| 1 |
<?xml version="1.0" encoding="UTF-8"?>
|
| 2 |
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">
|
| 3 | <X3D profile='Immersive' version='3.0' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'> |
| 4 | <head> |
| 5 | <meta name='title' content=' RifleM24Example.x3d '/> |
| 6 | <meta name='description' content='Animation example from RifleM24 Prototype. Clicking trigger fires and sound.'/> |
| 7 | <meta name='creator' content='Etsuko Lippi'/> |
| 8 | <meta name='created' content='31 Decmember 2001'/> |
| 9 | <meta name='modified' content='28 November 2019'/> |
| 10 | <meta name='generator' content='X3D-Edit 3.2, https://www.web3d.org/x3d/tools/X3D-Edit'/> |
| 11 | <meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Savage/Weapons/SmallArms/RifleM24Example.x3d '/> |
| 12 | <meta name='subject' content='Rifle M24'/> |
| 13 | <meta name='license' content='../../license.html'/> |
| 14 | </head> |
DEF nodes index:
About,
AboutRifleM24,
FireScript,
FireTouchSensor,
rifleM24,
Target
| 15 | <Scene> |
| 16 | <WorldInfo title='RifleM24Example.x3d'/> |
| 17 | <ExternProtoDeclare name='RifleM24' appinfo='Rifle M24' url=' "RifleM24Prototype.x3d#RifleM24" "https://www.web3d.org/x3d/content/examples/Savage/Weapons/SmallArms/RifleM24Prototype.x3d#RifleM24" "RifleM24Prototype.wrl#RifleM24" "https://www.web3d.org/x3d/content/examples/Savage/Weapons/SmallArms/RifleM24Prototype.wrl#RifleM24" '> |
| 18 |
<field name='trigger' type='SFBool' accessType='inputOnly'
appinfo='input true to fire'/> |
| 19 |
<field name='fire' type='SFBool' accessType='outputOnly'
appinfo='output true when fired'/> |
| 20 |
<field name='animationStartTime' type='SFTime' accessType='inputOnly'
appinfo='trigger animation'/> |
| 21 | </ExternProtoDeclare> |
| 22 | <Background skyColor='0.604 0.753 0.804'/> |
| 23 | <Group> |
| 24 |
<!-- ROUTE information for rifleM24 node:
[from FireTouchSensor.touchTime to animationStartTime
]
[from FireScript.fire to trigger
]
-->
<ProtoInstance name='RifleM24' DEF='rifleM24'/> |
| 25 |
<!-- ROUTE information for FireScript node:
[from FireTouchSensor.isOver to enabled
]
[from fire to rifleM24.trigger
]
-->
<Script DEF='FireScript'> |
| 26 | <field name='fire' type='SFBool' accessType='outputOnly'/> |
| 27 | <field name='enabled' type='SFBool' accessType='inputOnly'/> |
<![CDATA[
ecmascript:
function enabled (value, timeStamp)
{
//print ('enabled value =' + value);
if (value == true)
fire = value;
}
]]>
|
|
| 29 | </Script> |
| 30 |
<!-- ROUTE information for FireTouchSensor node:
[from isOver to FireScript.enabled
]
[from touchTime to rifleM24.animationStartTime
]
-->
<TouchSensor DEF='FireTouchSensor' description='click to shoot'/> |
| 31 | < ROUTE fromNode='FireTouchSensor' fromField='isOver' toNode='FireScript' toField='enabled'/> |
| 32 | < ROUTE fromNode='FireTouchSensor' fromField='touchTime' toNode='rifleM24' toField='animationStartTime'/> |
| 33 | < ROUTE fromNode='FireScript' fromField='fire' toNode='rifleM24' toField='trigger'/> |
| 34 | </Group> |
| 35 | <Transform DEF='Target' rotation='0.58 0.58 0.58 2.09' translation='50 -1 0'> |
| 36 | <Shape> |
| 37 | <Appearance> |
| 38 | <Material/> |
| 39 |
<ImageTexture
url=' "Target.gif
" "Target.jpg
" "https://www.web3d.org/x3d/content/examples/Savage/Weapons/SmallArms/Target.gif
" "https://www.web3d.org/x3d/content/examples/Savage/Weapons/SmallArms/Target.jpg
" '/>
|
| 40 | </Appearance> |
| 41 | <IndexedFaceSet creaseAngle='1.75' solid='false' coordIndex='0 1 2 3 0'> |
| 42 | <Coordinate point='0.00 1.30 0 2.5 1.30 0 2.5 -1.30 0 0.00 -1.30 0'/> |
| 43 | </IndexedFaceSet> |
| 44 | </Shape> |
| 45 | </Transform> |
| 46 | <Anchor DEF='About' description='Federation of American Scientists (FAS) page' parameter='"target=_blank"' url=' "https://www.fas.org/man/dod-101/sys/land/m14.htm" '> |
| 47 | <Transform DEF='AboutRifleM24' translation='-0.5 -0.4 -0.3'> |
| 48 | <Shape> |
| 49 | <Appearance> |
| 50 | <Material diffuseColor='0 0 0.545'/> |
| 51 | </Appearance> |
| 52 | <Text string='"About RifleM24"'> |
| 53 | <FontStyle justify='"MIDDLE" "MIDDLE"' size='0.25' style='BOLD'/> |
| 54 | </Text> |
| 55 | </Shape> |
| 56 | </Transform> |
| 57 | </Anchor> |
| 58 | </Scene> |
| 59 | </X3D> |
DEF nodes index:
About,
AboutRifleM24,
FireScript,
FireTouchSensor,
rifleM24,
Target
Event Graph ROUTE Table entries with 3 ROUTE connections total, showing X3D event-model relationships for this scene.
Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.
|
FireTouchSensor
TouchSensor isOver SFBool |
FireScript
Script enabled SFBool |
then
|
FireScript
Script fire SFBool |
rifleM24
ProtoInstance trigger SFBool |
||
|
FireTouchSensor
TouchSensor touchTime SFTime |
rifleM24
ProtoInstance animationStartTime SFTime |
|
rifleM24
ProtoInstance RifleM24 |
No direct ROUTE connection found for events to/from this node. This ProtoInstance contains SFNode/MFNode fieldValue declarations with direct access to other nodes, and thus has potential to produce run-time animation. |
|
About
Anchor |
description='Federation of American Scientists (FAS) page' User-interaction hint for this node. |
<!--
