<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">
<X3D profile='Interchange'  version='3.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation =' https://www.web3d.org/specifications/x3d-3.0.xsd ' >
<head>
<meta name='title' content=' ProfileExampleInterchange.x3d '/>
<meta name='creator' content='Don Brutzman'/>
<meta name='created' content='6 January 2000'/>
<meta name='modified' content='20 October 2019'/>
<meta name='description' content='List of nodes available in a strictly compliant Interchange profile scene. Only Background renders in this example, other nodes have null values.'/>
<meta name='reference' content=' https://www.web3d.org/spec_editors/abstract/Part01/interchange.html '/>
<meta name='reference' content='ProfileExampleInterchange.png'/>
<meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Basic/development/ProfileExampleInterchange.x3d '/>
<meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
<meta name='license' content=' ../license.html'/>
</head>
<!--
to top <!-- Event Graph ROUTE Table shows event connections -->

<!-- Index for DEF nodes: CI, NI, OI, PI, SI, SilenceWarnings, TS
Index for Viewpoint node: Viewpoint_1
-->
<Scene>
<Group>
<Shape>
<Appearance>
<ImageTexture
  url=' "earth-topo.png " "earth-topo.gif " "https://www.web3d.org/x3d/content/examples/Basic/development/earth-topo.png " "https://www.web3d.org/x3d/content/examples/Basic/development/earth-topo.gif " ' />
<Material/>
<TextureTransform/>
</Appearance>
<IndexedFaceSet creaseAngle='3.14159'>
<Color color='1 1 1'/>
<Coordinate point='0 0 0'/>
<MultiTextureCoordinate containerField='texCoord'/>
</IndexedFaceSet>
</Shape>
<Shape>
<IndexedLineSet>
<ColorRGBA color='1 1 1 1'/>
</IndexedLineSet>
</Shape>
<Shape>
<Box/>
<Appearance DEF='SilenceWarnings'/>
</Shape>
<Shape>
<Cone/>
<Appearance USE=' SilenceWarnings'/>
</Shape>
<Shape>
<Cylinder/>
<Appearance USE=' SilenceWarnings'/>
</Shape>
<Shape>
<IndexedTriangleFanSet ccw='true' colorPerVertex='true' normalPerVertex='true' solid='true' containerField='geometry'>
<TextureCoordinate point='0 0'/>
</IndexedTriangleFanSet>
<Appearance USE=' SilenceWarnings'/>
</Shape>
<Shape>
<IndexedTriangleSet ccw='true' colorPerVertex='true' normalPerVertex='true' solid='true' containerField='geometry'>
<TextureCoordinateGenerator/>
</IndexedTriangleSet>
<Appearance USE=' SilenceWarnings'/>
</Shape>
<Shape>
<IndexedTriangleStripSet ccw='true' colorPerVertex='true' normalPerVertex='true' solid='true' containerField='geometry'>
<Normal vector='0 1 0'/>
</IndexedTriangleStripSet>
<Appearance USE=' SilenceWarnings'/>
</Shape>
<Shape>
<LineSet containerField='geometry'/>
<Appearance>
<MultiTexture/>
<MultiTextureTransform containerField='textureTransform'/>
</Appearance>
</Shape>
<Shape>
<Appearance>
<PixelTexture/>
</Appearance>
<PointSet/>
</Shape>
<Shape>
<Sphere/>
<Appearance USE=' SilenceWarnings'/>
</Shape>
<Shape>
<TriangleFanSet ccw='true' colorPerVertex='true' normalPerVertex='true' solid='true' containerField='geometry'/>
<Appearance USE=' SilenceWarnings'/>
</Shape>
<Shape>
<TriangleSet ccw='true' colorPerVertex='true' normalPerVertex='true' solid='true' containerField='geometry'/>
<Appearance USE=' SilenceWarnings'/>
</Shape>
<Shape>
<TriangleStripSet ccw='true' colorPerVertex='true' normalPerVertex='true' solid='true' containerField='geometry'/>
<Appearance USE=' SilenceWarnings'/>
</Shape>
</Group>
<Background groundColor='0 0 0' skyColor='0.0 0.2 0.7'/>
<CoordinateInterpolator DEF='CI'/>
<DirectionalLight/>
<NavigationInfo/>
<!-- ROUTE information for NI node:  [from TS.fraction_changed to set_fraction ] -->
 <NormalInterpolator DEF='NI' key='0 1' keyValue='0 1 0 0 1 0'/>

<!-- ROUTE information for OI node:  [from TS.fraction_changed to set_fraction ] -->
 <OrientationInterpolator DEF='OI' key='0 1' keyValue='0 1 0 0 0 1 0 0'/>

<!-- ROUTE information for PI node:  [from TS.fraction_changed to set_fraction ] [from TS.fraction_changed to set_fraction ] -->
 <PositionInterpolator DEF='PI' key='0 1' keyValue='0 0 0 0 0 0'/>

<!-- ROUTE information for SI node:  [from TS.fraction_changed to set_fraction ] -->
 <ScalarInterpolator DEF='SI' key='0 1' keyValue='0 0'/>

<!-- ROUTE information for TS node:  [from fraction_changed to NI.set_fraction ] [from fraction_changed to OI.set_fraction ] [from fraction_changed to PI.set_fraction ] [from fraction_changed to SI.set_fraction ] [from fraction_changed to PI.set_fraction ] -->
 <TimeSensor DEF='TS' enabled='false'/>

< ROUTE  fromNode=' TS' fromField='fraction_changed' toNode=' NI' toField='set_fraction'/>
< ROUTE  fromNode=' TS' fromField='fraction_changed' toNode=' OI' toField='set_fraction'/>
< ROUTE  fromNode=' TS' fromField='fraction_changed' toNode=' PI' toField='set_fraction'/>
< ROUTE  fromNode=' TS' fromField='fraction_changed' toNode=' SI' toField='set_fraction'/>
<Transform/>
<Viewpoint description='InterchangeProfileExample'/>
<WorldInfo/>
< ROUTE  fromNode=' TS' fromField='fraction_changed' toNode=' PI' toField='set_fraction'/>
</Scene>
</X3D>
<!--
to top <!-- Event Graph ROUTE Table shows event connections -->

<!-- Index for DEF nodes: CI, NI, OI, PI, SI, SilenceWarnings, TS
Index for Viewpoint node: Viewpoint_1
-->

Event Graph ROUTE Table with 5 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

TS
TimeSensor
fraction_changed
SFFloat

ROUTE
event to
(1)
NI
NormalInterpolator
set_fraction
SFFloat
TS
TimeSensor
fraction_changed
SFFloat

ROUTE
event to
(1)
OI
OrientationInterpolator
set_fraction
SFFloat
TS
TimeSensor
fraction_changed
SFFloat

ROUTE
event to
(1)
PI
PositionInterpolator
set_fraction
SFFloat
TS
TimeSensor
fraction_changed
SFFloat

ROUTE
event to
(1)
SI
ScalarInterpolator
set_fraction
SFFloat
TS
TimeSensor
fraction_changed
SFFloat

ROUTE
event to
(1)
PI
PositionInterpolator
set_fraction
SFFloat

-->
