<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "http://www.web3d.org/specifications/x3d-3.0.dtd">
<X3D profile='Interactive' version='3.0 xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation =' http://www.web3d.org/specifications/x3d-3.0.xsd '>
<head>
<meta name='titlecontent='test_red_on_blue.x3d'/>
<meta name='Imagecontent='test-red-on-blue-front.jpg'/>
<meta name='referencecontent=' http://www.nist.gov/vrml.html '/>
<meta name='referencecontent=' http://www.itl.nist.gov/div897/ctg/vrml/vrml.html '/>
<meta name='creatorcontent=' http://www.itl.nist.gov/div897/ctg/vrml/members.html '/>
<meta name='disclaimercontent=' This file was provided by the National Institute of Standards and Technology, and is part of the X3D Conformance Test Suite, available at http://www.nist.gov/vrml.html The information contained within this file is provided for use in establishing conformance to the ISO VRML97 Specification. Conformance to this test does not imply recommendation or endorsement by the National Institute of Standards and Technology. This software can be redistributed and/or modified freely provided that any derivative works bear some notice that they are derived from it, and any modified versions bear some notice that they have been modified. '/>
<meta name='infocontent='Correct definition and compliance of this conformance scene is maintained by the X3D Working Group, http://www.web3d.org/working-groups/x3d'/>
<meta name='translatorcontent='Michael Kass NIST, Don Brutzman NPS'/>
<meta name='translatedcontent='21 January 2001'/>
<meta name='modifiedcontent='15 April 2017'/>
<meta name='descriptioncontent='This test addresses the ability of a browser to apply a red light on a blue object. Four simple geometries are defined on the local coordinate system and the emissive and diffuse color are both set to 0 0 1. A point light is also defined and a red color is associated with it. This light illuminates the objects making them look black. The dot product of the light and object color produce a black appearing object.'/>
<meta name='identifiercontent=' http://www.web3d.org/x3d/content/examples/ConformanceNist/Lights/PointLight/test_red_on_blue.x3d '/>
<meta name='generatorcontent='Vrml97ToX3dNist, http://ovrt.nist.gov/v2_x3d.html'/>
<meta name='generatorcontent='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
<meta name='licensecontent=' ../../license.html'/>
</head>
<!--

Index for Viewpoint image : Viewpoint_1
-->
<Scene>
<Group>
<Viewpoint description='Front Viewposition='0 0 15'/>
</Group>
<Background groundColor='0 0 0skyColor='1 1 1'/>
<NavigationInfo headlight='falsetype='"EXAMINE" "WALK" "FLY" "ANY"'/>
<DirectionalLight on='false'/>
<SpotLight beamWidth='1.570796cutOffAngle='.785398on='false'/>
<PointLight color='1 0 0location='0 0 10'/>
<Transform translation='6.14221 0.0694613 -0.000999451'>
<Shape>
<Appearance>
<Material diffuseColor='0 0 1'/>
</Appearance>
<Box/>
</Shape>
</Transform>
<Transform translation='-4.85443 0.0694381 -0.00149918'>
<Shape>
<Appearance>
<Material diffuseColor='0 0 1'/>
</Appearance>
<Sphere/>
</Shape>
</Transform>
<Transform translation='-1.47341 0.036672 -0.00175095'>
<Shape>
<Appearance>
<Material diffuseColor='0 0 1'/>
</Appearance>
<Cone/>
</Shape>
</Transform>
<Transform translation='2.31094 0.0694206 -0.00187683'>
<Shape>
<Appearance>
<Material diffuseColor='0 0 1'/>
</Appearance>
<Cylinder/>
</Shape>
</Transform>
</Scene>
</X3D>
<!--

Index for Viewpoint image : Viewpoint_1
-->
