X3D Example Archives: Basic, Networking

[1] NetworkReroutingAlternateRoutes.x3d Network Rerouting Alternate Routes
Directory Viewpoint Slideshow
Network Rerouting over Alternate Routes

This directory includes several experiments with X3D Networking.

Long-running efforts have attempted to define and build a new NetworkSensor node for X3D. Although useful design progress was made by the X3D working group, this work did not reach closure because author-written implementations did not appear to be possible using X3D prototypes encapsulating sandbox-restricted JavaScript network access from within an HTML browser. Further implementation and evaluation work might someday be pursued using an X3D browser implementation.

Examples of additional networking techniques for X3D can also be added to this archive. Of related interest: the Distributed Interactive Simulation (DIS) examples in this archive, which include native X3D support for the IEEE Distributed Interactive Simulation (DIS) networking-protocol standard.

4 X3D Models                 4 X3D Model Viewpoint Snapshots

NetworkReroutingAlternateRoutes
Network Rerouting Alternate Routes.x3d
[1] NetworkReroutingAlternateRoutes.x3d Network Rerouting Alternate Routes
[2] NetworkReroutingAlternateRoutes.x3d (default X3D view from 0 0 10)

NetworkReroutingNetwork
Network Rerouting Network.x3d
[3] NetworkReroutingNetwork.x3d (default X3D view from 0 0 10)

NetworkReroutingRoutes
Network Rerouting Routes.x3d
[4] NetworkReroutingRoutes.x3d (default X3D view from 0 0 10)

NetworkSensorConnectionPrototypes
Network Sensor Connection Prototypes.x3d
[5] NetworkSensorConnectionPrototypes.x3d (default X3D view from 0 0 10)


This viewpoint slideshow is online at
https://www.web3d.org/x3d/content/examples/Basic/Networking/viewpointSlideshow.html
