GroupFormation.x3d (X3dToXhtml listing)

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">

<X3D profile='Interchange' version='3.0' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation =' https://www.web3d.org/specifications/x3d-3.0.xsd ' >

<head>

<meta name='title' content=' GroupFormation.x3d '/>
<meta name='creator' content='Don Brutzman'/>
<meta name='created' content='8 November 2001'/>
<meta name='modified' content='20 October 2019'/>
<meta name='description' content='Simple example to demonstrate rotating a Group of copied, elongated Boxes.'/>
<meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Basic/course/GroupFormation.x3d '/>
<meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
<meta name='license' content=' ../license.html'/>

</head>
<!--

<!-- Index for DEF nodes: FLYING_BOX, LEAD_ENTITY, SECOND_ENTITY, THIRD_ENTITY

Index for Viewpoint node: Viewpoint_1

-->
<Scene>

<WorldInfo title='GroupFormation.x3d'/>
<Viewpoint description='watch the boxes' position='0 2 10'/>

<Transform rotation='0 1 0 -0.345'>

<Group DEF='LEAD_ENTITY'>

<Shape DEF='FLYING_BOX'>

<Box size='.5 .5 3'/>
<Appearance>

<Material diffuseColor='0 .2 .8'/>

</Appearance>

</Shape>

</Group>
<Transform DEF='SECOND_ENTITY' translation='5 0 -2'>

<Shape USE=' FLYING_BOX'/>

</Transform>
<Transform DEF='THIRD_ENTITY' translation='-5 0 -2'>

<Shape USE=' FLYING_BOX'/>

</Transform>

</Transform>

</Scene>

</X3D>
<!--

<!-- Index for DEF nodes: FLYING_BOX, LEAD_ENTITY, SECOND_ENTITY, THIRD_ENTITY

Index for Viewpoint node: Viewpoint_1

-->

-->
