Event Graph ROUTE Table entries with 21 ROUTE connections total, showing X3D event-model relationships for this scene.
Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.
BlueWireClock
TimeSensor fraction_changed SFFloat |
RedBallPath3
PositionInterpolator set_fraction SFFloat |
then |
RedBallPath3
PositionInterpolator value_changed SFVec3f |
RedBallTransform3
Transform set_translation SFVec3f |
||
BlueWireClock
TimeSensor fraction_changed SFFloat |
GreenBallPath3
PositionInterpolator set_fraction SFFloat |
then |
GreenBallPath3
PositionInterpolator value_changed SFVec3f |
GreenBallTransform3
Transform set_translation SFVec3f |
||
BlueWireClock
TimeSensor fraction_changed SFFloat |
YellowBallPath3
PositionInterpolator set_fraction SFFloat |
then |
YellowBallPath3
PositionInterpolator value_changed SFVec3f |
YellowBallTransform3
Transform set_translation SFVec3f |
YellowClock
TimeSensor fraction_changed SFFloat |
YellowBallPath2
PositionInterpolator set_fraction SFFloat |
then |
YellowBallPath2
PositionInterpolator value_changed SFVec3f |
YellowBallTransform2
Transform set_translation SFVec3f |
<!--
Online at
https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/IkeaBeadToyIndex.html
-->
<!--
Version control at
https://sourceforge.net/p/x3d/code/HEAD/tree/www.web3d.org/x3d/content/examples/Basic/StudentProjects/IkeaBeadToy.x3d
-->
<!--
