| 3 | <X3D profile='Immersive' version='3.0' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'> |
| 4 | <head> |
| 5 | <meta name='title' content=' SeatsLevelTwo.x3d '/> |
| 6 | <meta name='description' content='Viewer seats, level two'/> |
| 7 | <meta name='creator' content='LT Christos Kalogrias - Hellenic Navy'/> |
| 8 | <meta name='created' content='25 July 2003'/> |
| 9 | <meta name='modified' content='20 October 2019'/> |
| 10 |
<meta name='reference' content='http://www.fussballtempel.net/uefa/Gre/Nikos_Goumas.jpg' />
|
| 11 | <meta name='reference' content='http://www.wsoccer.com/stadium/greece/aek_athens/'/> |
| 12 | <meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Savage/Buildings/SoccerStadium/SeatsLevelTwo.x3d '/> |
| 13 | <meta name='generator' content=' https://www.web3d.org/x3d/content/README.X3D-Edit.html '/> |
| 14 | <meta name='license' content='../../license.html'/> |
| 15 | </head> |
DEF nodes index:
Fans,
Flag,
FlagCoor,
Logo,
LogoDown,
MoveFlag,
SeatsCollor,
SkapastiDown,
SkapastiUp,
SkepastiSeats,
SkepColmn,
SkepPole,
tenXtenSeats,
timer
| 16 | <Scene> |
| 17 | <WorldInfo title='SeatsLevelTwo.x3d'/> |
| 18 | <Transform DEF='SkapastiDown' translation='-30 0 86.5'> |
| 19 | <Transform rotation='0 0 1 -1.57'> |
| 20 | <Transform rotation='0 1 0 -1.57'> |
| 21 | <Shape> |
| 22 |
<!-- Appearance
SeatsCollor is a DEF node that has 1 USE node: USE_1 -->
<Appearance DEF='SeatsCollor'> |
| 23 | <Material diffuseColor='0.2 0.2 0.2'/> |
| 24 | </Appearance> |
| 25 | <Extrusion crossSection='0 0 -16 0 -16 2 -15 2 -15 3 -14 3 -14 4 -13 4 -13 5 -12 5 -12 6 -11 6 -11 7 -10 7 -10 8 -9 8 -9 9 -8 9 -8 10 -7 10 -7 11 -6 11 -6 12 -5 12 -5 13 -4 13 -4 14 -3 14 -3 15 -2 15 -2 16 -1 16 -1 17 0 17 0 0' spine='0 0 0 0 60 0'/> |
| 26 | </Shape> |
| 27 | |
| 28 | <Shape> |
| 29 | <Appearance> |
| 30 | <Material/> |
| 31 | </Appearance> |
| 32 | <Cylinder height='17' radius='0.2'/> |
| 33 | </Shape> |
| 34 | </Transform> |
| 35 | <Transform translation='0 59.4 0'> |
| 36 | <Transform USE='SkepPole'/> |
| 37 | </Transform> |
| 38 | </Transform> |
| 39 | </Transform> |
| 40 | </Transform> |
| 41 | <Transform translation='0 17 0'> |
| 42 | <Transform DEF='SkapastiUp' translation='-30 0 86.5'> |
| 43 | <Transform rotation='0 0 1 -1.57'> |
| 44 | <Transform rotation='0 1 0 -1.57'> |
| 45 | <Shape> |
| 46 | <Appearance USE='SeatsCollor'/> |
| 47 | <Extrusion crossSection='0 0 -16 0 -16 2 -15 2 -15 3 -14 3 -14 4 -13 4 -13 5 -12 5 -12 6 -11 6 -11 7 -10 7 -10 8 -9 8 -9 9 -8 9 -8 10 -7 10 -7 11 -6 11 -6 12 -5 12 -5 13 -4 13 -4 14 -3 14 -3 15 -2 15 -2 16 -1 16 -1 17 0 17 0 0' spine='0 0 0 0 60 0'/> |
| 48 | </Shape> |
| 49 | </Transform> |
| 50 | </Transform> |
| 51 | </Transform> |
| 52 |
<!-- Transform
SkepastiSeats is a DEF node that has 1 USE node: USE_1 -->
<Transform DEF='SkepastiSeats' translation='-30 0 86.5'> |
| 53 | |
| 54 | <Transform DEF='tenXtenSeats'> |
| 55 | <Transform rotation='1 0 0 0.78' translation='6 10 -8'> |
| 56 | <Transform DEF='Fans' scale='1.333 4 1' translation='0 1 0'> |
| 57 | <Group> |
| 58 | <Transform translation='-3.7 -3 -1'> |
| 59 | <Shape> |
| 60 | <IndexedFaceSet DEF='Flag' convex='false' solid='false' coordIndex='0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 0'> |
| 61 |
<!-- ROUTE information for FlagCoor node:
[from MoveFlag.value_changed to set_point
]
-->
<Coordinate DEF='FlagCoor' point='0.0 0.0 0.0 0.5 0.0 0.0 1.0 0.0 0.0 1.5 0.0 0.0 2.0 0.0 0.0 2.5 0.0 0.0 3.0 0.0 0.0 3.5 0.0 0.0 4.0 0.0 0.0 4.5 0.0 0.0 5.0 0.0 0.0 5.5 0.0 0.0 6.0 0.0 0.0 6.5 0.0 0.0 7.0 0.0 0.0 7.5 0.0 0.0 7.5 0.5 0.0 7.5 1.0 0.0 7.5 1.5 0.0 7.5 2.0 0.0 7.5 2.5 0.0 7.5 3.0 0.0 7.5 3.5 0.0 7.5 4.0 0.0 7.5 4.5 0.0 7.5 5.0 0.0 7.0 5.0 0.0 6.5 5.0 0.0 6.0 5.0 0.0 5.5 5.0 0.0 5.0 5.0 0.0 4.5 5.0 0.0 4.0 5.0 0.0 3.5 5.0 0.0 3.0 5.0 0.0 2.5 5.0 0.0 2.0 5.0 0.0 1.5 5.0 0.0 1.0 5.0 0.0 0.5 5.0 0.0 0.0 5.0 0.0 0.0 4.5 0.0 0.0 4.0 0.0 0.0 3.5 0.0 0.0 3.0 0.0 0.0 2.5 0.0 0.0 2.0 0.0 0.0 1.5 0.0 0.0 1.0 0.0 0.0 0.5 0.0'/> |
| 62 | </IndexedFaceSet> |
| 63 | <Appearance> |
| 64 | <Material diffuseColor='0.8 0.2 0.2' shininess='0.8'/> |
| 65 |
<ImageTexture
url=' "./aek5.jpg
" "https://www.web3d.org/x3d/content/examples/Savage/Buildings/SoccerStadium/aek5.jpg
" '/>
|
| 66 | <TextureTransform translation='0.0 0.01'/> |
| 67 | </Appearance> |
| 68 | </Shape> |
| 69 |
<!-- ROUTE information for timer node:
[from fraction_changed to MoveFlag.set_fraction
]
-->
<TimeSensor DEF='timer' cycleInterval='4.0' loop='true'/> |
| 70 |
<!-- ROUTE information for MoveFlag node:
[from timer.fraction_changed to set_fraction
]
[from value_changed to FlagCoor.set_point
]
-->
<CoordinateInterpolator DEF='MoveFlag' key='0.0 0.25 0.5 0.75 1.0' keyValue='0.0 0.0 0.00 0.5 0.0 0.087 1.0 0.0 .100 1.5 0.0 0.087 2.0 0.0 0.00 2.5 0.0 -0.087 3.0 0.0 -.100 3.5 0.0 -0.087 4.0 0.0 0.0 4.5 0.0 0.087 5.0 0.0 .10 5.5 0.0 0.087 6.0 0.0 0.0 6.5 0.0 -0.087 7.0 0.0 -.10 7.5 0.0 -0.087 7.5 0.5 -0.087 7.5 1.0 -0.087 7.5 1.5 -0.087 7.5 2.0 -0.087 7.5 2.5 -0.087 7.5 3.0 -0.087 7.5 3.5 -0.087 7.5 4.0 -0.087 7.5 4.5 -0.087 7.5 5.0 -0.087 7.0 5.0 -.10 6.5 5.0 -0.087 6.0 5.0 0.0 5.5 5.0 0.087 5.0 5.0 .10 4.5 5.0 0.087 4.0 5.0 0.0 3.5 5.0 -0.087 3.0 5.0 -.10 2.5 5.0 -0.087 2.0 5.0 0.0 1.5 5.0 0.087 1.0 5.0 .10 0.5 5.0 0.087 0.0 5.0 0.0 0.0 4.5 0.0 0.0 4.0 0.0 0.0 3.5 0.0 0.0 3.0 0.0 0.0 2.5 0.0 0.0 2.0 0.0 0.0 1.5 0.0 0.0 1.0 0.0 0.0 0.5 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.5 0.0 -0.087 1.0 0.0 -.10 1.5 0.0 -0.087 2.0 0.0 0.0 2.5 0.0 0.087 3.0 0.0 .10 3.5 0.0 0.087 4.0 0.0 0.0 4.5 0.0 -0.087 5.0 0.0 -.10 5.5 0.0 -0.087 6.0 0.0 0.0 6.5 0.0 0.087 7.0 0.0 .10 7.5 0.0 0.087 7.5 0.5 0.087 7.5 1.0 0.087 7.5 1.5 0.087 7.5 2.0 0.087 7.5 2.5 0.087 7.5 3.0 0.087 7.5 3.5 0.087 7.5 4.0 0.087 7.5 4.5 0.087 7.5 5.0 0.087 7.0 5.0 .10 6.5 5.0 0.087 6.0 5.0 0.0 5.5 5.0 -0.087 5.0 5.0 -.10 4.5 5.0 -0.087 4.0 5.0 0.0 3.5 5.0 0.087 3.0 5.0 .10 2.5 5.0 0.087 2.0 5.0 0.0 1.5 5.0 -0.087 1.0 5.0 -.10 0.5 5.0 -0.087 0.0 5.0 0.0 0.0 4.5 0.0 0.0 4.0 0.0 0.0 3.5 0.0 0.0 3.0 0.0 0.0 2.5 0.0 0.0 2.0 0.0 0.0 1.5 0.0 0.0 1.0 0.0 0.0 0.5 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.5 0.0 0.087 1.0 0.0 .10 1.5 0.0 0.087 2.0 0.0 0.0 2.5 0.0 -0.087 3.0 0.0 -.10 3.5 0.0 -0.087 4.0 0.0 0.0 4.5 0.0 0.087 5.0 0.0 .10 5.5 0.0 0.087 6.0 0.0 0.0 6.5 0.0 -0.087 7.0 0.0 -.10 7.5 0.0 -0.087 7.5 0.5 -0.087 7.5 1.0 -0.087 7.5 1.5 -0.087 7.5 2.0 -0.087 7.5 2.5 -0.087 7.5 3.0 -0.087 7.5 3.5 -0.087 7.5 4.0 -0.087 7.5 4.5 -0.087 7.5 5.0 -0.087 7.0 5.0 -.10 6.5 5.0 -0.087 6.0 5.0 0.0 5.5 5.0 0.087 5.0 5.0 .10 4.5 5.0 0.087 4.0 5.0 0.0 3.5 5.0 -0.087 3.0 5.0 -.10 2.5 5.0 -0.087 2.0 5.0 0.0 1.5 5.0 0.087 1.0 5.0 .10 0.5 5.0 0.087 0.0 5.0 0.0 0.0 4.5 0.0 0.0 4.0 0.0 0.0 3.5 0.0 0.0 3.0 0.0 0.0 2.5 0.0 0.0 2.0 0.0 0.0 1.5 0.0 0.0 1.0 0.0 0.0 0.5 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.5 0.0 -0.087 1.0 0.0 -.10 1.5 0.0 -0.087 2.0 0.0 0.0 2.5 0.0 0.087 3.0 0.0 .10 3.5 0.0 0.087 4.0 0.0 0.0 4.5 0.0 -0.087 5.0 0.0 -.10 5.5 0.0 -0.087 6.0 0.0 0.0 6.5 0.0 0.087 7.0 0.0 .10 7.5 0.0 0.087 7.5 0.5 0.087 7.5 1.0 0.087 7.5 1.5 0.087 7.5 2.0 0.087 7.5 2.5 0.087 7.5 3.0 0.087 7.5 3.5 0.087 7.5 4.0 0.087 7.5 4.5 0.087 7.5 5.0 0.087 7.0 5.0 .10 6.5 5.0 0.087 6.0 5.0 0.0 5.5 5.0 -0.087 5.0 5.0 -.10 4.5 5.0 -0.087 4.0 5.0 0.0 3.5 5.0 0.087 3.0 5.0 .10 2.5 5.0 0.087 2.0 5.0 0.0 1.5 5.0 -0.087 1.0 5.0 -1.0 0.5 5.0 -0.087 0.0 5.0 0.0 0.0 4.5 0.0 0.0 4.0 0.0 0.0 3.5 0.0 0.0 3.0 0.0 0.0 2.5 0.0 0.0 2.0 0.0 0.0 1.5 0.0 0.0 1.0 0.0 0.0 0.5 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.5 0.0 0.087 1.0 0.0 .10 1.5 0.0 0.087 2.0 0.0 0.0 2.5 0.0 -0.087 3.0 0.0 -.10 3.5 0.0 -0.087 4.0 0.0 0.0 4.5 0.0 0.087 5.0 0.0 .10 5.5 0.0 0.087 6.0 0.0 0.0 6.5 0.0 -0.087 7.0 0.0 -.10 7.5 0.0 -0.087 7.5 0.5 -0.087 7.5 1.0 -0.087 7.5 1.5 -0.087 7.5 2.0 -0.087 7.5 2.5 -0.087 7.5 3.0 -0.087 7.5 3.5 -0.087 7.5 4.0 -0.087 7.5 4.5 -0.087 7.5 5.0 -0.087 7.0 5.0 -.10 6.5 5.0 -0.087 6.0 5.0 0.0 5.5 5.0 0.087 5.0 5.0 .10 4.5 5.0 0.087 4.0 5.0 0.0 3.5 5.0 -0.087 3.0 5.0 -.10 2.5 5.0 -0.087 2.0 5.0 0.0 1.5 5.0 0.087 1.0 5.0 .10 0.5 5.0 0.087 0.0 5.0 0.0 0.0 4.5 0.0 0.0 4.0 0.0 0.0 3.5 0.0 0.0 3.0 0.0 0.0 2.5 0.0 0.0 2.0 0.0 0.0 1.5 0.0 0.0 1.0 0.0 0.0 0.5 0.0 0.0 0.0 0.0'/> |
| 71 | </Transform> |
| 72 | </Group> |
| 73 | < ROUTE fromNode='timer' fromField='fraction_changed' toNode='MoveFlag' toField='set_fraction'/> |
| 74 | < ROUTE fromNode='MoveFlag' fromField='value_changed' toNode='FlagCoor' toField='set_point'/> |
| 75 | </Transform> |
| 76 | </Transform> |
| 77 | </Transform> |
| 78 | </Transform> |
| 79 | <Transform translation='11 0 0'> |
| 80 | <Transform USE='SkepColmn'/> |
| 81 | </Transform> |
| 82 | <Transform translation='21 0 0'> |
| 83 | <Transform USE='SkepColmn'/> |
| 84 | </Transform> |
| 85 | <Transform translation='31 0 0'> |
| 86 | <Transform USE='SkepColmn'/> |
| 87 | </Transform> |
| 88 | <Transform translation='37 0 0'> |
| 89 | <Transform USE='SkepColmn'/> |
| 90 | </Transform> |
| 91 | <Transform translation='48 0 0'> |
| 92 | <Transform USE='SkepColmn'/> |
| 93 | </Transform> |
| 94 | </Transform> |
| 95 | <Transform translation='0 -17 0'> |
| 96 | <Transform USE='SkepastiSeats'/> |
| 97 | </Transform> |
| 98 | </Transform> |
| 99 | <Viewpoint description='Two Level Seats View' orientation='0 1 0 3.14' position='0 1.8 20'/> |
| 100 | |
| 101 | |
| 102 | <Shape> |
| 103 | <Appearance> |
| 104 |
<ImageTexture
url=' "web3d.gif
" "https://www.web3d.org/x3d/content/examples/Savage/Buildings/SoccerStadium/web3d.gif
" '/>
|
| 105 | <Material diffuseColor='0.7 0.7 0.1' shininess='0.9'/> |
| 106 | </Appearance> |
| 107 | <Box size='0.01 2 5'/> |
| 108 | </Shape> |
| 109 | <Transform translation='0 0 5'> |
| 110 | <Shape> |
| 111 | <Appearance> |
| 112 |
<ImageTexture
url=' "x3d.gif
" "https://www.web3d.org/x3d/content/examples/Savage/Buildings/SoccerStadium/x3d.gif
" '/>
|
| 113 | <Material diffuseColor='0.7 0.7 0.1' shininess='0.9'/> |
| 114 | </Appearance> |
| 115 | <Box size='0.01 2 5'/> |
| 116 | </Shape> |
| 117 | </Transform> |
| 118 | </Transform> |
| 119 | <Transform translation='10 0 0'> |
| 120 | <Transform USE='Logo'/> |
| 121 | </Transform> |
| 122 | <Transform translation='20 0 0'> |
| 123 | <Transform USE='Logo'/> |
| 124 | </Transform> |
| 125 | <Transform translation='-10 0 0'> |
| 126 | <Transform USE='Logo'/> |
| 127 | </Transform> |
| 128 | <Transform translation='-20 0 0'> |
| 129 | <Transform USE='Logo'/> |
| 130 | </Transform> |
| 131 | <Transform scale='0.9 1 1' translation='29 0 0'> |
| 132 | <Transform USE='Logo'/> |
| 133 | </Transform> |
| 134 | </Transform> |
| 135 | <Transform translation='0 17 0'> |
| 136 | <Transform USE='LogoDown'/> |
| 137 | </Transform> |
| 138 | </Scene> |
| 139 | </X3D> |
