X3D Example Archives: Basic, Networking

[1] NetworkReroutingAlternateRoutes.x3d - Network Rerouting Alternate Routes
Chapter Viewpoint Slideshow
Network Rerouting over Alternate Routes

This directory includes several experiments with X3D Networking.

Long-running efforts have attempted to define and build a new NetworkSensor node for X3D. Although useful design progress was made by the X3D working group, this work did not reach closure because author-written implementations did not appear to be possible using X3D prototypes. Further implementation and evaluation work might someday be pursued using an X3D browser implementation.

Examples of additional networking techniques for X3D can also be added to this archive. Of related interest: the Distributed Interactive Simulation (DIS) examples in this archive, which include native X3D support for the IEEE Distributed Interactive Simulation (DIS) networking-protocol standard.

4 X3D Scenes                 4 Viewpoint Snapshots

NetworkReroutingAlternateRoutes
Network Rerouting Alternate Routes.x3d
[1] NetworkReroutingAlternateRoutes.x3d - Network Rerouting Alternate Routes
[2] NetworkReroutingAlternateRoutes.x3d - (default X3D view from 0 0 10)

NetworkReroutingNetwork
Network Rerouting Network.x3d
[3] NetworkReroutingNetwork.x3d - (default X3D view from 0 0 10)

NetworkReroutingRoutes
Network Rerouting Routes.x3d
[4] NetworkReroutingRoutes.x3d - (default X3D view from 0 0 10)

NetworkSensorConnectionPrototypes
Network Sensor Connection Prototypes.x3d
[5] NetworkSensorConnectionPrototypes.x3d - (default X3D view from 0 0 10)


This viewpoint slideshow is online at
http://www.web3d.org/x3d/content/examples/Basic/Networking/viewpointSlideshow.html

Validate XHTML 1.1

Viewpoint image version history at
http://sourceforge.net/p/x3d/code/HEAD/tree/www.web3d.org/x3d/content/examples/Basic/Networking/_viewpoints
