AGM65MaverickViewAnchors.x3d (X3dToXhtml listing)

Event Graph ROUTE Table entries with 8 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

MyClickSensor TouchSensor touchTime SFTime	→ ROUTE event to (1)	CLOCK2 TimeSensor set_startTime SFTime	then	CLOCK2 TimeSensor fraction_changed SFFloat	→ ROUTE event to (2)	PathInterpolator PositionInterpolator set_fraction SFFloat	then	PathInterpolator PositionInterpolator value_changed SFVec3f	→ ROUTE event to (3)	MISSILE_TRANSFORM Transform set_translation SFVec3f
			then	CLOCK2 TimeSensor fraction_changed SFFloat	→ ROUTE event to (2)	SpinInterpolator OrientationInterpolator set_fraction SFFloat	then	SpinInterpolator OrientationInterpolator value_changed SFRotation	→ ROUTE event to (3)	MISSILE_TRANSFORM Transform set_rotation SFRotation

MyTouchSensor
TouchSensor
isOver
SFBool

→
ROUTE
event to
(1)

CLOCK1
TimeSensor
set_enabled
SFBool

then

CLOCK1
TimeSensor
fraction_changed
SFFloat

→
ROUTE
event to
(2)

RotateInterpolator
OrientationInterpolator
set_fraction
SFFloat

then

RotateInterpolator
OrientationInterpolator
value_changed
SFRotation

→
ROUTE
event to
(3)

MISSILE_TRANSFORM
Transform
set_rotation
SFRotation

line 20
Anchor

description='Click for closeup viewpoint of missile'
User-interaction hint for this node.

line 32
Anchor

description='Click for aft view of missile (for cool launch view)'
User-interaction hint for this node.

line 44
Anchor

description='Click to return to initial view of missile'
User-interaction hint for this node.

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀

1	`<?xml version="1.0" encoding="UTF-8"?>`
2	`<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">`
3	<X3D profile='Immersive' version='3.0' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
4	<head>
5	<meta name='title' content=' AGM65MaverickViewAnchors.x3d '/>
6	<meta name='description' content='AGM-65M Maverick Missile with anchors points for selective viewpoints, and touch sensors for user interaction.'/>
7	<meta name='creator' content='Al Shaffer'/>
8	<meta name='created' content='20 January 2005'/>
9	<meta name='modified' content='16 January 2014'/>
10	<meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Savage/Weapons/Missiles/AGM65MaverickViewAnchors.x3d '/>
11	<meta name='generator' content='X3D-Edit 3.2, https://www.web3d.org/x3d/tools/X3D-Edit'/>
12	<meta name='license' content='../../license.html'/>
13	</head>

14	<Scene>
15	<!-- Viewpoint nodes set various views, based on selection of Anchor points in the world. -->
16	<WorldInfo title='AGM65MaverickViewAnchors.x3d'/>
17	<Viewpoint DEF='MISSILE_INITIAL_VIEW' description='Initial view of Missile' position='-50 0 100'/>
18	<Viewpoint DEF='MISSILE_CLOSEUP' description='Closeup view of missile' position='0.0 0.0 13.0'/>
19	<Viewpoint DEF='MISSILE_AFT' description='Aft view of missile, for launch' orientation='-0.1 0.9 0.1 1.57' position='22.0 5.0 5.0'/>
20	<Anchor description='Click for closeup viewpoint of missile' url=' "#MISSILE_CLOSEUP" '>
21	<Transform rotation='1 0 0 -1.1' translation='-4.0 -2.5 15.0'>
22	<Collision enabled='false'>
23	<Shape>
24	<Cone bottomRadius='.5' height='2.5'/>
25	<Appearance>
26	<Material diffuseColor='0.1 0.4 0.8' emissiveColor='0 0.1 0.2' shininess='.4' specularColor='0.8 0.8 0.8' transparency='.5'/>
27	</Appearance>
28	</Shape>
29	</Collision>
30	</Transform>
31	</Anchor>
32	<Anchor description='Click for aft view of missile (for cool launch view)' url=' "#MISSILE_AFT" '>
33	<Transform rotation='0 0 1 1.57' translation='9.5 0.0 0.0'>
34	<Collision enabled='false'>
35	<Shape>
36	<Cone bottomRadius='0.5' height='2.5'/>
37	<Appearance>
38	<Material diffuseColor='0.1 0.8 0.4' emissiveColor='0 0.2 0.1' shininess='.4' specularColor='0.8 0.8 0.8' transparency='.5'/>
39	</Appearance>
40	</Shape>
41	</Collision>
42	</Transform>
43	</Anchor>
44	<Anchor description='Click to return to initial view of missile' url=' "#MISSILE_INITIAL_VIEW" '>
45	<Transform rotation='1 0 0 3.14' translation='0.0 5.0 0.0'>
46	<Collision enabled='false'>
47	<Shape>
48	<Cone bottomRadius='0.5' height='2.5'/>
49	<Appearance>
50	<Material diffuseColor='1 0 0' emissiveColor='0.2 0 0' shininess='.4' specularColor='0.8 0.8 0.8' transparency='.5'/>
51	</Appearance>
52	</Shape>
53	</Collision>
54	</Transform>
55	</Anchor>
56	<Background groundAngle='0.1 1.309 1.570796' groundColor='0 0 0 0 0.1 0.3 0 0.2 0.5 0 0.3 0.8' skyAngle='0.1 0.15 1.309 1.571' skyColor='0.4 0.4 0.1 0.4 0.4 0.1 0 0.1 0.3 0 0.2 0.6 0.8 0.8 0.8' backUrl=' "urn:web3d:media:textures/panoramas/ocean_4_back.jpg" "ocean_4_back.jpg " "https://www.web3d.org/WorkingGroups/media/textures/panoramas/ocean_4_back.jpg " "https://www.web3d.org/x3d/content/examples/UniversalMediaPanoramas/ocean_4_back.jpg " "http://www.web3dmedia.com/UniversalMedia/textures/panoramas/ocean_4_back.jpg " "http://www.officetowers.com/UniversalMedia/textures/panoramas/ocean_4_back.jpg " "http://geometrek.com/UniversalMedia/textures/panoramas/ocean_4_back.jpg " "http://www.sc.ehu.es/ccwgamoa/UniversalMedia/textures/panoramas/ocean_4_back.jpg " ' bottomUrl=' "urn:web3d:media:textures/panoramas/ocean_4_bottom.jpg" "ocean_4_bottom.jpg " "https://www.web3d.org/WorkingGroups/media/textures/panoramas/ocean_4_bottom.jpg " "https://www.web3d.org/x3d/content/examples/UniversalMediaPanoramas/ocean_4_bottom.jpg " "http://www.web3dmedia.com/UniversalMedia/textures/panoramas/ocean_4_bottom.jpg " "http://www.officetowers.com/UniversalMedia/textures/panoramas/ocean_4_bottom.jpg " "http://geometrek.com/UniversalMedia/textures/panoramas/ocean_4_bottom.jpg " "http://www.sc.ehu.es/ccwgamoa/UniversalMedia/textures/panoramas/ocean_4_bottom.jpg " ' frontUrl=' "urn:web3d:media:textures/panoramas/ocean_4_front.jpg" "ocean_4_front.jpg " "https://www.web3d.org/WorkingGroups/media/textures/panoramas/ocean_4_front.jpg " "https://www.web3d.org/x3d/content/examples/UniversalMediaPanoramas/ocean_4_front.jpg " "http://www.web3dmedia.com/UniversalMedia/textures/panoramas/ocean_4_front.jpg " "http://www.officetowers.com/UniversalMedia/textures/panoramas/ocean_4_front.jpg " "http://geometrek.com/UniversalMedia/textures/panoramas/ocean_4_front.jpg " "http://www.sc.ehu.es/ccwgamoa/UniversalMedia/textures/panoramas/ocean_4_front.jpg " ' leftUrl=' "urn:web3d:media:textures/panoramas/ocean_4_left.jpg" "ocean_4_left.jpg " "https://www.web3d.org/WorkingGroups/media/textures/panoramas/ocean_4_left.jpg " "https://www.web3d.org/x3d/content/examples/UniversalMediaPanoramas/ocean_4_left.jpg " "http://www.web3dmedia.com/UniversalMedia/textures/panoramas/ocean_4_left.jpg " "http://www.officetowers.com/UniversalMedia/textures/panoramas/ocean_4_left.jpg " "http://geometrek.com/UniversalMedia/textures/panoramas/ocean_4_left.jpg " "http://www.sc.ehu.es/ccwgamoa/UniversalMedia/textures/panoramas/ocean_4_left.jpg " ' rightUrl=' "urn:web3d:media:textures/panoramas/ocean_4_right.jpg" "ocean_4_right.jpg " "https://www.web3d.org/WorkingGroups/media/textures/panoramas/ocean_4_right.jpg " "https://www.web3d.org/x3d/content/examples/UniversalMediaPanoramas/ocean_4_right.jpg " "http://www.web3dmedia.com/UniversalMedia/textures/panoramas/ocean_4_right.jpg " "http://www.officetowers.com/UniversalMedia/textures/panoramas/ocean_4_right.jpg " "http://geometrek.com/UniversalMedia/textures/panoramas/ocean_4_right.jpg " "http://www.sc.ehu.es/ccwgamoa/UniversalMedia/textures/panoramas/ocean_4_right.jpg " ' topUrl=' "urn:web3d:media:textures/panoramas/ocean_4_top.jpg" "ocean_4_top.jpg " "https://www.web3d.org/WorkingGroups/media/textures/panoramas/ocean_4_top.jpg " "https://www.web3d.org/x3d/content/examples/UniversalMediaPanoramas/ocean_4_top.jpg " "http://www.web3dmedia.com/UniversalMedia/textures/panoramas/ocean_4_top.jpg " "http://www.officetowers.com/UniversalMedia/textures/panoramas/ocean_4_top.jpg " "http://geometrek.com/UniversalMedia/textures/panoramas/ocean_4_top.jpg " "http://www.sc.ehu.es/ccwgamoa/UniversalMedia/textures/panoramas/ocean_4_top.jpg " '/>
57	<Group>
58	<!-- ROUTE information for MISSILE_TRANSFORM node: [from PathInterpolator.value_changed to set_translation ] [from SpinInterpolator.value_changed to set_rotation ] [from RotateInterpolator.value_changed to set_rotation ] --> <Transform DEF='MISSILE_TRANSFORM'>
59	<Inline DEF='AGM65Maverick' url=' "ShafferAGM65Maverick.x3d" "https://www.web3d.org/x3d/content/examples/Savage/Weapons/Missiles/ShafferAGM65Maverick.x3d" "ShafferAGM65Maverick.wrl" "https://www.web3d.org/x3d/content/examples/Savage/Weapons/Missiles/ShafferAGM65Maverick.wrl" '/>
60	</Transform>
61	<!-- Define sensors and interpolator for missile rotation. -->
62	<!-- ROUTE information for MyTouchSensor node: [from isOver to CLOCK1.set_enabled ] --> <TouchSensor DEF='MyTouchSensor' description='touch sensor: hover mouse to rotate missile'/>
63	<!-- ROUTE information for CLOCK1 node: [from MyTouchSensor.isOver to set_enabled ] [from fraction_changed to RotateInterpolator.set_fraction ] --> <TimeSensor DEF='CLOCK1' cycleInterval='4' enabled='false' loop='true'/>
64	<!-- ROUTE information for RotateInterpolator node: [from CLOCK1.fraction_changed to set_fraction ] [from value_changed to MISSILE_TRANSFORM.set_rotation ] --> <OrientationInterpolator DEF='RotateInterpolator' key='0.0 0.25 0.5 0.75 1.0' keyValue='1.0 0.0 0.0 0.0 1.0 0.0 0.0 -1.57 1.0 0.0 0.0 -3.14 1.0 0.0 0.0 -4.71 1.0 0.0 0.0 -6.28'/>
65	<!-- Define sensors and interpolators for missile launch, travel, and rotation. -->
66	<!-- ROUTE information for MyClickSensor node: [from touchTime to CLOCK2.set_startTime ] --> <TouchSensor DEF='MyClickSensor' description='touch sensor: click to launch missile'/>
67	<!-- ROUTE information for CLOCK2 node: [from MyClickSensor.touchTime to set_startTime ] [from fraction_changed to PathInterpolator.set_fraction ] [from fraction_changed to SpinInterpolator.set_fraction ] --> <TimeSensor DEF='CLOCK2' cycleInterval='4'/>
68	<!-- ROUTE information for PathInterpolator node: [from CLOCK2.fraction_changed to set_fraction ] [from value_changed to MISSILE_TRANSFORM.set_translation ] --> <PositionInterpolator DEF='PathInterpolator' key='0.0 0.25 0.5 0.75 1.0' keyValue='0.0 0.0 0.0 -75.0 0.0 0.0 -150.0 0.0 0.0 -225.0 0.0 0.0 0.0 0.0 0.0'/>
69	<!-- ROUTE information for SpinInterpolator node: [from CLOCK2.fraction_changed to set_fraction ] [from value_changed to MISSILE_TRANSFORM.set_rotation ] --> <OrientationInterpolator DEF='SpinInterpolator' key='0.0 0.25 0.5 0.75 1.0' keyValue='1.0 0.0 0.0 0.0 1.0 0.0 0.0 -1.57 1.0 0.0 0.0 -3.14 1.0 0.0 0.0 -4.71 1.0 0.0 0.0 -6.28'/>
70	</Group>
71	<!-- Set ROUTE for missile to launch when clicked, and rotate during travel. -->
72	< ROUTE fromNode='MyClickSensor' fromField='touchTime' toNode='CLOCK2' toField='set_startTime'/>
73	< ROUTE fromNode='CLOCK2' fromField='fraction_changed' toNode='PathInterpolator' toField='set_fraction'/>
74	< ROUTE fromNode='PathInterpolator' fromField='value_changed' toNode='MISSILE_TRANSFORM' toField='set_translation'/>
75	< ROUTE fromNode='CLOCK2' fromField='fraction_changed' toNode='SpinInterpolator' toField='set_fraction'/>
76	< ROUTE fromNode='SpinInterpolator' fromField='value_changed' toNode='MISSILE_TRANSFORM' toField='set_rotation'/>
77	<!-- Set ROUTE for missile to rotate longitudinally when touched. -->
78	< ROUTE fromNode='MyTouchSensor' fromField='isOver' toNode='CLOCK1' toField='set_enabled'/>
79	< ROUTE fromNode='CLOCK1' fromField='fraction_changed' toNode='RotateInterpolator' toField='set_fraction'/>
80	< ROUTE fromNode='RotateInterpolator' fromField='value_changed' toNode='MISSILE_TRANSFORM' toField='set_rotation'/>
81	</Scene>
82	</X3D>

X3D Model Documentation: AGM65MaverickViewAnchors.x3d
