<head>
<meta name='title' content=' AllenDuttonVillage.x3d '/>
<meta name='creator' content='LT Allen Dutton'/>
<meta name='created' content='26 February 2001'/>
<meta name='modified' content='20 October 2019'/>
<meta name='description' content='Primitive village. Move mouse over the hut roofs to see a demonstration of sensors and interpolators'/>
<meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/AllenDuttonVillage.x3d '/>
<meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
<meta name='license' content=' ../license.html'/>
</head>
<!--
to top <!-- Event Graph ROUTE Table shows event connections -->

<!-- Index for DEF nodes: BROWN, CLOCK, CONE_TREE, grass, HUT, leaves, MyTouchSensor, ROOF_TRANSFORM, RoofRotateInterpolator, RoofTranslateInterpolator, SPHERE_TREE, straw, wood, YELLOW
Index for Viewpoint nodes: Viewpoint_1, Viewpoint_2
-->
<Scene>
<WorldInfo title='AllenDuttonVillage.x3d'/>
<Viewpoint description='View from 80m away' orientation='-1 0 0 0.5' position='0 60 100'/>
<Viewpoint description='Default viewpoint at (0 0 10) is way too close!! That is a bad place to be, provide a replacement viewpoint instead.'/>
<Background skyColor='0 0 .7'/>
<DirectionalLight color='1 1 0.8' direction='0 -1 0' intensity='0.5'/>
<Group>
<Transform translation='0 -3.5 0'>
<Shape>
<Appearance>
<Material diffuseColor='0 .7 0'/>
<ImageTexture DEF='grass'
  url=' "grass.jpg " "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/grass.jpg " ' />
<TextureTransform scale='20 20'/>
</Appearance>
<Box size='160 1 160'/>
</Shape>
</Transform>
</Group>
<Group>
<Transform rotation='0 1 0 2.7' scale='0.01 0.01 0.01' translation='5 12.3 30'>
<Inline
  url=' "ALLEN.WRL" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/ALLEN.WRL" ' />
</Transform>
<Transform translation='5 0 30'>
<Shape>
<Box size='5 5 5'/>
<Appearance>
<Material diffuseColor='0.5 0.5 0.5'/>
</Appearance>
</Shape>
</Transform>
</Group>
<Group DEF='HUT'>
<Shape>
<Appearance>
<Material DEF='BROWN' diffuseColor='0.5 0.4 0.3'/>
<ImageTexture DEF='wood'
  url=' "wood.gif " "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/wood.gif " ' />
<TextureTransform rotation='1.57079' scale='1.0 4.0'/>
</Appearance>
<Cylinder bottom='false' height='6' radius='4' top='false'/>
</Shape>
<!-- ROUTE information for ROOF_TRANSFORM node:  [from RoofRotateInterpolator.value_changed to set_rotation ] [from RoofTranslateInterpolator.value_changed to set_translation ] -->
 <Transform DEF='ROOF_TRANSFORM' translation='0 4 0'>
<Shape>
<Appearance>
<Material DEF='YELLOW' diffuseColor='0.8 0.8 0'/>
<ImageTexture DEF='straw'
  url=' "straw.jpg " "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/straw.jpg " ' />
</Appearance>
<Cone bottomRadius='6' height='4'/>
</Shape>
<!-- ROUTE information for MyTouchSensor node:  [from isOver to CLOCK.set_enabled ] -->
 <TouchSensor DEF='MyTouchSensor' description='raise the roof'/>
</Transform>
<!-- ROUTE information for CLOCK node:  [from MyTouchSensor.isOver to set_enabled ] [from fraction_changed to RoofRotateInterpolator.set_fraction ] [from fraction_changed to RoofTranslateInterpolator.set_fraction ] -->
 <TimeSensor DEF='CLOCK' cycleInterval='4' enabled='false' loop='true'/>

<!-- ROUTE information for RoofRotateInterpolator node:  [from CLOCK.fraction_changed to set_fraction ] [from value_changed to ROOF_TRANSFORM.set_rotation ] -->
 <OrientationInterpolator DEF='RoofRotateInterpolator' key='0.0 0.50 1.0' keyValue='0.0 1.0 0.0 0.0 0.0 1.0 0.0 3.14 0.0 1.0 0.0 6.28'/>

<!-- ROUTE information for RoofTranslateInterpolator node:  [from CLOCK.fraction_changed to set_fraction ] [from value_changed to ROOF_TRANSFORM.set_translation ] -->
 <PositionInterpolator DEF='RoofTranslateInterpolator' key='0.0 0.5 1.0' keyValue='0.0 4.0 0.0 0.0 8.0 0.0 0.0 4.0 0.0'/>
</Group>
<Group DEF='CONE_TREE'>
<Transform translation='10 0 0'>
<Shape>
<Appearance>
<Material USE=' BROWN'/>
<ImageTexture USE=' wood'/>
</Appearance>
<Cylinder bottom='false' height='6' radius='0.5' top='false'/>
</Shape>
</Transform>
<Transform translation='10 3 0'>
<Shape>
<Appearance>
<Material diffuseColor='0 .3 0'/>
<ImageTexture DEF='leaves'
  url=' "leaves.jpg " "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/leaves.jpg " ' />
</Appearance>
<Cone bottomRadius='2' height='6'/>
</Shape>
</Transform>
</Group>
<Group DEF='SPHERE_TREE'>
<Transform translation='-30 0 -3'>
<Shape>
<Appearance>
<Material USE=' BROWN'/>
<ImageTexture USE=' wood'/>
</Appearance>
<Cylinder bottom='false' height='6' radius='0.5' top='false'/>
</Shape>
</Transform>
<Transform translation='-30 6 -3'>
<Shape>
<Appearance>
<Material diffuseColor='0 .3 0'/>
<ImageTexture USE=' leaves'/>
</Appearance>
<Sphere radius='3.5'/>
</Shape>
</Transform>
</Group>
<Group>
<Transform scale='.8 1 .8' translation='-45 0 10'>
<Group USE=' HUT'/>
<Transform translation='0 11 0'>
<Shape>
<Text string='"Visitor's" "Center"'>
<FontStyle justify='"MIDDLE" "MIDDLE"' size='5.0' style='BOLDITALIC'/>
</Text>
<Appearance>
<Material diffuseColor='0.8 0.1 0.4'/>
</Appearance>
</Shape>
</Transform>
</Transform>
</Group>
<Group>
<Transform scale='1.5 1 1.5' translation='30 0 20'>
<Group USE=' HUT'/>
<Transform translation='1 8 0'>
<Shape>
<Text string='"Chief's Hut"'>
<FontStyle justify='"MIDDLE" "MIDDLE"' size='4.0' style='BOLD'/>
</Text>
<Appearance>
<Material diffuseColor='0.8 0.1 0.4'/>
</Appearance>
</Shape>
</Transform>
</Transform>
</Group>
<Group>
<Transform scale='.5 1 .5' translation='-10 0 20'>
<Group USE=' HUT'/>
<Transform translation='0 24 0'>
<Shape>
<Text string='"Outhouse"'>
<FontStyle family='"SANS"' horizontal='false' justify='"MIDDLE" "MIDDLE"' size='5.0' style='BOLD'/>
</Text>
<Appearance>
<Material diffuseColor='0.8 0.1 0.4'/>
</Appearance>
</Shape>
</Transform>
</Transform>
</Group>
<Group>
<Transform scale='0.5 1.0 0.5' translation='30 0 30'>
<Group USE=' SPHERE_TREE'/>
</Transform>
</Group>
<Group>
<Transform scale='2 1.0 2' translation='-45 0 30'>
<Group USE=' CONE_TREE'/>
</Transform>
</Group>
< ROUTE  fromNode=' MyTouchSensor' fromField='isOver' toNode=' CLOCK' toField='set_enabled'/>
< ROUTE  fromNode=' CLOCK' fromField='fraction_changed' toNode=' RoofRotateInterpolator' toField='set_fraction'/>
< ROUTE  fromNode=' RoofRotateInterpolator' fromField='value_changed' toNode=' ROOF_TRANSFORM' toField='set_rotation'/>
< ROUTE  fromNode=' CLOCK' fromField='fraction_changed' toNode=' RoofTranslateInterpolator' toField='set_fraction'/>
< ROUTE  fromNode=' RoofTranslateInterpolator' fromField='value_changed' toNode=' ROOF_TRANSFORM' toField='set_translation'/>
</Scene>
</X3D>
<!--
