X3D Model Documentation: RadioWithAntenna.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">
  3  <X3D profile='Immersive' version='3.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
  4       <head>
  5            <meta name='title' content=' RadioWithAntenna.x3d '/>
  6            <meta name='description' content='A smartbridges radio inline with sector panel antenna inline with cable extrusion, produced as a MV4204 class project.'/>
  7            <meta name='creator' content='Mark P. Sullivan'/>
  8            <meta name='created' content='21 July 2003'/>
  9            <meta name='modified' content='20 October 2019'/>
 10            <meta name='generator' content='X3D-Edit 3.2, https://www.web3d.org/x3d/tools/X3D-Edit'/>
 11            <meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Savage/CommunicationsAndSensors/WISP/RadioWithAntenna.x3d '/>
 12            <meta name='license' content='../../license.html'/>
 13       </head>
<!--
<!-- -->
<!-- to top DEF nodes index: Cable, CAT5, CpeRadioPlusSticker, UBolt, UBolts

Index for Viewpoint node: Viewpoint_1
-->
 14       <Scene>
 15            <WorldInfo title='RadioWithAntenna.x3d'/>
 16            <Viewpoint description='RadioWithAntenna' position='0 0 4'/>
 17            <Transform scale='.5 .5 .5'>
 18                 <Shape>
 19                      <Appearance>
 20                           <Material diffuseColor='1 1 1'/>
 21                      </Appearance>
 22                      <Extrusion convex='false' creaseAngle='0.785' crossSection='-0.43214 0.09999 -0.43214 -0 0.18214 -0 0.18214 0.09999 0.15 0.09999 0.15 0.02692 0.07857 0.02692 -0.04642 0.20769 -0.20714 0.20769 -0.33571 0.03076 -0.40714 0.03076 -0.40714 0.09615 -0.43214 0.09999' solid='false' spine='0 -1 0 0 1 0'/>
 23                 </Shape>
 24            </Transform>
 25            <Transform translation='-.067 -.7 .01'>
 26                 <Inline DEF='CpeRadioPlusSticker'   url=' "CpeRadioPlusSticker.x3d" "https://www.web3d.org/x3d/content/examples/Savage/CommunicationsAndSensors/WISP/CpeRadioPlusSticker.x3d" "CpeRadioPlusSticker.wrl" "https://www.web3d.org/x3d/content/examples/Savage/CommunicationsAndSensors/WISP/CpeRadioPlusSticker.wrl" '/>
 27            </Transform>
 28            <Transform DEF='Cable' rotation='1 0 0 1.57' translation='-.065 -.69 .01'>
 29                 <Shape>
 30                      <Appearance>
 31                           <Material diffuseColor='.02 .02 .02'/>
 32                      </Appearance>
 33                      <Extrusion creaseAngle='3.14' crossSection='0.00892 0.00961 0.00714 0.00961 0.00714 0.01153 0.00535 0.01153 0.00357 0.01346 0.00357 0.01346 0.00178 0.01346 0.0 0.01346 -0.00178 0.01346 -0.00178 0.01346 -0.00357 0.01346 -0.00535 0.01346 -0.00535 0.01346 -0.00714 0.01153 -0.00892 0.01153 -0.00892 0.00961 -0.01071 0.00961 -0.01071 0.00769 -0.01071 0.00576 -0.01071 0.00576 -0.01071 0.00384 -0.01071 0.00192 -0.01071 -0.0 -0.01071 -0.0 -0.01071 -0.00192 -0.01071 -0.00384 -0.00892 -0.00384 -0.00892 -0.00576 -0.00714 -0.00576 -0.00535 -0.00769 -0.00535 -0.00769 -0.00357 -0.00769 -0.00178 -0.00769 0.0 -0.00769 0.0 -0.00769 0.00178 -0.00769 0.00357 -0.00769 0.00357 -0.00769 0.00535 -0.00576 0.00714 -0.00576 0.00714 -0.00384 0.00892 -0.00384 0.00892 -0.00192 0.00892 -0.0 0.00892 -0.0 0.00892 0.00192 0.00892 0.00384 0.00892 0.00576 0.00892 0.00576 0.00892 0.00769 0.00892 0.00961' spine='0.0 0 -0.19999 0.0 0 -0.14499 0.0 0 -0.13749 0.00714 0 -0.12499 0.04285 0 -0.10499 0.08571 0 -0.07749 0.11428 0 -0.04749 0.13928 0 -0.00499 0.14642 0 0.03249 0.14642 0 0.06749 0.13571 0 0.08749 0.10714 0 0.11499 0.08571 0 0.12249 0.06428 0 0.12749 0.047 0 0.12 0.042 0 0.12 0.03071 0 0.10499 0.02714 0 0.09'/>
 34                 </Shape>
 35            </Transform>
 36            <Transform DEF='UBolts' translation='-.05 -.4 0'>
 37
               <!-- Shape UBolt is a DEF node that has 2 USE nodes: USE_1, USE_2 -->
                <Shape DEF='UBolt'>
 38                      <Appearance>
 39                           <Material diffuseColor='.6 .6 .6'/>
 40                      </Appearance>
 41                      <Extrusion creaseAngle='3.14' crossSection='0.00892 0.00961 0.00714 0.00961 0.00714 0.01153 0.00535 0.01153 0.00357 0.01346 0.00357 0.01346 0.00178 0.01346 0.0 0.01346 -0.00178 0.01346 -0.00178 0.01346 -0.00357 0.01346 -0.00535 0.01346 -0.00535 0.01346 -0.00714 0.01153 -0.00892 0.01153 -0.00892 0.00961 -0.01071 0.00961 -0.01071 0.00769 -0.01071 0.00576 -0.01071 0.00576 -0.01071 0.00384 -0.01071 0.00192 -0.01071 -0.0 -0.01071 -0.0 -0.01071 -0.00192 -0.01071 -0.00384 -0.00892 -0.00384 -0.00892 -0.00576 -0.00714 -0.00576 -0.00535 -0.00769 -0.00535 -0.00769 -0.00357 -0.00769 -0.00178 -0.00769 0.0 -0.00769 0.0 -0.00769 0.00178 -0.00769 0.00357 -0.00769 0.00357 -0.00769 0.00535 -0.00576 0.00714 -0.00576 0.00714 -0.00384 0.00892 -0.00384 0.00892 -0.00192 0.00892 -0.0 0.00892 -0.0 0.00892 0.00192 0.00892 0.00384 0.00892 0.00576 0.00892 0.00576 0.00892 0.00769 0.00892 0.00961' spine='-0.07714 0 -0.00461 -0.07714 0 -0.11076 -0.07714 0 -0.12692 -0.075 0 -0.14076 -0.06857 0 -0.15461 -0.06428 0 -0.15692 -0.05571 0 -0.17076 -0.04714 0 -0.17769 -0.03428 0 -0.1823 -0.01071 0 -0.18461 0.00428 0 -0.18 0.01928 0 -0.17076 0.03 0 -0.15461 0.04071 0 -0.14076 0.04285 0 -0.1223 0.045 0 -0.10384 0.04285 0 -0.00461'/>
 42                 </Shape>
 43            </Transform>
 44            <Transform translation='-.05 .4 0'>
 45                 <Shape USE='UBolt'/>
 46            </Transform>
 47            <Transform translation='-.05 -.65 0'>
 48                 <Shape USE='UBolt'/>
 49            </Transform>
 50            <Transform DEF='CAT5' translation='-.08 -1.4 .01'>
 51                 <Shape>
 52                      <Appearance>
 53                           <Material diffuseColor='.02 .02 .02'/>
 54                      </Appearance>
 55                      <Cylinder height='1.4' radius='.007'/>
 56                 </Shape>
 57            </Transform>
 58       </Scene>
 59  </X3D>
<!--
<!-- -->
