ElevationGrid is a geometry node defining a rectangular height field, with default values for a 1m by 1m square at height 0. Vertices corresponding to ElevationGrid height values define quadrilaterals, which are placed above or below a flat surface. Hint: the height array defines (xDimension-1)*(zDimension-1) quadrilaterals.

X3D Tooltips of interest: ElevationGrid.

X3D Specification sections of interest: 13 Geometry3D component, 13.2 Concepts and 13.3.4 ElevationGrid.

X3D Examples Archives of related interest:

VRML 2 Sourcebook: Chapter 14 Elevation Grid
X3D for Web Authors: Chapter 06 Geometry Points Lines Polygons
