 -->
                          <Inline DEF='FlowerGardens'   url=' "FlowerGardens.x3d" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/FlowerGardens.x3d" "FlowerGardens.wrl" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/FlowerGardens.wrl" '/>
 85                      </Transform>
 86                 </Group>
 87                 <Group DEF='TitlesandViewpointsInOrderofAppearance'>
 88
                    <!-- ROUTE information for Scene_StageFarView node:  [from Scene_StageFarViewSequencer.value_changed to set_bind ] -->
                     <Viewpoint DEF='Scene_StageFarView' centerOfRotation='9.8557 0 3.5' description='Stage Far View' orientation='0.5 1.76 0.3 -1' position='-15 10 32'/>
 89                      <Group DEF='TitleSet1of2'>
 90                           <Transform DEF='TitleSet1'>
 91                                <Transform DEF='WinterAndSpringTitle' translation='10 10 0'>
 92
                                   <!-- ROUTE information for WinterAndSpringTitleView node:  [from WinterAndSpringTitleViewSequencer.value_changed to set_bind ] -->
                                    <Viewpoint DEF='WinterAndSpringTitleView' description='Look at WS title' jump='false' orientation='-0.15 0 0 0.2' position='0 0.75 4'/>
 93                                     <Shape>
 94                                          <Box size='4 3 0.25'/>
 95                                          <Appearance>
 96                                               <ImageTexture   url=' "images/WinterAndSpring.png " "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/images/WinterAndSpring.png " '/>
 97                                               <Material/>
 98                                          </Appearance>
 99                                     </Shape>
100                                </Transform>
101                                <Transform DEF='WSAuthorsTitle' translation='10 10 -5'>
102
                                   <!-- ROUTE information for WSAuthorsTitleView node:  [from WSAuthorsTitleViewSequencer.value_changed to set_bind ] -->
                                    <Viewpoint DEF='WSAuthorsTitleView' description='Look at Authors title' jump='false' orientation='-0.15 0 0 0.2' position='0 1 5'/>
103                                     <Shape>
104                                          <Box size='4 3 0.25'/>
105                                          <Appearance>
106                                               <ImageTexture   url=' "images/WSAuthorsAll.png " "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/images/WSAuthorsAll.png " '/>
107                                               <Material/>
108                                          </Appearance>
109                                     </Shape>
110                                </Transform>
111                           </Transform>
112                      </Group>
113                      <Group DEF='SceneViewpoints01'>
114                           <!-- Looking down the path -->
115
                         <!-- ROUTE information for Scene_GrampsBack1View node:  [from Scene_GrampsBack1ViewSequencer.value_changed to set_bind ] -->
                          <Viewpoint DEF='Scene_GrampsBack1View' centerOfRotation='7 1.5 0' description='Looking down the path' orientation='0 1 0 -2.7' position='7 2 -6.5'/>
116                           <!-- Looking toward the bushes -->
117
                         <!-- ROUTE information for Scene_KidsRunningTowardGramps node:  [from Scene_KidsRunningTowardGrampsSequencer.value_changed to set_bind ] -->
                          <Viewpoint DEF='Scene_KidsRunningTowardGramps' centerOfRotation='10 0.8 4' description='Grand Kids Running' orientation='0 1 0 1.5' position='11 1.6 4'/>
118                      </Group>
119                      <Group DEF='CharactersAndCharacterViewpoints'>
120                           <Transform DEF='Gramps'>
121
                              <!-- ROUTE information for GrampsBox node:  [from Gramps_HumanoidRoot_TranslationInterpolator.value_changed to set_translation ] [from Gramps_HumanoidRoot_RotationInterpolator.value_changed to set_rotation ] -->
                               <Transform DEF='GrampsBox' translation='6.6 0 0.5'>
122
                                   <!-- ROUTE information for Gramps01View node:  [from Gramps01ViewSequencer.value_changed to set_bind ] -->
                                    <Viewpoint DEF='Gramps01View' description='Look at Gramps' orientation='-0.25 0 0 0.3' position='0 4 11'/>
123                                     <!-- Viewpoint DEF='Gramps02View' description='Look over Gramps Shoulder' orientation='0 1 0 3' position='-3 2 -9'/ -->
124                                     <!-- PointLight location='0 5 15' global='true' intensity='0.5' / -->
125
                                   <!-- ROUTE information for Gramps03View node:  [from Gramps03ViewSequencer.value_changed to set_bind ] -->
                                    <Viewpoint DEF='Gramps03View' description='Look at Heart over Gramps Shoulder' orientation='0 0.7 0 3' position='-1 2 -8'/>
126
                                   <!-- Inline Gramps11 is a DEF node that has 1 USE node: USE_1 -->
                                    <Inline DEF='Gramps11'   url=' "Gramps11.x3dv" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/Gramps11.x3dv" '/>
127                                     <!-- TODO get proper conversion of Gramps <Inline DEF='GrampsAnimations' "url='GrampsAnimations.x3d" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/GrampsAnimations.x3d" "GrampsAnimations.wrl" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/GrampsAnimations.wrl'/>" -->
128                                     <!-- visual debug assist -->
129
                                   <!-- Inline JointCoordinateAxes is a DEF node that has 1 USE node: USE_1 -->
                                    <Inline DEF='JointCoordinateAxes'   url=' "JointCoordinateAxes.x3dv" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/JointCoordinateAxes.x3d" '/>
130                                     <Transform>
131
                                        <!-- Inline CaneFitting is a DEF node that has 1 USE node: USE_1 -->
                                         <Inline DEF='CaneFitting'   url=' "CaneFitting.x3d" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/CaneFitting.x3d" "CaneFitting.wrl" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/CaneFitting.wrl" '/>
132                                     </Transform>
133                                </Transform>
134                           </Transform>
135                           <Transform DEF='GrampsGrandKids'>
136                                <!-- TODO Viewpoint DEF='GrampsGrandKidsView' description='Look at Gramps GrandKids' orientation='-0.25 0 0 0.3' position='0 4 9'/> -->
137                                <!-- Leif -->
138                                <Transform DEF='Leif'>
139
                                   <!-- ROUTE information for LeifBox node:  [from Leif_Root_TranslationInterpolator.value_changed to set_translation ] [from Leif_HumanoidRoot_RotationInterpolator.value_changed to set_rotation ] -->
                                    <Transform DEF='LeifBox' translation='-7.9962 0.0046 3.000'>
140                                          <!-- PointLight location='0 10 15' global='true' intensity='0.5' / -->
141
                                        <!-- ROUTE information for LeifView node:  [from LeifViewSequencer.value_changed to set_bind ] -->
                                         <Viewpoint DEF='LeifView' description='Look at Leif' orientation='-0.25 0 0 0.5' position='0 2 4'/>
142
                                        <!-- Inline LeifAnimated is a DEF node that has 1 USE node: USE_1 -->
                                         <Inline DEF='LeifAnimated'   url=' "LeifAnimated.x3d" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/LeifAnimated.x3d" "LeifAnimated.wrl" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/LeifAnimated.wrl" '/>
143                                     </Transform>
144                                </Transform>
145                                <!-- Lily -->
146                                <Transform DEF='Lily'>
147
                                   <!-- ROUTE information for LilyBox node:  [from Lily_HumanoidRoot_TranslationInterpolator.value_changed to set_translation ] [from Lily_HumanoidRoot_RotationInterpolator.value_changed to set_rotation ] -->
                                    <Transform DEF='LilyBox' translation='-8.0962 0.0046 5.600'>
148                                          <!-- PointLight location='0 10 15' global='true' intensity='0.5' / -->
149
                                        <!-- ROUTE information for Lilyview node:  [from LilyViewSequencer.value_changed to set_bind ] -->
                                         <Viewpoint DEF='Lilyview' description='Look at Lily' orientation='-0.25 0 0 0.5' position='0 2 4'/>
150
                                        <!-- Inline LilyAnimated is a DEF node that has 1 USE node: USE_1 -->
                                         <Inline DEF='LilyAnimated'   url=' "LilyAnimated.x3d" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/LilyAnimated.x3d" "LilyAnimated.wrl" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/LilyAnimated.wrl" '/>
151                                     </Transform>
152                                </Transform>
153                                <!-- Tufani -->
154                                <Transform DEF='Tufani'>
155
                                   <!-- ROUTE information for TufaniBox node:  [from Tufani_HumanoidRoot_TranslationInterpolator.value_changed to set_translation ] [from Tufani_HumanoidRoot_RotationInterpolator.value_changed to set_rotation ] -->
                                    <Transform DEF='TufaniBox' translation='-8.0962 0.0046 6.400'>
156                                          <!-- PointLight location='0 10 15' global='true' intensity='0.5' / -->
157
                                        <!-- ROUTE information for Tufaniview node:  [from TufaniViewSequencer.value_changed to set_bind ] -->
                                         <Viewpoint DEF='Tufaniview' description='Look at Tufani' orientation='-0.25 0 0 0.5' position='0 2 4'/>
158
                                        <!-- Inline TufaniAnimated is a DEF node that has 1 USE node: USE_1 -->
                                         <Inline DEF='TufaniAnimated'   url=' "TufaniAnimated.x3d" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/TufaniAnimated.x3d" "TufaniAnimated.wrl" "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/TufaniAnimated.wrl" '/>
159                                     </Transform>
160                                </Transform>
161                           </Transform>
162                           <!-- Gramps and GrandKids Translation and Orientation -->
163                           <!-- All other animations are in file for character -->
164
                         <!-- ROUTE information for Gramps_HumanoidRoot_TranslationInterpolator node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to GrampsBox.set_translation ] -->
                          <PositionInterpolator DEF='Gramps_HumanoidRoot_TranslationInterpolator' key='0 0.09 0.11 0.22 0.43 0.55 0.63 0.73 0.85 0.86 0.88 0.90 0.92 0.94 0.96 0.98 1' keyValue='6.6 0 0.5 6.8557 0 0.5 6.8557 0 0.5 9.8557 0 3.5 9.8557 0.1 3.5 9.8557 0 3.5 14.3558 0 8.0 16.8558 0 15.0 21.3557 0 24.5 21.3557 0.05 24.5 21.3557 0 24.5 21.3557 0.05 24.5 21.3557 0 24.5 21.3557 0.05 24.5 21.3557 0 24.5 21.3557 0.1 24.5 21.3557 0 24.5'/>
165
                         <!-- ROUTE information for Gramps_HumanoidRoot_RotationInterpolator node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to GrampsBox.set_rotation ] -->
                          <OrientationInterpolator DEF='Gramps_HumanoidRoot_RotationInterpolator' key='0 0.09 0.11 0.22 0.25 0.43 0.55 0.63 0.73 0.85 0.88 0.90 0.92 0.94 0.96 0.98 1' keyValue='0 1 0 1.65 0 1 0 1.65 0 1 0 1 0 1 0 -0.5 0 1 0 -1 0 1 0 -1.7 0 1 0 1 0 1 0 0.35 0 1 0 0.35 0 1 0 0.35 0 1 0 0.35 0 1 0 0.35 0 1 0 0.35 0 1 0 0.35 0 1 0 0.35 0 1 0 0.36 0 1 0 0.36'/>
166                           < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Gramps_HumanoidRoot_TranslationInterpolator' toField='set_fraction'/>
167                           < ROUTE  fromNode='Gramps_HumanoidRoot_TranslationInterpolator' fromField='value_changed' toNode='GrampsBox' toField='set_translation'/>
168                           < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Gramps_HumanoidRoot_RotationInterpolator' toField='set_fraction'/>
169                           < ROUTE  fromNode='Gramps_HumanoidRoot_RotationInterpolator' fromField='value_changed' toNode='GrampsBox' toField='set_rotation'/>
170
                         <!-- ROUTE information for Leif_Root_TranslationInterpolator node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to LeifBox.set_translation ] -->
                          <PositionInterpolator DEF='Leif_Root_TranslationInterpolator' key='0 0.09 0.11 0.21 0.223 0.43 0.55 0.63 0.73 0.75 0.85 0.9 1' keyValue='-7.9962 0.0046 3.000 -7.9962 0.0046 3.000 -7.9962 0.0046 3.000 -7.9962 0.1046 3.000 -7.9962 0.0046 3.000 9.0038 0.0796 2.4999 11.5048 0.0796 3.4999 16.0038 0.0796 7.8699 18.5038 0.1796 14.8699 18.5038 0.0796 14.8699 23.0038 0.0796 24.3699 23.0038 0.0796 24.3699 23.0038 0.0796 24.3699'/>
171
                         <!-- ROUTE information for Leif_HumanoidRoot_RotationInterpolator node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to LeifBox.set_rotation ] -->
                          <OrientationInterpolator DEF='Leif_HumanoidRoot_RotationInterpolator' key='0 0.05 0.11 0.22 0.25 0.43 0.55 0.63 0.73 0.85 0.88 0.90 0.92 0.94 0.96 0.98 1' keyValue='0 0 1 0 0 1 0 1.6 0 1 0 1.6 0 1 0 1.6 0 1 0 1.6 0 1 0 1.6 0 1 0 1.0 0 1 0 0.5 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3'/>
172                           < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Leif_Root_TranslationInterpolator' toField='set_fraction'/>
173                           < ROUTE  fromNode='Leif_Root_TranslationInterpolator' fromField='value_changed' toNode='LeifBox' toField='set_translation'/>
174                           < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Leif_HumanoidRoot_RotationInterpolator' toField='set_fraction'/>
175                           < ROUTE  fromNode='Leif_HumanoidRoot_RotationInterpolator' fromField='value_changed' toNode='LeifBox' toField='set_rotation'/>
176
                         <!-- ROUTE information for Lily_HumanoidRoot_TranslationInterpolator node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to LilyBox.set_translation ] -->
                          <PositionInterpolator DEF='Lily_HumanoidRoot_TranslationInterpolator' key='0 0.09 0.11 0.225 0.43 0.55 0.63 0.73 0.85 0.86 1' keyValue='-8.0962 0.0046 5.600 -8.0962 0.0046 5.600 -8.0962 0.0046 5.600 -8.0962 0.0046 5.600 8.9038 0.0796 3.0999 10.1538 0.0796 3.0999 15.1538 0.0796 7.8499 17.6538 0.0796 14.8499 22.1538 0.0796 24.3499 22.1538 0.0796 24.3499 22.1538 0.0796 24.3499'/>
177
                         <!-- ROUTE information for Lily_HumanoidRoot_RotationInterpolator node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to LilyBox.set_rotation ] -->
                          <OrientationInterpolator DEF='Lily_HumanoidRoot_RotationInterpolator' key='0 0.07 0.11 0.22 0.25 0.43 0.55 0.63 0.73 0.85 0.88 0.90 0.92 0.94 0.96 0.98 1' keyValue='0 0 1 0 0 1 0 1.6 0 1 0 1.6 0 1 0 1.6 0 1 0 1.6 0 1 0 1.6 0 1 0 1.0 0 1 0 0.5 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3'/>
178                           < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Lily_HumanoidRoot_TranslationInterpolator' toField='set_fraction'/>
179                           < ROUTE  fromNode='Lily_HumanoidRoot_TranslationInterpolator' fromField='value_changed' toNode='LilyBox' toField='set_translation'/>
180                           < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Lily_HumanoidRoot_RotationInterpolator' toField='set_fraction'/>
181                           < ROUTE  fromNode='Lily_HumanoidRoot_RotationInterpolator' fromField='value_changed' toNode='LilyBox' toField='set_rotation'/>
182
                         <!-- ROUTE information for Tufani_HumanoidRoot_TranslationInterpolator node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to TufaniBox.set_translation ] -->
                          <PositionInterpolator DEF='Tufani_HumanoidRoot_TranslationInterpolator' key='0 0.09 0.11 0.227 0.43 0.55 0.63 0.73 0.85 0.86 1' keyValue='-8.0962 0.0046 6.400 -8.0962 0.0046 6.400 -8.0962 0.0046 6.400 -8.0962 0.0046 6.400 8.7038 0.0796 3.8999 9.2038 0.0796 3.6499 13.6538 0.0796 7.7699 16.1538 0.0796 14.7699 20.6538 0.0796 24.2699 20.6538 0.0796 24.2699 20.6538 0.0796 24.2699'/>
183
                         <!-- ROUTE information for Tufani_HumanoidRoot_RotationInterpolator node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to TufaniBox.set_rotation ] -->
                          <OrientationInterpolator DEF='Tufani_HumanoidRoot_RotationInterpolator' key='0 0.09 0.11 0.22 0.25 0.43 0.55 0.63 0.73 0.85 0.88 0.90 0.92 0.94 0.96 0.98 1' keyValue='0 0 1 0 0 1 0 1.6 0 1 0 1.6 0 1 0 1.6 0 1 0 1.6 0 1 0 1.6 0 1 0 1.0 0 1 0 0.5 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3 0 1 0 0.3'/>
184                           < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Tufani_HumanoidRoot_TranslationInterpolator' toField='set_fraction'/>
185                           < ROUTE  fromNode='Tufani_HumanoidRoot_TranslationInterpolator' fromField='value_changed' toNode='TufaniBox' toField='set_translation'/>
186                           < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Tufani_HumanoidRoot_RotationInterpolator' toField='set_fraction'/>
187                           < ROUTE  fromNode='Tufani_HumanoidRoot_RotationInterpolator' fromField='value_changed' toNode='TufaniBox' toField='set_rotation'/>
188                      </Group>
189                      <Group DEF='SceneViewPoints02'>
190                           <!-- Insert other PageDown viewpoints before final titles -->
191                           <Transform DEF='WSDedicationTitle' translation='10 10 -10'>
192
                              <!-- ROUTE information for WSDedicationTitleView node:  [from WSDedicationTitleViewSequencer.value_changed to set_bind ] -->
                               <Viewpoint DEF='WSDedicationTitleView' description='Look at Dedication title' jump='false' orientation='-0.15 0 0 0.2' position='0 1 5'/>
193                                <Shape>
194                                     <Box size='4 3 0.25'/>
195                                     <Appearance>
196                                          <ImageTexture   url=' "images/WSDedicationR1.png " "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/images/WSDedicationR1.png " '/>
197                                          <Material/>
198                                     </Appearance>
199                                </Shape>
200                           </Transform>
201                           <Transform DEF='WSThanksTitle' translation='10 10 -15'>
202
                              <!-- ROUTE information for WSThanksTitleView node:  [from WSThanksTitleViewSequencer.value_changed to set_bind ] -->
                               <Viewpoint DEF='WSThanksTitleView' description='Look at Thanks title' jump='false' orientation='-0.15 0 0 0.2' position='0 1 5'/>
203                                <Shape>
204                                     <Box size='4 3 0.25'/>
205                                     <Appearance>
206                                          <ImageTexture   url=' "images/WSThanksR2trimmed.png " "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/images/WSThanksR2trimmed.png " '/>
207                                          <Material/>
208                                     </Appearance>
209                                </Shape>
210                           </Transform>
211                           <Transform DEF='WSMusicCreditsTitle' translation='10 10 -20'>
212
                              <!-- ROUTE information for WSMusicCreditsTitleView node:  [from WSMusicCreditsTitleViewSequencer.value_changed to set_bind ] -->
                               <Viewpoint DEF='WSMusicCreditsTitleView' description='Look at Music Credits title' jump='false' orientation='-0.15 0 0 0.2' position='0 1 5'/>
213                                <Shape>
214                                     <Box size='4 3 0.25'/>
215                                     <Appearance>
216                                          <ImageTexture   url=' "images/WSMusicCreditAll.png " "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/images/WSMusicCreditAll.png " '/>
217                                          <Material/>
218                                     </Appearance>
219                                </Shape>
220                           </Transform>
221                      </Group>
222                 </Group>
223            </Group>
224            <!-- Sequencers for Viewpoints -->
225
          <!-- ROUTE information for Scene_StageFarViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Scene_StageFarView.set_bind ] -->
           <BooleanSequencer DEF='Scene_StageFarViewSequencer' key='0 1' keyValue='true false'/>
226            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Scene_StageFarViewSequencer' toField='set_fraction'/>
227            < ROUTE  fromNode='Scene_StageFarViewSequencer' fromField='value_changed' toNode='Scene_StageFarView' toField='set_bind'/>
228
          <!-- ROUTE information for WinterAndSpringTitleViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to WinterAndSpringTitleView.set_bind ] -->
           <BooleanSequencer DEF='WinterAndSpringTitleViewSequencer' key='0 0.03 1' keyValue='false true false'/>
229            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='WinterAndSpringTitleViewSequencer' toField='set_fraction'/>
230            < ROUTE  fromNode='WinterAndSpringTitleViewSequencer' fromField='value_changed' toNode='WinterAndSpringTitleView' toField='set_bind'/>
231
          <!-- ROUTE information for WSAuthorsTitleViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to WSAuthorsTitleView.set_bind ] -->
           <BooleanSequencer DEF='WSAuthorsTitleViewSequencer' key='0 0.06 1' keyValue='false true false'/>
232            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='WSAuthorsTitleViewSequencer' toField='set_fraction'/>
233            < ROUTE  fromNode='WSAuthorsTitleViewSequencer' fromField='value_changed' toNode='WSAuthorsTitleView' toField='set_bind'/>
234
          <!-- ROUTE information for Scene_GrampsBack1ViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Scene_GrampsBack1View.set_bind ] -->
           <BooleanSequencer DEF='Scene_GrampsBack1ViewSequencer' key='0 0.09 1' keyValue='false true false'/>
235            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Scene_GrampsBack1ViewSequencer' toField='set_fraction'/>
236            < ROUTE  fromNode='Scene_GrampsBack1ViewSequencer' fromField='value_changed' toNode='Scene_GrampsBack1View' toField='set_bind'/>
237
          <!-- ROUTE information for Scene_KidsRunningTowardGrampsSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Scene_KidsRunningTowardGramps.set_bind ] -->
           <BooleanSequencer DEF='Scene_KidsRunningTowardGrampsSequencer' key='0 0.23 1' keyValue='false true false'/>
238            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Scene_KidsRunningTowardGrampsSequencer' toField='set_fraction'/>
239            < ROUTE  fromNode='Scene_KidsRunningTowardGrampsSequencer' fromField='value_changed' toNode='Scene_KidsRunningTowardGramps' toField='set_bind'/>
240
          <!-- ROUTE information for LeifViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to LeifView.set_bind ] -->
           <BooleanSequencer DEF='LeifViewSequencer' key='0 0.30 1' keyValue='false false false'/>
241            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='LeifViewSequencer' toField='set_fraction'/>
242            < ROUTE  fromNode='LeifViewSequencer' fromField='value_changed' toNode='LeifView' toField='set_bind'/>
243
          <!-- ROUTE information for LilyViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Lilyview.set_bind ] -->
           <BooleanSequencer DEF='LilyViewSequencer' key='0 0.33 1' keyValue='false true false'/>
244            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='LilyViewSequencer' toField='set_fraction'/>
245            < ROUTE  fromNode='LilyViewSequencer' fromField='value_changed' toNode='Lilyview' toField='set_bind'/>
246
          <!-- ROUTE information for TufaniViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Tufaniview.set_bind ] -->
           <BooleanSequencer DEF='TufaniViewSequencer' key='0 0.36 1' keyValue='false false false'/>
247            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='TufaniViewSequencer' toField='set_fraction'/>
248            < ROUTE  fromNode='TufaniViewSequencer' fromField='value_changed' toNode='Tufaniview' toField='set_bind'/>
249
          <!-- ROUTE information for Gramps01ViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Gramps01View.set_bind ] -->
           <BooleanSequencer DEF='Gramps01ViewSequencer' key='0 0.56 1' keyValue='false true false'/>
250            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Gramps01ViewSequencer' toField='set_fraction'/>
251            < ROUTE  fromNode='Gramps01ViewSequencer' fromField='value_changed' toNode='Gramps01View' toField='set_bind'/>
252
          <!-- ROUTE information for Gramps03ViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Gramps03View.set_bind ] -->
           <BooleanSequencer DEF='Gramps03ViewSequencer' key='0 0.75 1' keyValue='false true true'/>
253            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Gramps03ViewSequencer' toField='set_fraction'/>
254            < ROUTE  fromNode='Gramps03ViewSequencer' fromField='value_changed' toNode='Gramps03View' toField='set_bind'/>
255
          <!-- ROUTE information for WSDedicationTitleViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to WSDedicationTitleView.set_bind ] -->
           <BooleanSequencer DEF='WSDedicationTitleViewSequencer' key='0 0.89 1' keyValue='false true false'/>
256            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='WSDedicationTitleViewSequencer' toField='set_fraction'/>
257            < ROUTE  fromNode='WSDedicationTitleViewSequencer' fromField='value_changed' toNode='WSDedicationTitleView' toField='set_bind'/>
258
          <!-- ROUTE information for WSThanksTitleViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to WSThanksTitleView.set_bind ] -->
           <BooleanSequencer DEF='WSThanksTitleViewSequencer' key='0 0.93 1' keyValue='false true false'/>
259            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='WSThanksTitleViewSequencer' toField='set_fraction'/>
260            < ROUTE  fromNode='WSThanksTitleViewSequencer' fromField='value_changed' toNode='WSThanksTitleView' toField='set_bind'/>
261
          <!-- ROUTE information for WSMusicCreditsTitleViewSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to WSMusicCreditsTitleView.set_bind ] -->
           <BooleanSequencer DEF='WSMusicCreditsTitleViewSequencer' key='0 0.96 1' keyValue='false true false'/>
262            < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='WSMusicCreditsTitleViewSequencer' toField='set_fraction'/>
263            < ROUTE  fromNode='WSMusicCreditsTitleViewSequencer' fromField='value_changed' toNode='WSMusicCreditsTitleView' toField='set_bind'/>
264            <Group DEF='BackgroundsAndBackgroundSwitching'>
265                 <!-- Backgrounds -->
266                 <!-- This is black for all -->
267
               <!-- ROUTE information for Background1Black node:  [from Background1BlackSequencer.value_changed to set_bind ] -->
                <Background DEF='Background1Black' groundColor='0 0 0'/>
268                 <!-- This is light gray sky and green grass -->
269
               <!-- ROUTE information for Background2GraySkyGreenGrass node:  [from Background2GraySkyGreenGrassSequencer.value_changed to set_bind ] -->
                <Background DEF='Background2GraySkyGreenGrass' groundAngle='1.57' groundColor='0.956 0.639 0 0.721 1 0.501' skyColor='0.827 0.827 0.827'   backUrl=' "images/SCENE_FOG_1.png " "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/images/SCENE_FOG_1.png " '   frontUrl=' "images/SCENE_FOG_1.png " "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/images/SCENE_FOG_1.png " '   leftUrl=' "images/SCENE_FOG_1.png " "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/images/SCENE_FOG_1.png " '   rightUrl=' "images/SCENE_FOG_1.png " "https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/images/SCENE_FOG_1.png " '/>
270                 <!-- This is blue sky and green grass -->
271
               <!-- ROUTE information for Background3BlueSkyGreenGrass node:  [from Background3SkyBlueGreenGrassSequencer.value_changed to set_bind ] -->
                <Background DEF='Background3BlueSkyGreenGrass' groundAngle='1.57' groundColor='0.356 0.639 0 0.721 1 0.501' skyColor='0 0.71 0.886'/>
272                 <!-- This is DarkGrey background and white text for all -->
273
               <!-- ROUTE information for Background4DarkGrey node:  [from Background4DarkGreySequencer.value_changed to set_bind ] -->
                <Background DEF='Background4DarkGrey' skyColor='0.6 0.6 0.6'/>
274
               <!-- ROUTE information for Background1BlackSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Background1Black.set_bind ] -->
                <BooleanSequencer DEF='Background1BlackSequencer' key='0 0.90 1' keyValue='true true true'/>
275
               <!-- ROUTE information for Background2GraySkyGreenGrassSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Background2GraySkyGreenGrass.set_bind ] -->
                <BooleanSequencer DEF='Background2GraySkyGreenGrassSequencer' key='0 0.09 1' keyValue='false true false'/>
276
               <!-- ROUTE information for Background3SkyBlueGreenGrassSequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Background3BlueSkyGreenGrass.set_bind ] -->
                <BooleanSequencer DEF='Background3SkyBlueGreenGrassSequencer' key='0 0.22 1' keyValue='false true false'/>
277
               <!-- ROUTE information for Background4DarkGreySequencer node:  [from Clock100Seconds.fraction_changed to set_fraction ] [from value_changed to Background4DarkGrey.set_bind ] -->
                <BooleanSequencer DEF='Background4DarkGreySequencer' key='0 0.85 1' keyValue='false true false'/>
278                 < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Background1BlackSequencer' toField='set_fraction'/>
279                 < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Background2GraySkyGreenGrassSequencer' toField='set_fraction'/>
280                 < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Background3SkyBlueGreenGrassSequencer' toField='set_fraction'/>
281                 < ROUTE  fromNode='Clock100Seconds' fromField='fraction_changed' toNode='Background4DarkGreySequencer' toField='set_fraction'/>
282                 < ROUTE  fromNode='Background1BlackSequencer' fromField='value_changed' toNode='Background1Black' toField='set_bind'/>
283                 < ROUTE  fromNode='Background2GraySkyGreenGrassSequencer' fromField='value_changed' toNode='Background2GraySkyGreenGrass' toField='set_bind'/>
284                 < ROUTE  fromNode='Background3SkyBlueGreenGrassSequencer' fromField='value_changed' toNode='Background3BlueSkyGreenGrass' toField='set_bind'/>
285                 < ROUTE  fromNode='Background4DarkGreySequencer' fromField='value_changed' toNode='Background4DarkGrey' toField='set_bind'/>
286            </Group>
287
          <!-- ROUTE information for EveryInlineLoadSensor node:  [from loadTime to StartTIME.startTime ] -->
           <LoadSensor DEF='EveryInlineLoadSensor'>
288                 <Inline USE='PathMeshTopSurface'/>
289                 <Inline USE='Pathway'/>
290                 <Inline USE='Bushes'/>
291                 <Inline USE='FlowerSet'/>
292                 <Inline USE='FlowerGardens'/>
293                 <Inline USE='Gramps11'/>
294                 <Inline USE='JointCoordinateAxes'/>
295                 <Inline USE='CaneFitting'/>
296                 <Inline USE='LeifAnimated'/>
297                 <Inline USE='LilyAnimated'/>
298                 <Inline USE='TufaniAnimated'/>
299            </LoadSensor>
300            < ROUTE  fromNode='EveryInlineLoadSensor' fromField='loadTime' toNode='StartTIME' toField='startTime'/>
301       </Scene>
302  </X3D>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->
<!-- to top DEF nodes index: Background1Black, Background1BlackSequencer, Background2GraySkyGreenGrass, Background2GraySkyGreenGrassSequencer, Background3BlueSkyGreenGrass, Background3SkyBlueGreenGrassSequencer, Background4DarkGrey, Background4DarkGreySequencer, BackgroundsAndBackgroundSwitching, BorderFlowers, Bushes, BushesTransform, CaneFitting, CharactersAndCharacterViewpoints, Clock100Seconds, Clock100SecondsTRIGGER, DelayFILTER, DelayTIME, EveryInlineLoadSensor, Floor, FlowerGardens, FlowerSet, Gramps, Gramps_HumanoidRoot_RotationInterpolator, Gramps_HumanoidRoot_TranslationInterpolator, Gramps01View, Gramps01ViewSequencer, Gramps03View, Gramps03ViewSequencer, Gramps11, GrampsBox, GrampsGrandKids, GrampsStage, JointCoordinateAxes, Leif, Leif_HumanoidRoot_RotationInterpolator, Leif_Root_TranslationInterpolator, LeifAnimated, LeifBox, LeifView, LeifViewSequencer, Lily, Lily_HumanoidRoot_RotationInterpolator, Lily_HumanoidRoot_TranslationInterpolator, LilyAnimated, LilyBox, Lilyview, LilyViewSequencer, Melodies1, PathMeshTopSurface, Pathway, PathwayGrid, PathwaySurface1, PathwaySurface2, Scene_GrampsBack1View, Scene_GrampsBack1ViewSequencer, Scene_KidsRunningTowardGramps, Scene_KidsRunningTowardGrampsSequencer, Scene_StageFarView, Scene_StageFarViewSequencer, SceneMusic1, SceneViewpoints01, SceneViewPoints02, StageDecorations, StageSurface, StartTIME, TitlesandViewpointsInOrderofAppearance, TitleSet1, TitleSet1of2, Tufani, Tufani_HumanoidRoot_RotationInterpolator, Tufani_HumanoidRoot_TranslationInterpolator, TufaniAnimated, TufaniBox, Tufaniview, TufaniViewSequencer, TwoFlowerGardens, WinterAndSpringTitle, WinterAndSpringTitleView, WinterAndSpringTitleViewSequencer, WSAudio, WSAuthorsTitle, WSAuthorsTitleView, WSAuthorsTitleViewSequencer, WSDedicationTitle, WSDedicationTitleView, WSDedicationTitleViewSequencer, WSMusicCreditsTitle, WSMusicCreditsTitleView, WSMusicCreditsTitleViewSequencer, WSThanksTitle, WSThanksTitleView, WSThanksTitleViewSequencer

Index for Viewpoint nodes: Gramps01View, Gramps03View, LeifView, Lilyview, Scene_GrampsBack1View, Scene_KidsRunningTowardGramps, Scene_StageFarView, Tufaniview, WinterAndSpringTitleView, WSAuthorsTitleView, WSDedicationTitleView, WSMusicCreditsTitleView, WSThanksTitleView
-->
X3D Tooltips element index: Appearance, AudioClip, Background, BooleanFilter, BooleanSequencer, Box, component, DirectionalLight, Group, head, ImageTexture, Inline, LoadSensor, Material, meta, NavigationInfo, OrientationInterpolator, PositionInterpolator, ROUTE, Scene, Shape, Sound, TimeSensor, TimeTrigger, Transform, Viewpoint, WorldInfo, X3D, plus documentation for accessType definitions, type definitions, XML data types, and field types

Event Graph ROUTE Table entries with 57 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

EveryInlineLoadSensor
LoadSensor
loadTime
SFTime
→
ROUTE
event to
(1)
StartTIME
TimeSensor
startTime
SFTime 		then


  		StartTIME
TimeSensor
stopTime
SFTime
→
ROUTE
event to
(2)
DelayTIME
TimeSensor
set_startTime
SFTime 		then


  		DelayTIME
TimeSensor
isActive
SFBool
→
ROUTE
event to
(3)
DelayFILTER
BooleanFilter
set_boolean
SFBool 		then


  		DelayFILTER
BooleanFilter
inputFalse
SFBool
→
ROUTE
event to
(4)
Clock100SecondsTRIGGER
TimeTrigger
set_boolean
SFBool 		then


  		Clock100SecondsTRIGGER
TimeTrigger
triggerTime
SFTime
→
ROUTE
event to
(5)
Clock100Seconds
TimeSensor
set_startTime
SFTime
  then


  		StartTIME
TimeSensor
stopTime
SFTime
→
ROUTE
event to
(2)
Melodies1
AudioClip
set_startTime
SFTime


Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀
-->
<!-- Online at
https://www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/MainStageIndex.html -->
<!-- Version control at
https://sourceforge.net/p/x3d/code/HEAD/tree/www.web3d.org/x3d/content/examples/HumanoidAnimation/WinterAndSpring/MainStage.x3d -->

<!-- Color-coding legend: X3D terminology <X3dNode  DEF='idName' field='value'/> matches XML terminology <XmlElement  DEF='idName' attribute='value'/>
(Light-blue background: event-based behavior node or statement) (Grey background inside box: inserted documentation) (Magenta background: X3D Extensibility)
-->

to top <!-- For additional help information about X3D scenes, please see X3D Tooltips, X3D Resources, and X3D Scene Authoring Hints. -->
