X3D Model Documentation: BridgeDoorPort.x3d

1	`<?xml version="1.0" encoding="UTF-8"?>`
2	`<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.2//EN" "https://www.web3d.org/specifications/x3d-3.2.dtd">`
3	<X3D profile='Immersive' version='3.2' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.2.xsd'>
4	<head>
5	<meta name='title' content=' BridgeDoorPort.x3d '/>
6	<meta name='description' content='Brazilian Naval Academy Training Ship'/>
7	<meta name='creator' content='Claudio Coreixas'/>
8	<meta name='created' content='20 October 2009'/>
9	<meta name='modified' content='20 October 2019'/>
10	<meta name='reference' content='http://www.en.mar.mil.br'/>
11	<meta name='subject' content='ships parts'/>
12	<meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/PatrolCraftNavalAcademyBrazil/BridgeDoorPort.x3d '/>
13	<meta name='generator' content='X3D-Edit, https://www.web3d.org/x3d/tools/X3D-Edit'/>
14	<meta name='license' content='../../license.html'/>
15	</head>

<!--

Event Graph ROUTE Table shows event connections.

-->
<!--

DEF nodes index: BridgeDoorStb, dog, dogSensor, dogTimer, doorIFS, Glass, openDog, openDogSpin, openDoor, openDoorTransform, spinTimer, window, windowIFS

Index for Viewpoint node: Viewpoint_1

-->

16	<Scene>
17	<WorldInfo title='BridgeDoorPort.x3d'/>
18	<Viewpoint description='Door' fieldOfView='0.45' orientation='1 0 0 0' position='5.7 2.3 4'/>
19	<!-- ROUTE information for spinTimer node: [from dogSensor.touchTime to startTime ] [from fraction_changed to openDoor.set_fraction ] --> <TimeSensor DEF='spinTimer' cycleInterval='3'/>
20	<!-- ROUTE information for openDoor node: [from spinTimer.fraction_changed to set_fraction ] [from value_changed to openDoorTransform.rotation ] --> <OrientationInterpolator DEF='openDoor' key='0 0.25 0.5 0.75 1' keyValue='0 1 0 0 0 1 0 0 0 1 0 0 0 1 0 -1.57 0 1 0 -3'/>
21	< ROUTE fromNode='spinTimer' fromField='fraction_changed' toNode='openDoor' toField='set_fraction'/>
22	<!-- ROUTE information for dogTimer node: [from dogSensor.touchTime to startTime ] [from fraction_changed to openDog.set_fraction ] --> <TimeSensor DEF='dogTimer'/>
23	<!-- ROUTE information for openDog node: [from dogTimer.fraction_changed to set_fraction ] [from value_changed to openDogSpin.rotation ] --> <OrientationInterpolator DEF='openDog' key='0 1' keyValue='0 0 1 0 0 0 1 -1.3'/>
24	< ROUTE fromNode='dogTimer' fromField='fraction_changed' toNode='openDog' toField='set_fraction'/>
25	<!-- ROUTE information for openDoorTransform node: [from openDoor.value_changed to rotation ] --> <Transform DEF='openDoorTransform' center='5.825 2 -0.55'>
26	< ROUTE fromNode='openDoor' fromField='value_changed' toNode='openDoorTransform' toField='rotation'/>
27	<!-- ROUTE information for openDogSpin node: [from openDog.value_changed to rotation ] --> <Transform DEF='openDogSpin' center='5.6 2.3 -0.55'>
28	< ROUTE fromNode='openDog' fromField='value_changed' toNode='openDogSpin' toField='rotation'/>
29	<Transform>
30	<Transform>
31	<Shape DEF='dog'>
32	<Appearance>
33	<Material/>
34	</Appearance>
35	<Extrusion ccw='false' convex='false' crossSection='0.01 0 0.0092 0.0038 0.0071 0.0071 0.0038 0.0092 0 0.01 -0.0038 0.0092 -0.0071 0.0071 -0.0092 0.0038 -0.01 0 -0.0092 -0.0038 -0.0071 -0.0071 -0.0038 -0.0092 0 -0.01 0.0038 -0.0092 0.0071 -0.0071 0.0092 -0.0039 0.01 0' scale='0.3 0.5 0.4 0.7 0.55 0.8 0.7 0.85 0.85 0.95 1 1 1 1 0.85 0.95 0.7 0.85 0.55 0.8 0.4 0.7 0.3 0.5' solid='false' spine='5.6690 2.3000 -0.5330 5.6100 2.3000 -0.5330 5.6062 2.3000 -0.5338 5.6029 2.3000 -0.5359 5.6008 2.3000 -0.5391 5.6000 2.3000 -0.5430 5.6000 2.3000 -0.5570 5.6008 2.3000 -0.5608 5.6029 2.3000 -0.5641 5.6062 2.3000 -0.5662 5.6100 2.3000 -0.5670 5.6690 2.3000 -0.5670'/>
36	</Shape>
37	</Transform>
38	<!-- ROUTE information for dogSensor node: [from touchTime to spinTimer.startTime ] [from touchTime to dogTimer.startTime ] --> <TouchSensor DEF='dogSensor' description='Touch to Open Hatch'/>
39	< ROUTE fromNode='dogSensor' fromField='touchTime' toNode='spinTimer' toField='startTime'/>
40	< ROUTE fromNode='dogSensor' fromField='touchTime' toNode='dogTimer' toField='startTime'/>
41	</Transform>
42	</Transform>
43	<Shape DEF='BridgeDoorStb'>
44	<Appearance>
45	<ImageTexture url=' "wood02.jpg " "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/PatrolCraftNavalAcademyBrazil/wood.jpg " '/>
46	</Appearance>
47	<IndexedFaceSet DEF='doorIFS' creaseAngle='1.5' solid='false' coordIndex='0 4 5 1 -1 1 5 6 2 -1 2 6 7 3 -1 4 0 3 7 -1'>
48	<Coordinate point='5.575 2 -0.55 5.825 2 -0.55 5.825 2.55 -0.55 5.575 2.55 -0.55 5.6 2.325 -0.55 5.8 2.325 -0.55 5.8 2.525 -0.55 5.6 2.525 -0.55'/>
49	</IndexedFaceSet>
50	</Shape>
51	<Shape DEF='window'>
52	<Appearance>
53	<Material DEF='Glass' ambientIntensity='0.37773332' diffuseColor='0.0 0.36666667 0.76666665' shininess='0.76666665' specularColor='1.0 1.0 1.0' transparency='0.58'/>
54	</Appearance>
55	<IndexedFaceSet DEF='windowIFS' creaseAngle='1.5' solid='false' coordIndex='0 1 2 3 -1'>
56	<Coordinate point='5.6 2.325 -0.55 5.8 2.325 -0.55 5.8 2.525 -0.55 5.6 2.525 -0.55'/>
57	</IndexedFaceSet>
58	</Shape>
59	</Transform>
60	</Scene>
61	</X3D>

<!--

Event Graph ROUTE Table shows event connections.

-->
<!--

-->

X3D Tooltips element index: Appearance, Coordinate, Extrusion, head, ImageTexture, IndexedFaceSet, Material, meta, OrientationInterpolator, ROUTE, Scene, Shape, TimeSensor, TouchSensor, Transform, Viewpoint, WorldInfo, X3D, plus documentation for accessType definitions, type definitions, XML data types, and field types

Event Graph ROUTE Table entries with 6 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

dogSensor TouchSensor touchTime SFTime	→ ROUTE event to (1)	spinTimer TimeSensor startTime SFTime	then	spinTimer TimeSensor fraction_changed SFFloat	→ ROUTE event to (2)	openDoor OrientationInterpolator set_fraction SFFloat	then	openDoor OrientationInterpolator value_changed SFRotation	→ ROUTE event to (3)	openDoorTransform Transform rotation SFRotation
dogSensor TouchSensor touchTime SFTime	→ ROUTE event to (1)	dogTimer TimeSensor startTime SFTime	then	dogTimer TimeSensor fraction_changed SFFloat	→ ROUTE event to (2)	openDog OrientationInterpolator set_fraction SFFloat	then	openDog OrientationInterpolator value_changed SFRotation	→ ROUTE event to (3)	openDogSpin Transform rotation SFRotation

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀

-->
