X3D Model Documentation: Room.x3d go to online X3D Example Archives model page

  1  <?xml version="1.0" encoding="UTF-8"?>
  2
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">
  3  <X3D profile='Immersive' version='3.0'  xmlns:xsd='https://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
  4       <head>
  5            <meta name='title' content=' Room.x3d '/>
  6            <meta name='description' content='A simple room containing protoype instances for chair, desk lamp, wall clock, etc.'/>
  7            <meta name='creator' content='Frederic Roussille'/>
  8            <meta name='created' content='1 April 2001'/>
  9            <meta name='modified' content='20 October 2019'/>
 10            <meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Room.x3d '/>
 11            <meta name='generator' content='X3D-Edit 3.3, https://www.web3d.org/x3d/tools/X3D-Edit'/>
 12            <meta name='license' content='../license.html'/>
 13       </head>
<!--

Event Graph ROUTE Table shows event connections.

--> <!-- to top DEF nodes index: clock, grinding_door, open_door, open_door_js, touch_door, transform_door, wall, wallpaper

Index for Viewpoint node: Viewpoint_1

Index for ExternProtoDeclare definitions: Chair, Desk, WallLamp

-->
 14       <Scene>
 15            <!-- externprodeclare : chair -->
 16            <WorldInfo title='Room.x3d'/>
 17  go to online X3D Example Archives model page           <ExternProtoDeclare name='Chair'   url=' "Chair.x3d#Chair" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Chair.x3d#Chair" "Chair.wrl#Chair" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Chair.wrl#Chair"'>
 18                 <field name='diffuseColor' type='SFColor' accessType='inputOutput'/>
 19            </ExternProtoDeclare>
 20  go to online X3D Example Archives model page           <ExternProtoDeclare name='Desk'   url=' "Desk.x3d#Desk" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Desk.x3d#Desk" "Desk.wrl#Desk" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Desk.wrl#Desk"'>
 21                 <field name='diffuseColor' type='SFColor' accessType='inputOutput'/>
 22            </ExternProtoDeclare>
 23  go to online X3D Example Archives model page           <ExternProtoDeclare name='WallLamp'   url=' "WallLamp.x3d#WallLamp" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/WallLamp.x3d#WallLamp" "WallLamp.wrl#WallLamp" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/WallLamp.wrl#WallLamp"'>
 24                 <field name='lampColor' type='SFColor' accessType='inputOutput'/>
 25                 <field name='lightColor' type='SFColor' accessType='inputOutput'/>
 26                 <field name='lightIntensity' type='SFFloat' accessType='inputOutput'/>
 27                 <field name='lightAttenuation' type='SFVec3f' accessType='inputOutput'/>
 28                 <field name='radius' type='SFFloat' accessType='inputOutput'/>
 29                 <field name='lightLocation' type='SFVec3f' accessType='inputOutput'/>
 30            </ExternProtoDeclare>
 31            <NavigationInfo headlight='false'/>
 32            <Viewpoint description='entry' orientation='1 0 0 -0.2' position='16 23 75'/>
 33            <Transform scale='0.4 0.4 0.6'>
 34                 <Group>
 35                      <!-- floor -->
 36
                    <!-- Shape wall is a DEF node that has 3 USE nodes: USE_1, USE_2, USE_3 -->
                     <Shape DEF='wall'>
 37                           <ElevationGrid solid='false' xDimension='9' xSpacing='10' zDimension='9' zSpacing='10' height='0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0'/>
 38
                         <!-- Appearance wallpaper is a DEF node that has 1 USE node: USE_1 -->
                          <Appearance DEF='wallpaper'>
 39                                <ImageTexture   url=' "WallPaper.jpg"image preview "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/WallPaper.jpg"image preview '/>
 40                                <TextureTransform scale='2 2'/>
 41                                <Material/>
 42                           </Appearance>
 43                      </Shape>
 44                      <!-- left wall -->
 45                      <Transform rotation='0 0 1 1.57'>
 46                           <Shape USE='wall'/>
 47                      </Transform>
 48                      <!-- right wall -->
 49                      <Transform rotation='0 0 1 1.57' translation='80 0 0'>
 50                           <Shape USE='wall'/>
 51                      </Transform>
 52                      <!-- top -->
 53                      <Transform translation='0 80 0'>
 54                           <Shape USE='wall'/>
 55                      </Transform>
 56                      <!-- front wall -->
 57                      <Transform rotation='1 0 0 1.57'>
 58                           <Shape>
 59                                <Appearance USE='wallpaper'/>
 60                                <IndexedFaceSet solid='false' coordIndex='0 1 2 7 -1 2 3 6 7 -1 4 5 6 3 -1'>
 61                                     <Coordinate point='0 0 0 25 0 0 25 0 -45 55 0 -45 55 0 0 80 0 0 80 0 -80 0 0 -80'/>
 62                                </IndexedFaceSet>
 63                           </Shape>
 64                      </Transform>
 65                      <!-- door with its interpalotors and sensors -->
 66
                    <!-- ROUTE information for transform_door node:  [from open_door.value_changed to set_rotation ] -->
                     <Transform DEF='transform_door' center='25 0 0'>
 67                           <Transform translation='40 22.5 0'>
 68                                <Shape>
 69                                     <Appearance>
 70                                          <ImageTexture   url=' "Door.jpg"image preview "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/Door.jpg"image preview '/>
 71                                     </Appearance>
 72                                     <Box size='30 44.5 2'/>
 73                                </Shape>
 74
                              <!-- ROUTE information for touch_door node:  [from touchTime to clock.startTime ] [from touchTime to open_door_js.set_open ] [from touchTime to grinding_door.startTime ] -->
                               <TouchSensor DEF='touch_door' description='touch door to open/close'/>
 75                           </Transform>
 76
                         <!-- ROUTE information for open_door_js node:  [from touch_door.touchTime to set_open ] [from keyValue_changed to open_door.set_keyValue ] -->
                          <Script DEF='open_door_js'>
 77                                <field name='set_open' type='SFTime' accessType='inputOnly'/>
 78                                <field name='keyValue_changed' type='MFRotation' accessType='outputOnly'/>
 79                                <field name='open' type='SFBool' value='false' accessType='initializeOnly'/>
  <![CDATA[

ecmascript:

function set_open() {
    keyValue_changed[0][0] = 0;
    keyValue_changed[0][1] = 1;
    keyValue_changed[0][2] = 0;
    keyValue_changed[1][0] = 0;
    keyValue_changed[1][1] = 1;
    keyValue_changed[1][2] = 0;
    keyValue_changed[1][3] = -0.754;
    keyValue_changed[2][0] = 0;
    keyValue_changed[2][1] = 1;
    keyValue_changed[2][2] = 0;

  if(open == false) {
    keyValue_changed[0][3] = 0;
    keyValue_changed[2][3] = -1.57;
    open = true;
  } else {
      if(open == true) {
         keyValue_changed[0][3] = -1.57;
         keyValue_changed[2][3] = 0;
         open = false;
      }
   }
}
]]>
 81                           </Script>
 82
                         <!-- ROUTE information for clock node:  [from touch_door.touchTime to startTime ] [from fraction_changed to open_door.set_fraction ] -->
                          <TimeSensor DEF='clock' cycleInterval='4.5' enabled='true' loop='false'/>
 83
                         <!-- ROUTE information for open_door node:  [from open_door_js.keyValue_changed to set_keyValue ] [from clock.fraction_changed to set_fraction ] [from value_changed to transform_door.set_rotation ] -->
                          <OrientationInterpolator DEF='open_door' key='0 0.5 1' keyValue='0 1 0 0 0 1 0 0 0 1 0 0'/>
 84                      </Transform>
 85                      <!-- link to nps site -->
 86                      <Anchor description='link to NPS web page'   url=' "https://www.nps.edu"'>
 87                           <Transform translation='40 22.5 -20'>
 88                                <Shape>
 89                                     <Appearance>
 90                                          <Material diffuseColor='0 0 0'/>
 91                                     </Appearance>
 92                                     <Box size='30 44.5 1'/>
 93                                </Shape>
 94                           </Transform>
 95                      </Anchor>
 96                 </Group>
 97                 <!-- Door sound -->
 98                 <Sound direction='0 1 1' location='40 0 0' maxBack='150' maxFront='150'>
 99
                    <!-- ROUTE information for grinding_door node:  [from touch_door.touchTime to startTime ] -->
                     <AudioClip DEF='grinding_door' description='GrindingDoor'   url='
"GrindingDoor.wav"
"https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/GrindingDoor.wav"'/>
100                 </Sound>
101            </Transform>
102            <!-- chair inserted -->
103            <Transform scale='1.5 1.5 1.5' translation='10 5.3 35'>
104                 <ProtoInstance name='Chair'>
105                      <fieldValue name='diffuseColor' value='0 0.3 0.7'/>
106                 </ProtoInstance>
107            </Transform>
108            <!-- desk inserted -->
109            <Transform rotation='0 1 0 -0.754' scale='0.8 0.8 0.7' translation='18 8.1 28'>
110                 <ProtoInstance name='Desk'/>
111            </Transform>
112            <!-- left wall_lamp -->
113            <Transform rotation='0 1 0 1.57' scale='2 2 2' translation='0.05 23 20'>
114                 <ProtoInstance name='WallLamp'>
115                      <fieldValue name='lampColor' value='0 0 1'/>
116                      <fieldValue name='lightColor' value='1 1 1'/>
117                      <fieldValue name='lightIntensity' value='0.8'/>
118                      <fieldValue name='lightAttenuation' value='0 0 0'/>
119                      <fieldValue name='radius' value='100'/>
120                      <fieldValue name='lightLocation' value='0 0 5'/>
121                 </ProtoInstance>
122            </Transform>
123            <!-- right wall_lamp -->
124            <Transform rotation='0 1 0 -1.57' scale='2 2 2' translation='31.99 23 20'>
125                 <ProtoInstance name='WallLamp'>
126                      <fieldValue name='lampColor' value='0 0 1'/>
127                      <fieldValue name='lightColor' value='1 1 1'/>
128                      <fieldValue name='lightIntensity' value='0.8'/>
129                      <fieldValue name='lightAttenuation' value='0 0 0'/>
130                      <fieldValue name='radius' value='100'/>
131                      <fieldValue name='lightLocation' value='0 0 -5'/>
132                 </ProtoInstance>
133            </Transform>
134            <!-- clock inserted on the wall -->
135            <Transform translation='16 22.5 0'>
136  go to online X3D Example Archives model page                <Inline   url=' "WallClock.x3d" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/WallClock.x3d" "WallClock.wrl" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/WallClock.wrl"'/>
137            </Transform>
138            <!-- desk lamp inserted in the scene -->
139            <Transform scale='15 15 15' translation='16 8.6 25'>
140  go to online X3D Example Archives model page                <Inline   url=' "DeskLamp.x3d" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/DeskLamp.x3d" "DeskLamp.wrl" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/DeskLamp.wrl"'/>
141            </Transform>
142            <!-- routes for the door -->
143            < ROUTE  fromNode='touch_door' fromField='touchTime' toNode='clock' toField='startTime'/>
144            < ROUTE  fromNode='touch_door' fromField='touchTime' toNode='open_door_js' toField='set_open'/>
145            < ROUTE  fromNode='touch_door' fromField='touchTime' toNode='grinding_door' toField='startTime'/>
146            < ROUTE  fromNode='open_door_js' fromField='keyValue_changed' toNode='open_door' toField='set_keyValue'/>
147            < ROUTE  fromNode='clock' fromField='fraction_changed' toNode='open_door' toField='set_fraction'/>
148            < ROUTE  fromNode='open_door' fromField='value_changed' toNode='transform_door' toField='set_rotation'/>
149       </Scene>
150  </X3D>
<!--

Event Graph ROUTE Table shows event connections.

--> <!-- to top DEF nodes index: clock, grinding_door, open_door, open_door_js, touch_door, transform_door, wall, wallpaper

Index for Viewpoint node: Viewpoint_1

Index for ExternProtoDeclare definitions: Chair, Desk, WallLamp

-->

X3D Tooltips element index: to top Anchor, Appearance, AudioClip, Box, Coordinate, ElevationGrid, ExternProtoDeclare, field, fieldValue, Group, head, ImageTexture, IndexedFaceSet, Inline, Material, meta, NavigationInfo, OrientationInterpolator, ProtoInstance, ROUTE, Scene, Script, Shape, Sound, TextureTransform, TimeSensor, TouchSensor, Transform, Viewpoint, WorldInfo, X3D,
plus documentation for accessType definitions, type definitions, XML data types, and field types

🔖   Event Graph ROUTE Table entries with 6 ROUTE connections and 2 Anchor, TouchSensor hover hints, showing X3D event-model relationships for this scene.

Each row with a ROUTE statement shows an event cascade that may occur during a single timestamp interval between frame renderings, performed as part of the X3D execution model.

clock
TimeSensor
fraction_changed
SFFloat
→
ROUTE
event to
(1)
open_door
OrientationInterpolator
set_fraction
SFFloat 		then
from
same
node 		open_door
OrientationInterpolator
value_changed
SFRotation
→
ROUTE
event to
(2)
transform_door
Transform
set_rotation
SFRotation

line 86
Anchor
description='link to NPS web page'
No direct ROUTE connection found for events to/from this node.

line 104
ProtoInstance
Chair 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

line 110
ProtoInstance
Desk 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

line 114
ProtoInstance
WallLamp 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

line 125
ProtoInstance
WallLamp 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

touch_door
TouchSensor
touchTime
SFTime
→
ROUTE
event to
(1)
clock
TimeSensor
startTime
SFTime 		then
from
same
node 		clock
TimeSensor
fraction_changed
SFFloat
→
ROUTE
event to
(2)
open_door
OrientationInterpolator
set_fraction
SFFloat 		then
from
same
node 		open_door
OrientationInterpolator
value_changed
SFRotation
→
ROUTE
event to
(3)
transform_door
Transform
set_rotation
SFRotation
touch_door
TouchSensor
touchTime
SFTime
→
ROUTE
event to
(1)
open_door_js
Script
set_open
SFTime 		then
from
same
node 		open_door_js
Script
keyValue_changed
MFRotation
→
ROUTE
event to
(2)
open_door
OrientationInterpolator
set_keyValue
MFRotation 		then
from
same
node 		open_door
OrientationInterpolator
value_changed
SFRotation
→
ROUTE
event to
(3)
transform_door
Transform
set_rotation
SFRotation
touch_door
TouchSensor
touchTime
SFTime
→
ROUTE
event to
(1)
grinding_door
AudioClip
startTime
SFTime

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets.
Have fun with X3D! 😀
-->
go to online X3D Example Archives model page <!-- Online at
https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/RoomIndex.html -->
<!-- SourceForge version control Version control at
https://sourceforge.net/p/x3d/code/HEAD/tree/www.web3d.org/x3d/content/examples/Basic/StudentProjects/Room.x3d -->

<!-- Color-coding legend: X3D terminology <X3dNode DEF='idName' field='value'/> matches XML terminology <XmlElement DEF='idName' attribute='value'/>
(Light-blue background: event-based behavior node or statement) (Grey background inside box: inserted documentation) (Magenta background: X3D Extensibility)
    <ProtoInstance name='ProtoName'> <field name='fieldName'/> </ProtoInstance> -->

to top <!-- For additional help information about X3D scenes, please see X3D Tooltips, X3D Resources, and X3D Scene Authoring Hints. -->
